  1. STATION AUGMENTATION NNN0FCC 19 OCTOBER 2003

  2. STATION #1 • IC-751 2-30 MHz, SSB, 100 Watts, IC-AT-500 Tuner • IC-751A 2-30 MHz, Digital, 100 Watts • MFJ Deluxe Versa Tuner • IC-706 MK-II-G, 2-30, 6-mtrs, 2-mtrs, 440, AT-160 Tuner • TS-711A 2 Meters, all mode, 25 Watts • PK-232-PSK TNC, AEA PKterm for Windows • Toshiba Satellite T-2135C laptop (Win 95) • MFJ-1275 Sound Card Interface, MixW2 • Compaq Presario 1626 laptop (Win 98)

  3. NNN0FCC Main operating position

  4. Main Antenna Switch

  5. STATION #2 • IC-746-PRO 2-30 SSB/Digital, 100 Watts • MFJ Deluxe Versa Tuner • FT-8900 10/6/2/440 FM/Digital, 50 Watts • Dell Dimension Desktop, Windows 2000 • PK-232-MBX, AEA PLTerm for Windows • MFJ-1275 Sound Card Interface

  6. STATION #2

  7. Additional Equipment, Station #2 • D-700-A Packet/APRS Station • FT-8900 MARS Packet Mail Box • KAM PLUS • KPC-3+ with K-Net 3+ ROMs

  8. NNN0FCC ANTENNA FARM • 80 METER DIPOLE @ 17 feet • 160 METER LOADED DIPOLE @ 35 feet • 10 to 40 vertical, ground mounted • 2-30 B&W FOLDED DIPOLE @ 35 feet • AEA ISO-POLE 2 meter vertical @ 25 feet • Cushcraft 11-element beam @ 18 feet • AR-270 vertical @ 20 feet • Diamond 6-2-440 vertical @ 40 feet • Full size 6 meter vertical at 12 feet

  9. EMERGENCY POWER • Craftsman 6,000 Watt, gasoline generator • 30 Amp, 110/220 VAC • Powers entire house (less air conditioners) • 8 hours per 5 gallon tank • 10 gallon storage capacity • Sources 12 Volts to charge batteries or run 12 Volt equipment • Deep Cycle Marine Battery, 160 Amp-Hours • Spare Automotive Battery

  10. EMERGENCY POWER

  11. Additional Radio Equipment • IC-T81-A, 6/2/440/1.2GHz hand-held, 5-Watts • IC-24AT 2/440 hand-held, 5-Watts • Uniden BC-580 trunking scanner • RCA Scantrak Scanner • Swan FM-2X, 2 Meter, Xtal-controlled • 80-watt, 2 Meter amplifier
