  1. Ca++ Na+ Cl- SO4= NO3- Water Test Interpretation Mike Kizer OSU Extension Irrigation Specialist HCO3- CO3= K+ Mg++

  2. Measures of Water Quality • Electrical Conductivity (EC) • Total Dissolved Solids (TDS) • Individual mineral concentrations • Calculated salinity products (Hardness, SAR, Na%, etc.)

  3. Electrical Conductivity(EC) • Pure water is a poor conductor of electricity • The more minerals dissolved in water, the more current it conducts • EC is a good estimator of total mineral content (TSS)

  4. Units - EC • mmho/cm = (millimho per centimeter) • mmho/cm = (micromho per centimeter) • dS/m = (deciSiemen/meter) • mS/cm = (milliSiemen per centimeter) • 1 mmho/cm = 1 dS/m = 1mS/cm • 1 mmho/cm = 1000 mmho/cm

  5. Total Dissolved Solids(TDS) • TDS is calculated by totaling all measured mineral concentrations as determined by chemical analyses • TSS is an estimate of TDS based on EC • EC (mmho/cm) x 640  TSS mg/l • This equivalence is approximate and depends on the ions causing the salinity

  6. Units - TDS / TSS mg/l = milligrams/liter ppm = parts per million mg/l = micrograms/liter ppb = parts per billion • 1 mg/l = 1 ppm in water chemistry (1 liter of water weighs 1,000,000 mg) • 1 mg/l = 1000 mg /l • 1 mg /l = 1 ppb in water chemistry

  7. SW&FAL Water Quality Tests The OSU Soil Water & Forage Analytical Laboratory (Room 048 Ag. Hall) offers three water tests: • Livestock Water Test • Household Water Test • Irrigation Water Test (All tests require a 1 pint water sample)

  8. Livestock Water Test • Price: $6.00 • Analytes: • pH • Total Soluble Salts (TSS) • Electrical Conductivity (EC) • Nitrate-Nitrogen (NO3-N)

  9. Livestock Water QualityTotal Soluble Salts -TSS TSS (ppm)Interpretation • Less than 1000: Excellent • 1000 – 3000: Satisfactory for all animals • 3000 – 5000: Unsatisfactory for poultry • 5000 – 7000: Can be used except for pregnant, lactating or immature livestock • Over 10,000: Unsatisfactory for all animals

  10. Livestock Water QualityNitrate- Nitrogen –NO3-N NO3-N (ppm)Interpretation • Less than 100: Satisfactory for all animals • 100 – 290: Use with care when given in combination with high nitrate feeds (especially certain forages in times of drought) • Over 290: Unsatisfactory for all animals

  11. Livestock Water Quality • Sulfate (SO4) • If most of the TSS are sulfates the acceptable TSS level is reduced because of scouring concerns • Polioencephalomalasia (PEM) is a nervous system disease in cattle caused by thiamine deficiency. High dietary sulfate has been linked to thiamine deficiency by research and case studies. • pH • The preferred range is 6.0-8.5. Animals can tolerate water outside this range, but some species may perform poorly.

  12. Household Water Test • Price: $15.00 • Analytes: • Sodium (Na)  Nitrate-Nitrogen (NO3-N • Calcium (Ca)  Iron (Fe) • Magnesium (Mg)  Manganese (Mn) • Potassium (K)  Zn • Boron (B) Electrical Conductivity (EC) • Hardness Total soluble Salts (TSS) • Chloride (Cl)  Sodium Percentage • Sulfate (SO4)  pH

  13. Household Water TestNitrate-Nitrogen – (NO3-N) • NO3-N is the only analyte on the test with a Federal SDWA Standard • The NO3-N standard is 10 mg/l • Newborn infants (less than 9 months) and pregnant women are “at-risk” consumers • NO3-N affects the blood’s ability to carry oxygen, causing methemoglobenemia

  14. Household Water TestSecondary Contaminants • Other regulated analytes on the Household Water Test are Secondary Contaminants that have Federal SDWA Guidelines • Exceeding SDWA Guidelines is not a primary health risk • Secondary contaminants affect aesthetic quality of water (taste, odor, etc.) or damage the water system (hardness, corrosion, etc.)

  15. Household Water TestSecondary Contaminants Secondary contaminants can indirectly affect health: • High sulfates can cause diarrhea which could result in dehydration • Corrosion due to low pH and low alkalinity can leach lead and copper from plumbing fixtures which could cause lead toxicity

  16. Corrosiveness of WaterpH – Alkalinity Balance

  17. Household Water TestHardness Hardness is caused by calcium and magnesium (iron also contributes to hardness)

  18. Irrigation Water Test • Price: $15.00 • Analytes: • Sodium (Na) —Chloride (Cl) • Calcium (Ca) —Sulfate (SO4) • Magnesium (Mg) —Nitrate-Nitrogen (NO3-N) • Potassium (K) —Carbonate (CO3) • Boron (B) —Bicarbonate (HCO3) • pH —Electrical Conductivity (EC) • Hardness —Total Soluble Salts (TSS) • Residual Carbonates —Sodium Adsorption Ratio (SAR)

  19. Irrigation Water QualityImportant Analytes •EC (or TSS): determines soil osmotic potential •SAR (or Na%): rates infiltration problem potential •Boron: toxic at very low concentrations •Residual Carbonates (RSC): raises effective SAR/Na%

  20. The Effect of Salinity of Soil Water Availability Salt Concentrations 0.4% = 4000 mg/l 0.2% = 2000 mg/l 0.1% = 1000 mg/l

  21. Irrigation Water QualitySodium (Na) Hazard • Na generally creates soil infiltration problems before becoming toxic to plants • In hot, dry weather conditions sprinkling can lead to leaf burning due to Na toxicity • Na reduces soil permeability by dispersing clay particles which seal larger pore spaces • Na hazard is greater high clay content soils • Na hazard is greater in expanding clays than in non-expanding clays

  22. Potential for infiltration problems due to high Na+ water.

  23. Water Suitability Based on Total Salinity and Sodium Content (Example: EC = 1.7 dS/m = 1700 mho/cm and Na%= 35)

  24. Irrigation Water QualityBoron (B) • Crops are very sensitive to boron • Threshold soil concentration for yield reduction: 0.3 – 5 mg/l • Toxic to all vegetation: 10-15 mg/l • Typical boron toxicity symptoms are spotting, yellowing and/or drying at tips and edges of older leaves

  25. Irrigation Water QualityResidual Carbonates (RSC) • Excessive bicarbonate and carbonate in irrigation water will combine with calcium and magnesium ions in soil • This effectively increases the SAR and leads to greater risk of infiltration problems • Residual carbonates ≥ 2.5 are usually a problem RSC = (CO3 + HCO3) - (Ca + Mg)

  26. Nitrate Nitrogen • NO3-N in irrigation water should be accounted for in nutrient management • 1 mg/L of NO3-N in irrigation water applies 0.23 lb/acre of N per 1 inch of irrigation water applied

  27. Water Quality Units and Terms(Concentrations) 1 mg/l = 1 ppm = 1000 g/l= 1000ppb TSS = Total Soluble Salts TDS = Total Dissolved Solids TSS  TDS TSS, (mg/l)  640 x EC, (mmho/cm) (Electrical Conductivity) 1 mmho/cm = 1 dS/m = 1 mS/cm= 1000 mho/cm EC = electrical conductivity of water ECe = electrical conductivity of saturated soil extract

  28. Water Quality Units and Terms(Concentrations) meq/l = milliequivalents per liter epm = equivalents per million 1 meq/l = 1 epm Ionppm per meq/lIonppm per meq/l Ca 20 CO3 30 Mg 12 HCO3 61 Na 23 SO4 48 K 39 Cl 35.5

  29. Derived Water Quality Terms SAR = Sodium Adsorption Ratio SAR = Na (Ca+Mg)/2 Na% = Sodium Percentage Na% = (Na x 100) (Ca+Mg+K+Na) RSC = Residual Sodium Carbonates RSC = (CO3 + HCO3) - (Ca + Mg) (the 3 calculations on this page are in meq/l)

  30. OSU Publications • L-256 Understanding Your Livestock Water Test Report • L-296 Understanding Your Household Water Test Report • L-323 Understanding Your Irrigation Water Test Report • F-2401 Classification of Irrigation Water Quality To download a copy of this presentation go to: (http://biosystems.okstate.edu/Home/mkizer/index.htm)
