  1. CANLYTE SOLID STATE LIGHTING Canlyte with Philips, Lightolier SSL, Calculite, Color Kinetics and Keene LED products is positioned to be the leading company for SSL products in the Canadian market

  2. NextLEDTaking LED to the Next Level

  3. NextLED The New Standard in LED Technology • Canlyte & Philips • LED Development Team • Technology • High-end Optical Design • Standards & Legislation • Developed a New Standard in: • Light Quality • Reliability • Energy Efficiency • System Approach • Develop a Wide Range of Products • Commercially Viable & Sustainable • Performance

  4. IES Recommended Standards • Designed & Tested to IES Recommended Standards • IES LM-80 • IES Approved Method for Lumen Depreciation Testing of LED Light Sources • IES LM-79 • IES Approved Method for the Electrical and Photometric Measurements of Solid-State Lighting Products

  5. NextLED: Luminaires Housing LED Driver Heat Sink LED LED Circuit Board Asymmetric Collimators Mask

  6. NextLED: Light Engine • LED Circuit Board • Asymmetric Collimator • Collimator Orientation Mask

  7. NextLED: Luminaires Optics

  8. NextLED: Optics • LEDs Without Optics Have No Light Control

  9. NextLED: Optics • Directional Light Control Using Asymmetric Collimators

  10. NextLED: Optics • Patented Asymmetrical Collimator • Total Internal Reflection (TIR) Optical Principle • Medium Beam 66° Vertical Aiming Angle • Designed Using Optical Simulation Software

  11. NextLED: Optics • Refraction angle i < angle r (always) i r

  12. NextLED: Optics • Refraction angle i < angle r (always) i r

  13. NextLED: Optics • Refraction angle i < angle r (always) i r

  14. NextLED: Optics • Total Internal Reflection (TIR) angle i = angle r (always) r i 100% Internal Reflection (TIR)

  15. NextLED: Optics Total Internal Reflection (TIR)

  16. NextLED Promise: Target Lumens • Better Utilization of Lumens on the Task • Fewer Initial Lumens Required • Puts the Light Where it is Needed Most • Achieve the same number of lumens on the task with: • Lower Energy Use • Less Wasted Light • Dark Sky Friendly • Low Glare • Ideal for Preventing Light Trespass

  17. Target Lumens - Garage • Premium Metal Halide Spectra-Lyte • Source Watts: 150W • Input Watts: 185W

  18. Target Lumens - Garage • NextLED Spectra-Lyte • Source Watts: 82W • Input Watts: 95W

  19. Target Lumens - Garage • Results • 49% Reduction of Input Watts • 75% Reduction in Glare Zone Lumens

  20. NextLED: Outdoor Luminaires LED Circuit Board

  21. NextLED: Circuit Board • 54 Cree XR-E White Light LEDs • 9 Strings of 6 LED in Series • 444mA Constant Current • Through each LED for 82W Board Version • Zener Diodes in Parallel to Each LED • LED End of Life Isolation. • Specially Designed Board • Tracings for Proper Heat Dissipation • Aluminum Backed PCB • eGRAF Thermal Interface Material • 24 Hour Burn In Period

  22. NextLED: Outdoor Luminaires LED

  23. NextLED: LEDs • Cree XR-E White • Colour Temperature: 5000+K • CRI: 72+ • Lumens per LED: 107-114 • Forward Voltage: 3.4Vf • All LED Products are tested in our Integrating Sphere • Cambridge, ON

  24. NextLED: Luminaires Mask

  25. NextLED: Mask Assembly Keyed Orientation

  26. NextLED: Mask Orientation • Different Beam Direction Combine to Make a Complete Luminaire Distribution • Pre Aimed Light Collimators from the Factory Type Main Beam Left Zone POLE Central/Across Zone Type Main Beam Right Zone

  27. NextLED: Mask Distributions Side Distribution • Designed & Tested to IES Recommended Standards • LM-79-08: IESNA Approved Method for the Electrical and Photometric Measurements of Solid-State Lighting Products Top Distribution Type 2 Type 3 Type 4

  28. NextLED: Luminaires LED Driver

  29. NextLED: Driver • Electronic Class II • Output 4A Constant Current Versions • 120 to 277Vac, 347Vac (Step Down Transformer) • 3kV Surge Protection • THD < 20% • High Level of Voltage Regulation • High Power Factor > 0.95 • -30°C Start Temperature • Built in Thermal Protection

  30. NextLED: Luminaires Heat Sink

  31. NextLED: Heat Transfer • LED Sources Conduct Heat • Up from the Circuit Board into the Luminaire • Must Quickly & Efficiently Transfer Heat to the Outside Environment • Heat Sink must not Compromise: • The LED • Integrity of the Luminaire

  32. NextLED: Heat Transfer • Built for the Canadian Environment • Downward Heat Sink Design • Issues with Upward Facing Heat Sinks • Dirt & Debris Build Up • Birds • Snow & Ice NextLED ConventionalLED DownwardHeat Sink Upward Heat Sink

  33. NextLED: LEDs • Important to Maintain Junction Temperature • Lifetime (L70) Based on Junction Temperature • IES Standard • 60,000 Hour Life @ 70% Lumen Maintenance • Designed & Tested to IES Recommended Standards • LM-80-08: • IESNA Approved Method For Measuring Lumen Depreciation of LED Light Sources

  34. NextLED: Outdoor LuminairesTaking LED to the Next Level

  35. NextLED Spectra-Lyte Available: June 2009

  36. Garage & Canopy NextLED Spectra-Lyte Round & Square 82W NextLED System (95W Input) Distribution: Type II, IV, V (Square & Rectangular) Lumens: 4,900 Lumens Per Watt: 52 Voltages: 120V - 277V & 347V Construction: Die-Cast Aluminum Construction Vandal Resistant Lens Wet Location Listed

  37. NextLED Ellipse & Silhouette Available: June 2009

  38. Architectural Area NextLED Area Light 82W NextLED System (95W Input) Distribution: Type II, III, IV, V Lumens: 4,100 to 4,400 Lumens Per Watt: 43 to 46 Voltages: 120V - 277V & 347V Cutoff: Full & Semi Construction: Die-Cast Aluminum Construction Glass Protective Lens Wet Location Listed

  39. NextLED GeoScapes Available: June 2009

  40. Decorative Wall NextLED GeoScapes Wallcube 82W NextLED System (95W Input) Distribution: Type II, III, IV Lumens: 4,200 Lumens Per Watt: 48 Voltages: 120V - 277V & 347V Cutoff: Full & Semi Construction: Die-Cast Aluminum Construction Glass Protective Lens Wet Location Listed

  41. NextLED FloodPak Available: June 2009

  42. Wall & Security NextLED FloodPak Wallcube 92W NextLED System (95W Input) Distribution: Type II, III, IV Lumens: Up to 4,200 Lumens Per Watt: Up to 48 Voltages: 120V - 277V & 347V Cutoff: Full & Semi Construction: Die-Cast Aluminum Construction Glass Protective Lens Wet Location Listed Not Intended for Flood Applications

  43. Next Generation NextLED • Floodlighting • PentaFlood Series • PF2 & PF3 • Available: Q4 2009 • Architectural Area Lighting • Optra Compact • Available: Q4 2009

  44. NextLED Promise • Life Cycle Cost • Low Total Cost of Ownership • LED Technology Typically Cost More • Fixture Energy Savings – 30% to 50% • Lower Maintenance Cost • Maximum Light Output, Control & Quality • Solves Issues of Intensity & Uniformity • Patented, Individually Oriented Optics • Delivers Target Lumens • Reliability • Built in State of the Art Clean Room • Lachine, Quebec • Long Life through Proper Heat Management • 24 Hour Burn In • 5 Year Warranty

  45. NextLED:Environmentally Friendly Design • Night Sky Friendly • Fewer Pollutants • No Heavy Metals Such as Mercury • No Persistent Organic Pollutants (POP) • No Volatile Organic Compounds (VOC) • RoHS Compliant Parts • Restriction of Hazardous Substances Directive • Restricts the Use of Six Hazardous Materials • Such as: Lead, Mercury, Cadmium

  46. Our LED Promise • Low Cost of Ownership • Energy Savings • High Fixture Efficacy • Quality of Light • Target Lumens • Great Cutoff • Uniformity & Consistency • Reliability • Industry Leading 5 Year Warranty • Tested to IES Standards & Testing (LM-79 & LM-80) • Long Life (L70)

  47. CANLYTE SOLID STATE LIGHTING Canlyte with Philips, Lightolier SSL, Calculite, Color Kinetics and Keene LED products is positioned to be the leading company for SSL products in the Canadian market
