  1. Introduction to RADIUS Protocol Presented By: Hiral Shah Varsha Mahalingappa

  2. RADIUS Introduction : RADIUS is an application level protocol that carries authentication, authorization and configuration information between a Network Access Server (NAS) and a Shared Authentication Server. Transport protocol - UDP UDP Port 1812 – Authentication UDP Port 1813 - Accounting Key Featuresof RADIUS : Client Server model Network Security Flexible Authentication mechanism Extensible protocol

  3. Access-RejectAccess-ChallengeAccounting-RequestAccounting-ResponseAccess-RejectAccess-ChallengeAccounting-RequestAccounting-Response Terminology : • Service • Session • Silently discard • Access-Request • Access-Accept

  4. User Radius Client Radius Server RADIUS Overview : Authentication Request Username & Password Authentication Acknowledgement

  5. Radius Client Radius Server Authentication and Authorization : Access Request Frame Access-Reject or Access-Challenge or Access-Accept

  6. Accounting • Key : Access Request, Access-Reject, an Access-Challenge or an Access-Accept • Built-in accounting schemes: • Unix accounting • Accounting data are stored in files and can be viewed using radwho and radlast commands • Detailed accounting • The detailed accounting information is stored in plain text format. The resulting files can easily be parsed using standard text processing tool. • SQL accounting • information stores it in an SQL database, processed using standard SQL queries. • Radius is extensible

  7. Packet Frame: • Details • Code • Identifier • Length • Authenticator - Value used to authenticate the reply from the RADIUS server • Attributes - The data

  8. Client Server Sequence • NAS sends encrypted user info with access request • Access accept with IP-address, network mask, allowed session time, etc • Accounting Phase starts with Accounting Request • When user logs out accounting phase ends with NAS sending an 'Accounting-request (Stop)' with some additional information. • The RADIUS Server responds with an 'Accounting-response' when the accounting information is stored.

  9. Limitations • Response Authenticator Based Shared Secret Attack • Attacker listens to requests and server responses, and pre-compute MD5 state, which is the prefix of the response authenticator: MD5(Code+ID+Length+ReqAuth+Attrib) • Perform an exhaustive search on shared secret, adding it to the above MD5 state each time. • User-Password Attribute Based Shared Secret Attack • Perform an exhaustive search on shared secret. • The attacker attempts a connection to the NAS, and intercepts the access-request. • User-Password Based Password Attack • Performs an exhaustive / dictionary attack on password, XORing it with above MD5 and sending it each time in appropriate attribute. • Possible due to no authentication on request packet.

  10. Limitations Continued… • Shared Secret Hygiene • Viewed as single client • Small key size enabling easy attack • Request Authenticator Based Attacks • Passive User-Password Compromise through Repeated Request Authenticators • Active User-Password Compromise through Repeated Request Authenticators • Attacker builds a dictionary as before. • When he predicts he can cause NAS to use a certain ReqAuth, he tries to connect it and intercepts access-request. • Replay of Server Responses through Repeated Request Authenticators • The attacker builds a dictionary with ReqAuth, ID and entire server response. • Most server responses will be access-accept.

  11. Conclusion • RADIUS is a remote authentication protocol. • RADIUS is a de-facto standard for remote authentication. • RADIUS is an extensible protocol, and can support many authentication methods (e.g. EAP). • RADIUS has several weaknesses. • Usage of stream cipher • Transaction of Access-Request not authenticated at all • The RADIUS specification should require each client use a different Shared Secret. It should also require the shared secret to be a random bit string at least 16 octets long that is generated by a PRNG. • DIAMETER brought in to replace RADIUS and fix some of the flaws • Uses TCP • Better transmission level security using IPSEC

  12. References • Radius can be downloaded from http://ftp.gnu.org/gnu/radius/ • http://www.panasia.org.sg/conf/pan/c001p028.htm • http://www.ietf.org/rfc/rfc2865.txt • http://www.ietf.org/rfc/rfc2866.txt • http://www.gnu.org/software/radius/radius.html • http://www2.rad.com/networks/2000/radius/home.htm
