  1. Lecture 19: Control Abstraction(Section 8.1-8.2) CSCI 431 Programming Languages Fall 2002 A compilation of material developed by Felix Hernandez-Campos and Michael Scott

  2. Abstraction • Programming languages support the binding of names with potentially complex program fragments that can be used through an interface • Programmers only need to know about the purpose of the fragment rather than its implementation  Abstraction • A control abstraction performs a well-defined operation • Subroutines • A data abstraction represents information • Data structures • Most data structures include some number of control abstractions

  3. Subroutines • Execute an operation on behalf of a calling program unit • Subroutines can be parameterized • The parameters in the definition of the function are known as formal parameters • The parameters passed in the subroutine call are known as actual parameters or arguments • At the time of the call, actual parameters are mapped to formal parameters • Functions are subroutines that return a value, while procedures are subroutines that do not return a value

  4. Actual Parameters Formal Parameters Subroutine Frames • Each subroutines requires a subroutine frame (a.k.a activation record) to keep track of • Arguments and return values • Local variables and temporaries • Bookkeeping information • When a subroutine returns, its frame is removed 1001: A(3) … 2001: int A(int n) { int m = n * n; return m + A(n-1); }

  5. Call StackRecursive Subroutine A A A A A A

  6. C Example • Stack pointer sp • Top of the frame stack • Frame pointer fp • Access to arguments and locals via offset of fp • They differ if temporary space is allocated in the stack

  7. C Example • Stack pointer sp • Top of the frame stack • Frame pointer fp • Access to arguments and locals via offset of fp • They differ if temporary space is allocated in the stack

  8. Stack Maintenance • Calling sequence (by caller) and prologue (by callee) are executed in the way into the subroutine: • Pass parameters • Save return address • Change program counter • Change stack pointer to allocate stack space • Save registers (including frame pointer) • Change frame pointer to new frame • Initialization code • Separation of tasks? • As much as possible in the callee (only once in the program)

  9. Stack Maintenance • Epilogue (by callee) is executed in the way out of the subroutine: • Pass return value • Execute finalization code • Deallocate stack frame (restore stack pointer) • Restore registers

  10. C Example Calling sequence by the caller: • Caller saves registers in local variables and temporaries space • 4 scalar arguments in registers • Rest of the arguments at the top of the current frame • Return address in register ra and jump to target address

  11. C Example Prologue by the callee: • Subtract the frame size from the sp • Save registers at the beginning of the new frame using sp as the base for displacement • Copy the sp into the fp

  12. C Example Callee epilogue: • Set the function return value • Copy fp to sp to deallocate any dynamically allocated space • Restore registers including ra (based on sp) • Add frame size to sp • Return (jump to ra)

  13. Pascal Example

  14. Parameter Passing • Pass-by-value • Input parameter • Pass-by-result • Output parameter • Pass-by-value-result • Input/output parameter • Pass-by-reference • Input/Output parameter, no copy • Pass-by-name • Textual substitution

  15. Closure • Closure are subroutines that maintain all their referencing environment • This mechanism is also known as deep binding • This is significant when subroutines are passed as arguments

  16. Exception Handling • An exception is an unexpected or unusual condition that arises during program execution • Raised by the program or detected by the language implementation • Example: read a value after EOF reached • Alternatives: • Invent the value (e.g. –1) • Always return the value and a status code (must be checked every time) • Pass a closure (if available) to handle errors

  17. Exception Handling • Exception move error-checking out of the normal flow of the program • No special values to be returned • No error checking after each call • Exceptions in Java • http://java.sun.com/docs/books/tutorial/essential/exceptions/
