Presentation Transcript

  1. Resource Efficiency Training Add venue Name of advisors

  2. Introductions • Name & Job / Role • Company name & brief description of operations • What is your company’s major waste? • What do you hope to get out of today? ENWORKS Resource Efficiency Programme

  3. Module 1 - Energy

  4. Learning objectives • To gain a basic understanding of: • energy consumption • monitoring • control • Identify potential savings & share best practice ENWORKS Resource Efficiency Programme

  5. Why focus on energy? • All companies use some form of energy – gas, electricity & fuel • Because most companies can reduce their energy bills by 20% • Because legislation and other Government initiatives are forcing us • Often a company’s major environmental impact • Because £12 billion of energy is wasted in the UK every year (Action Energy) ENWORKS Resource Efficiency Programme

  6. Impact of electricity • Company paying £5,000/year • Equivalent to: • 100,000 kW consumption (5p per kW) • 44 tonnes of carbon dioxide (or 12 solid tonnes of carbon) • Volume of 250 double-decker buses (CO2) • Weight of 8.1 elephants (or 587 men) • 73,997 miles in a car using petrol at 30mpg • Running Titanic for 2.6 hours on full steam ENWORKS Resource Efficiency Programme

  7. What are the benefits of reducing consumption? ENWORKS Resource Efficiency Programme

  8. Example of savings potential • Turnover £1 million • Profit (10%) £100,000 • Energy Cost (4%) £40,000 • Savings potential (20%) £8,000 • Equivalent to 8% rise in profits • Turnover increase of £80,000 ENWORKS Resource Efficiency Programme

  9. Other benefits • Improved reliability – plant/service • Better working environment • Increased output • Competitive advantage ENWORKS Resource Efficiency Programme

  10. Energy management • Make someone responsible • Establish the facts • Compare your performance • Plan & Organise • Pay less for your energy • Use less energy • Control & Monitor ENWORKS Resource Efficiency Programme

  11. Or • Consider: • Management • Monitoring • Actions • People ENWORKS Resource Efficiency Programme

  12. Management - Buy it cheaper • Energy contract negotiation • Simple tendering process • Make sure you are familiar with components of energy bills • beware of estimates • electricity maximum demand • Checking the small print (e.g. notice required) ENWORKS Resource Efficiency Programme

  13. Monitoring - Where is it being used? • 3 main areas: • Process – machines, tools, process heating, furnaces • Services – compressed air, steam, hot/cold water • Building Services – space heating, ventilation, lighting ENWORKS Resource Efficiency Programme

  14. Monitoring - Where is it being used? • Produce an energy map • Identify the five biggest energy consumers in your company • Use pareto rule 80% of energy used by 20% of process ENWORKS Resource Efficiency Programme

  15. What to monitor? • Electricity • Day Units • Night Units • Availability & Maximum Demand • Power factor • Gas • Units • Degree Days ENWORKS Resource Efficiency Programme

  16. Monitoring - Day and night units ENWORKS Resource Efficiency Programme

  17. Monitoring Maximum Demand • The peak instantaneous demand during a specific period (kW or kVA) ENWORKS Resource Efficiency Programme

  18. Monitoring Availability • The reservation of an agreed capacity with your supply company (kVA) • Should be set at approximately 10% above maximum demand ENWORKS Resource Efficiency Programme

  19. Cause of problem: Equipment failure Additional cost due to equipment failure Availability and maximum demand ENWORKS Resource Efficiency Programme

  20. Beer Monitoring Power Factor & Reactive Power Charge Froth (kVArh) Real Beer (kWh) (kVA) ENWORKS Resource Efficiency Programme

  21. Equipment Failure Power factor ENWORKS Resource Efficiency Programme

  22. Monitoring - Half-hourly Metering • Available to above 100 kW Maximum Demand market • Approximately £1,000 per month • Metering company take a reading every ½ hour • Smaller consumers can hire portable metering equipment ENWORKS Resource Efficiency Programme

  23. Data received in spreadsheet form ENWORKS Resource Efficiency Programme

  24. ENWORKS Resource Efficiency Programme

  25. ENWORKS Resource Efficiency Programme

  26. ENWORKS Resource Efficiency Programme

  27. ENWORKS Resource Efficiency Programme

  28. How does consumption vary against production? • Monitoring against time valuable • However, peaks and troughs can be misleading A B ENWORKS Resource Efficiency Programme

  29. How does consumption vary against production? (A) (B) KWh to Oven (C) Production figures ENWORKS Resource Efficiency Programme

  30. m1 m2 C Y = 22x + 789 ENWORKS Resource Efficiency Programme

  31. Base load - Fixed costs • C on the graph • Start-up losses • Operating losses such as compressed air leaks • Equipment running despite absence of any load • The use of any equipment that doesn’t add value to the product - ancillary equipment ENWORKS Resource Efficiency Programme

  32. Unit costs - Variable costs • M on the graph • Process Yield • Off-spec, scrap or non-saleable product • Product re-working • Product finishing ENWORKS Resource Efficiency Programme

  33. Monitoring - Sub-metering • Separate specific areas • Office • Production area • Data loggers • Specific pieces of plant, machinery ENWORKS Resource Efficiency Programme

  34. MonitoringCompare performance - Benchmarking ENWORKS Resource Efficiency Programme

  35. Actions No & low cost solutions • Energy walk-round • Procedures ignored? • Repairs or maintenance needed • Overheating • Lighting • Draughts • Regular maintenance/servicing ENWORKS Resource Efficiency Programme

  36. No & low cost solutionsElectric motors • Often account for 60% of electricity costs • Common problems • Oversized motors • Poor power factor/performance • Common solutions • Motor audit – numbers, size • Maintenance • Buy high-efficiency ENWORKS Resource Efficiency Programme

  37. No & low cost solutions Compressed air • 10 times more expensive than electricity • hole the size of pinprick in an air line can =£120 per year • 30-40% compressed air leakage rate is common - 10-15% should be the target • Good housekeeping • Turn off when not needed • Leakage detection • Minimise • Audit – see manual ENWORKS Resource Efficiency Programme

  38. No & low cost solutions Fuel use • Regular servicing • Monitor MPG / driver performance • Route planning • software • Conversion to cleaner fuels • Powershift ENWORKS Resource Efficiency Programme

  39. Actions - Equipment investment • High efficiency motors • Variable speed drives • Energy efficient lighting • Building insulation • Financial assistance • Enhanced capital allowances • Loans • Capital grants ENWORKS Resource Efficiency Programme

  40. People - Myths and legends • “Leaving the lights on is more economical than switching them off” • “Leaving equipment such as compressors, machine tools and other motors on is more economical than switching them on and off all the time” • “Office equipment such as computers use hardly any electricity” ENWORKS Resource Efficiency Programme

  41. People - Get them involved • Measuring • Monitoring • Awareness raising • Maintenance • Planning ENWORKS Resource Efficiency Programme

  42. Case Study - Wild Manufacturing • Presswork company – 180 employees • EMS driven – energy was key cost/environmental impact • Formed committee • Measured • Set targets • 10% utilities reduction in first year • Awareness raising campaigns • “switch off, turn off, save it” ENWORKS Resource Efficiency Programme

  43. Case Study - Wild Manufacturing • What they did • Focused on ‘common sense’ housekeeping issues • Check & repair procedures for compressors • Fitted light sensors • Sealed gaps around windows & doors • Kept traffic doors shut as much as possible • Publicised consumption data to staff ENWORKS Resource Efficiency Programme

  44. Case Study - Wild Manufacturing • What they achieved (first year) • Reduced electricity costs by 13% • Reduced gas costs by 7% • Vastly improved staff awareness • SAVINGS IN £££££££ ENWORKS Resource Efficiency Programme

  45. Energy support • Action Energy • Helpline – 0800 58 57 94 • Publications • Interest Free Loans • On-site surveys • Must have consumption £50,000+ • www.actionenergy.org.uk ENWORKS Resource Efficiency Programme

  46. Workshop 1 Energy Auditing

  47. Workshop 2 Understanding Your Energy Bills

  48. Workshop 3 Energy Efficiency Action Plan

  49. Module 2 - Packaging

  50. Why focus on packaging? • Legislation • It is expensive • As a raw material • To dispose of • Offers a lot of opportunity ENWORKS Resource Efficiency Programme
