  1. FTTH Network Configuration FOR Drop Line Infrastructure Solution 2012.07

  2. 1 2 3 3 4 4 5 Contents FTTx Network Configuration FTTH Network Structure Drop Line Infrastructure Solutions Proposal Product Comparison VISSEM-AFL

  3. FTTx Network Configuration

  4. FTTH Network Structure Feeder 96C cable / 12 fiber use Distribution cable 12C / 3 fiber use 1C cable for 16 subscribers C/O FDF RACK OLT Feeder Cable 96C cable (12 dead fibers) 96C cable OTB Connectorized Closure 1C cable 12C cable 2C cable 1C cable Drop cable Distribution Cable 1xn Splitter inside 12C cable (3 dead fiber) Outlet

  5. FTTH Network Structure Drop Line Infrastructure Solutions 1x4 Fan-out Splitter SPLITTER(1*N) Loose Cable for Heat Shrinkable Sleeve TRAY CHIP TRAY BOTTOM Ribbon Cable for Heat Shrinkable Sleeve FIBER STOPPER HINGE

  6. FTTH Network Structure Drop Line Infrastructure Solutions

  7. Drop Line Infrastructure Solution FTTH Network Structure

  8. Proposal Product Drop Line Infrastructure Structure FTTx Closure for 8port FTTx Closure for 16port FTTx Closure for 12port Outdoor Outlet for 2port Outdoor OTB for 12port FTTx Closure for 24port

  9. Comparison VISSEM-AFL

  10. Comparison VISSEM-AFL

  11. Installation Thailand Dominican Republic

  12. Thank you very much VISSEM ELECTRONICS Co., Ltd. Web: http://www.vissem.com Email: djkang@vissem.com 235-2 Deokpyeong-ri, Majang-myeon, Icheon-si Gyeonggi-do, Korea Tel : 82-31-288-3481, Fax : 82-31-283-7844
