  1. CS335 Networking &Network Administration Wednesday, April 14, 2010

  2. Long Distance WANS • Digital Telephony • Prior to networks being important • Early telephone used analog signals which degrade over long distance needing amplifiers and introduce noise • Digital audio avoids noise by encoding original audio into digital form

  3. Audio digitization • Closest integer to signal = sampling = continuous stream of numbers

  4. Audio to digital converter • Sample the signal • Compute a number closest to level of signal • Continuous stream of numbers • Human voice has frequencies up to 4000 Hz • If sampled at twice the highest frequencies the original signal can be reconstructed from the samples • Digitized voice sampled 8000 times/sec (once every 125 microseconds)

  5. Pulse Code Modulation • World-wide standard for digital telephony • Need to choose a range of values • More values = more accurate but also more data • Uses integers between 0 and 255 for voice • PCM is the sampling scheme • Digitized data sent over long distance and converted back to audio at destination

  6. Synchronous communication • Telephone industry has complex digital communications systems – long distance • Digitized voice is synchronous or clocked • Data is moved at precise rates • Voice apps can’t tolerate delay or noise in the same way as data • Continuous transmission synchronized to have constant data rate

  7. Digital phone circuits • Point to point digital circuits - data uses different standards than voice • DSU/CSU’s (Data Service Unit /Channel Service Unit) at each end of phone circuit

  8. The demarc • Network Interface Unit (NIU) is the last piece of telephone company equipment • CSU portion handles line termination and diagnostics to test if line is connected • DSU translates data between the digital format of the phone circuit and the format needed by computer network

  9. Data rates • Fractional t1’s can also be leased • Phone company uses Time Division Multiplexing to subdivide T1 into 24/64 Kbps fractions =1536

  10. Intermediate capacity • Need more than a T1 but less than a T3 • Inverse multiplexor allows multiple T1’s to be combined

  11. Highest Capacity Circuits • Synchronous Transport Signal (STS) • Optical Carrier (OC)

  12. SONET (Synchronous Optical Network) • In addition to STS and OC standards phone companies have defined SONET • Specifies details such as how data is framed • How lower capacity circuits are multiplexed into a high capacity circuit • How synchronous clock info is sent along with the data

  13. SONET Frame • SONET Encoding • Size of a SONET frame depends on bit rate • STS-3 circuit each frame holds 2430 octets

  14. IDSN • Digitized voice and data over conventional local loop wiring (twisted pair copper same as the analog phone system – POTS: plain old telephone service) • Two B channels operating at 64Kbps • B channels can be combined into a single channel to get 128 KbPS • One D channel operating at 16 Kbps as a control channel • When it was begun 64 Kbps was much faster than dialup modem, now it is an expensive alternative with little throughput

  15. ADSL • Multiple flavors so we refer to it as xDSL • ADSL, SDSL, HDSL • ADSL –Asymmetric digital subscriber line • Higher bit rate downstream than upstream • Most users request downstream data – browsing the internet • ADSL can operate at 6.144 Mbps downstream and 576 upstream • Doesn’t require changes in local loop wiring • Can run simultaneously over the same wires as phone service

  16. ADSL

  17. ADSL • Adaptive to conditions on the local line in terms of choosing frequencies based on the interference that the modems find on the line when they power up • Probe many frequencies on the line between modems and select frequencies and modulation techniques that give optimal results • 286 separate frequencies or subchannels • 255 downstream and 31 upstream with 2 channels for control information • Choose frequencies above 4 Khz to not interfere with voice

  18. Cable Modems • Higher speed than telephone wiring • Less susceptible to EM interference • Already has infrastructure in place • Multiplexed onto the cable with other TV signal • Can deliver up to 36 Mbps, but is a shared capacity can be as little as 1/n where n=subscribers • CATV was never designed for upstream communication • Early attempts used a dual path approach – upstream data handled by a dialup modem • New approach is HFC )hybrid fiber coax) but it requires major upgrade of existing cable infrastructure

  19. Satellite and Wireless • Wireless is usually line-of-site • Receiving antenna needs to be in line with transmitter • Satellite also uses another path for upstream traffic, making it more complex
