  1. FFA Dr Aaron Ng

  2. FFA Principles • Fluorescence • Stimulated by light of shorter wavelength • Emission of light of longer wavelength • Flurescein • Excitation peak 490nm • Emit light of about 530nm

  3. FFA Principles: Filters

  4. 5 Phases of Angiogram 1. Choroidal (Pre-arterial): 9-15 sec

  5. 5 Phases of Angiogram 2. Arterial phase: 1 sec after choroidal phase

  6. 5 Phases of Angiogram 3. Arterio-venous (capillary) phase: early venous laminar flow

  7. 5 Phases of Angiogram 4a. Venous phase: Laminar venous flow

  8. 5 Phases of Angiogram 4b. Venous phase – complete filling • Max perifoveal capillary filling – 20-25 sec • First pass of fluorescein circulation – 30 sec

  9. 5 Phases of Angiogram 5. Late (recirculation) phase • Absent after 10 min

  10. Timing of FFA phases • Arm to retina (ONH): 7-12s • Posterior ciliary artery 9s • Choroidal flush, cilio-retinal artery 10s • Retinal arterial phase 10-12s • Capillary transition phase 13s • Early venous/lamellar/a-v phase 14-15s • Venous phase 16-17s • Late venous phase 18-20s • Late phase 5-15 min

  11. Foveal dark appearance • Foveal avascular zone • High density of xanthophyll at the fovea • Foveal RPE larger and rich in melanin and lipofuscin

  12. Causes of hyperfluorescence • Autofluorescence • Pseudofluorescence • RPE window defect • Dye pooling • Dye leaking • Tissue staining-disc, drusen, chorioretinal scar

  13. Autofluorescence Optic disc drusen

  14. Autofluorescence Lipofuscin

  15. Autofluorescence Angioid streaks

  16. RPE window defect Atrophic ARMD

  17. Dye pooling Subretinal - CSCR

  18. Dye pooling Sub-RPE - PED

  19. Dye leaking Proliferative DR Cystoid Macula Oedema

  20. Late staining

  21. Causes for hypofluorescence • Masking of retinal fluorescence • Pre-retinal lesions block all fluorescence • Deeper retinal lesions e.g. intraretinal haemorrhages and hard exudates block only capillary fluorescence

  22. Pre-retinal lesions Blockage to all fluorescence

  23. Intraretinal lesions Hard exudates Intraretinal haemorrhages

  24. Causes for hypofluorescence • Masking of background choroidal fluorescence • Conditions that block retinal fluorescence • Conditions that block only choroidal • Sub-retinal or subRPE lesions • Increased RPE density • Choroidallesions • Filling defects • Vascular occlusions • Loss of vascular bed (myopic degen, choroidaeraemia)

  25. Increased RPE density CHRPE

  26. Choroidal naevus

  27. Filling defects Capillary drop – out in DR (vascular occlusion) Choroidaeraemia (loss of vascular bed)

  28. CNVM subtypes

  29. Classic

  30. Atypical classic

  31. Occult

  32. Minimally classic

  33. Indocyanine Green Angiography • Advantages over FFA • Study of choroidal vasculature otherwise prevented in FFA due to RPE blockage • Near-infrared light utilised penetrates melanin, xanthophylls, exudates and subretinal blood • Infrared is scattered less cf visible light, thus suitable in eyes with media opacities • 98% ICG molecules bound to protein, thus remaining in the blood vessels

  34. ICGA Principles • Infrared excitation (805nm) • Infrared emission (835nm)

  35. Phases of ICGA • Early phase (first 60 sec post injection) – choroidal arteries • Early mid phase (1-3 min) – choroidal veins and retinal vessels • Late mid phase (3-15 min) – choroidal vessels facing but retinal vessels are still visible • Late phase (14-45 min) – hypofluorescent choroidal vessels and gradual fading of diffuse hyperfluorescence

  36. Causes for hyperfluorescence • “Window defect” • Retinal or choroidal vessel leakage • Abnormal retinal or choroidal vessels

  37. Causes for hypofluorescence • Blockage • Pigment, blood, fibrosis, infiltrate, exudate, serous fluid • PED are predominantly hypofluorescent on ICGA as cf FFA • Filling defect • Vascular occlusion • Loss of choroidal or retinal circulation

  38. Clinical indications • PCV • CSCR • Posterior uveitis (extent of disease involvement) • Breaks in Bruch’s (lacquer cracks, angiod streaks) • Contraindication for FFA

  39. CSCR FFA ICGA

  40. CSCR

  41. PCV
