  1. Sybase PowerBuilder Applications Modernization

  2. About the Company Founded in 2002 Unites high-level information technology and organization architecture professionals. Areas of specialization: Legacy modernization from Oracle Rally to Java (Enterprise Edition) environment Legacy modernization from Sybase PowerBuilder to JEE or .NET environments Borland Delphi modernizationto JEE environment Oracle PL/SQL to Java modernization Legacy environments Architecture, Foundations, Database and Application development in Java and .NET environments 29 September 2014 2

  3. Relevant Projects A large U. S. power corporation A large U.S. government agency A large Israel government agency 29 September 2014 3

  4. Partners 29 September 2014 4

  5. Managing the future of your legacy applications??? Modernization 29 September 2014 5

  6. Rewriting from scratch Very expensive and cost-ineffective Long “time-to-production” cycle Wasting of resources for maintaining of the existing application during the long development of the new one. Risky in terms of budget, time and functionality "Legacy code" often differs from its suggested alternative by actually working and scaling. Bjarne Stroustrup, the father of C++ 29 September 2014 6

  7. Conversion or Face Lifting? 29 September 2014 7

  8. Automated Modernization The existing application logic is automatically preserved Low risks in terms of the project scope and schedule Easier deployment and shorter end-user learning curve You always can go back Maximum use of the existing manpower 29 September 2014 8

  9. PowerBuilder Modernization Process: Architecture Change 29 September 2014 9

  10. Legacy Thick Client Architecture 29 September 2014 10

  11. Modern Thin Client Architecture Microsoft .NET 4.0 29 September 2014 11

  12. Modern Thin Client Architecture Java Enterprise Edition Any Servlet/JSP Container Database Server JSP Business Logic, Data Access 29 September 2014 12

  13. PowerBuilder Modernization Process: Steps 29 September 2014 13

  14. 1. Learning the Application and the Environment Objective Understanding the application and its environment. Process Learning the application. Obtaining the source code. Identifying exceptions. Mapping external resources (images, help files, INI files, XML and text files, registry keys etc.) and interfaces (DLLs, applications etc.). Understanding the target environment. Schedule About three weeks for a medium-size application Deliverables Draft version of the System-Wide Standard (S.W.S.) for the application. Application sizing and modernization project estimations Target platform and “modernization feasibility” recommendations 29 September 2014 14

  15. 2. Integrity Check Objective Preparation of the original application for the conversion. Process System integrity checks. Building walkthrough scenarios (by the client) - scenarios “how an end-user works with the application”. Identifying failures. Application fixing (if required), or documenting for after-conversion fixes. Schedule About a month, depending on the application and the client availability. Deliverables Cleaned application Bug report + fixes plan Walkthrough scenarios (by the client), approved by MainTrend 29 September 2014 15

  16. 3. PowerBuilder Objects Export Objective Extracting of all the PowerBuilder objects from the application libraries to text files. Process Libraries consolidation. Duplicates identifying. Export of all the PowerBuilder objects to text files. Schedule Less than a week. Deliverables Plain text source files for all the PowerBuilder objects (correct versions). 29 September 2014 16

  17. 4. Reverse Engineering Objective Preparation of the intermediate files, required for the code generation step Process Parsing of the code of all the PowerBuilder objects and building the abstract syntax tree and the dictionary for the application. Managing relationships and inheritances. Deleting unnecessary objects. Schedule From a week to two weeks. Deliverables Abstract syntax tree for the application (xml files) Application dictionary (xml file) The second version of the S.W.S. document 29 September 2014 17

  18. 5. Code generation Objective Producing of the code according to the target environment. Process Automatic generation of the destination code. First fixes according to the S.W.S. Manual completion for exceptional objects (e.g. OLE). Schedule Defined in the S.W.S. depending on the size and complexity of the application. Deliverables Application code migrated to the target environment. A third version of the document S.W.S. 29 September 2014 18

  19. 6. Unit Test (UT) Objective UT environment building. Performing of the unit tests. Process Preparation of the UT environment at the customer premises (servers, required software, test database etc.). Linking the unit test application to the test database. Installation of the UT application in the UT environment. Performing of the unit tests. Schedule Defined in the S.W.S. depending on the size and complexity of the application, and on the availability of the customer. Deliverables UT environment installed at the customer premises UT report 29 September 2014 19

  20. 7. Database Migration Objective In case the database platform is changed – to have the production database migrated to the new platform. Process Database metadata and database data migration. Building reports for the application changes required in response of the database changes Preparation of production servers and related software. Tests and the database fine tuning. Schedule Defined in the S.W.S. depending on the size and complexity of the application, and on the availability of the customer. Deliverables Complete and working database. Report of the performed database changes. 29 September 2014 20

  21. 8. Integration Objective Building of interfaces and links to external systems. Integration of all the application parts. Process Changes to match the new database structure. Adjustments to the operating system. Building interfaces to external systems. Building and linking of external objects. Making the integration of all the parts of the system Schedule Defined in the S.W.S. depending on the size and complexity of the application, and on the availability of the customer. Deliverables Customized application connected to external objects. 29 September 2014 21

  22. 9. Integration Test Objective Integration tests including end-users involvement. Process Performed as a “Test and fix” cycle. Performed in cooperation with the customer’s end-users according to the walkthrough scenarios prepared in the second step. Schedule Defined in the S.W.S. depending on the size and complexity of the application, and on the availability of the customer. Deliverables Verified customized application connected to external objects. 29 September 2014 22

  23. 10. Web-environment adaptation Objective Making adjustments to the thin-client browser-based environment. Process Adjustment of the web forms according to S.W.S. Adjustment to the size limits to get the desired response times. Fixes and adjustments which are found needed during the process. Schedule Defined in the S.W.S. depending on the size and complexity of the application, about a month for a medium-size application. Deliverables The application ready for the user acceptance test. 29 September 2014 23

  24. 11. Implementation to Production Objective Acceptance and moving to production. Process User acceptance tests. Finishing of all the needed installations in the production environment. Moving to production. Training for the end-users. Training for the client’s developers. Schedule Defined in the S.W.S. depending on the size and complexity of the application, and on the availability of the customer. Deliverables The modernized application working in the production environment. 29 September 2014 24

  25. Legacy Software Migration Case Study

  26. The customer: DLF - Family Department of the Commonwealth of Puerto Rico Government (a large U.S. government agency). More then 3000 users in more than 100 local offices. The legacy application: supported almost all DLF’s activities. More than 150,000lines of code. More than 30 man-years of investment. Case Study (1) 29 September 2014 26

  27. A joint team (Hewlett Packard of Puerto Rico as an integrator, MainTrend as a conversion subcontractor). The core of the migration was the automatic conversion The entire migration took less than 7 months from the project start to the new converted application working in production Costs about one third of the estimated budget of a full rewrite. The resulting application is now maintained by the department’s own developers. Case Study (2) 29 September 2014 27

  28. No loss in business knowledge. A significant reduction in client maintenance (browser-based solution). Low assimilation efforts. Much easier to find development personnel. The more flexible programming environment reduces the “maintenance cost per change”. The new technology allows application enhancements to increase business productivity. Paul Segarra, the DLF’s project manager: “The system is working great and everyone is highly impressed on how quickly and accurately the conversion went!” Case Study (3) 29 September 2014 28

  29. Thank You! For additional information: Site: http://maintrend.net/ Email: info@maintrend.net
