  1. Isomerism SCH4U Spring 2012

  2. Isomerism • Isomerism occurs when there are two or more compounds (called isomers) with the same molecular formula but different arrangements of their atoms • Isomers have different physical and chemical properties • There are two main classes of isomerism: a) structural isomerism b) stereoisomerism

  3. Structural isomerism • Structural isomers are molecules with the same molecular formula but with different structural arrangements of the atoms • There are three types of structural isomers: a) Chain isomers b) Positional isomers c) Functional groupisomers

  4. Chain isomers • Isomers have different arrangements of the carbon chain • E.g. C4H10

  5. Chain isomers • As the number of carbon atoms increases , the number of possible isomers increases • How many isomers would C5H12 have? What are they?

  6. Positional Isomers • Isomers have the same carbon skeleton but the functional group is in different positions in the molecule • E.g. C6H4Cl2

  7. Positional isomers • What would be a positional isomer of butan-1-ol?

  8. Functional group isomers • Isomers have the same molecular formula but different functional groups • E.g. C3H8O CH3CH2CH2OH, propan-1-ol H3COCH2CH3 , methoxyethane

  9. Functional group isomers • What would be a functional group isomer of cyclohexane?

  10. Stereoisomerism • Stereoisomers have identical molecular formula and the atoms are linked together in the same order but have different relative positions in space • There are two types of stereoisomers: a) Geometric (or cis-trans ) isomers b) Optical isomers

  11. Geometric isomers • Geometric or cis-trans isomers exist because the (pie) π bond of the C=C bond prevents free rotation • Cis – same side • Trans – opposite side of the double bond • E.g. 1,2-dichloroethene

  12. Optical isomers • This type of isomerism occurs when a molecule has one or more asymmetric carbon atoms i.e. a carbon atom linked to four different atoms or groups • The optical isomers have a chiral centre and are mirror images of each other • E.g. butan-2-ol

  13. Optical isomers • Identify all chiral centre(s), if any:
