1. Tornado Codes, with Applicationsto Reliable Multicast Michael Mitzenmacher

2. Based On • Practical Loss-Resilient Codes • Michael Luby, Michael Mitzenmacher, Amin Shokrollahi, Dan Spielman, Volker Stemann • STOC ‘97 • Analysis of Random Processes Using And-Or Tree Evaluation • Michael Luby, Michael Mitzenmacher, Amin Shokrollahi • SODA ‘98 • A Digital Fountain Solution to Reliable Multicast of Bulk Data • John Byers, Michael Luby, Michael Mitzenmacher, Ashu Rege • SIGCOMM ‘

3. Application:Software Distribution Problem • Millions of users want to download a new version of a software package. • 32 megabyte file, at 56 Kbits/second. • Download takes around 75 minutes at full speed.

4. Point-to-Point Solution Features • Good • Users can initiate the download at their discretion. • Users can continue download seamlessly after temporary interruption. • Moderate packet loss is not a problem. • Bad • High server load. • High network load. • Doesn’t scale well (without more resources).

5. Broadcast Solution Features • Bad • Users cannot initiate the download at their discretion. • Users cannot continue download seamlessly after temporary interruption. • Packet loss is a problem. • Good • Low server load. • Low network load. • Does scale well.

6. A Coding Solution: Assumptions • We can take a file of n packets, and encode it into cn encoded packets. • From any set of n encoded packets, the original message can be decoded.

7. 5 hours 4 hours 3 hours 2 hours 1 hour 0 hours Coding Solution Encoding Copy 2 Encoding File Encoding Copy 1 User 1 Reception User 2 Reception Transmission

8. Coding Solution Features • Users can initiate the download at their discretion. • Users can continue download seamlessly after temporary interruption. • Moderate packet loss is not a problem. • Low server load - simple protocol. • Does scale well. • Low network load.

9. So, Why Aren’t We Using This... • Encoding and decoding are slow for large files -- especially decoding. • So we need fast codes to use a coding scheme. • We may have to give something up for fast codes...

10. n Erasure Codes n Message Encoding Algorithm cn Encoding Transmission Received Decoding Algorithm n Message

11. Performance Measures • Time Overhead • The time to encode and decode expressed as a multiple of the encoding length. • Reception efficiency • Ratio of packets in message to packets needed to decode. Optimal is 1.

12. Reception Efficiency • Optimal • Can decode from any n words of encoding. • Reception efficiency is 1. • Relaxation • Decode from any (1+e) n words of encoding • Reception efficiency is 1/(1+e).

13. Parameters of the Code n Message cn Encoding (1+e)n Reception efficiency is 1/(1+e)

14. Previous Work • Reception efficiency is1. • Standard Reed-Solomon • Time overhead is number of redundant packets. • Uses finite field operations. • Fast Fourier-based • Time overhead is ln2 nfield operations. • Reception efficiency is1/(1+e). • Random mixed-length linear equations • Time overhead is ln(1/e)/e.

15. Tornado Code Performance • Reception efficiency is1/(1+e). • Time overhead is ln(1/e). • Simple, fast, and practical.

16. is the shrink factor = message = redundancy Encoding Structure Bipartite graph Bipartite graph Standard loss-resilient code Message n to encoding cn, c=2

17. Encoding Process

18. Decoding Structure Bipartite graph Bipartite graph Standard loss-resilient code = received directly = missing

19. Transmission Model • Which packets received • Can depend on when sent, route taken. • Does not depend on payload. • Algorithm • Compute entire encoding. • Place encoding into packets in random order. • Implication • Random portion of encoding is received. • Same amount from each level.

20. Decoding Process: Direct Recovery

21. Decoding Process: Substitution Recovery indicates right node has one edge

22. Regular Graphs Random Permutation of the Edges Degree 6 Degree 3

23. Decoding Process Analysis Induced Graph = Recovered = Missing/not yet recovered

24. 3-6 Regular Graph Analysis Left Right Left

25. 3-6 Regular Graph Equation Want:y < xfor all0 < x < a Works fora < 0.43

26. Regular Graph Performance Reception efficiency Time overhead (Left degree)

27. Why regular graphs are bad Right degree 2d implies Pr[right degree =1] = d Left node has on average neighbors of degree one.

28. Degree 1 Degree 4 Random Permutation of the Edges Degree 5 Degree 2 Degree 6 Degree 10 Degree 3 Degree 4 Irregular Graphs

29. Degree Sequence Functions • Left Side • fraction of edges of degree ion the left in the originalgraph. • Right Side • fraction of edges of degree ion the right in the original graph.

30. Irregular Graph Analysis Left Right Left

31. Irregular Graph Condition Want:y < xfor all0 < x < a

32. Good Left Degree Sequence:Truncated Heavy Tail D= 9, N = Fraction of nodes of degree i is Average node degree is

33. Good Right Degree Sequence:Poisson Average node degree is

34. Good Degree Sequence Functions Want:y < xfor all0 < x < a Works for

35. Tornado Code Performance Reception Efficiency Time overhead (Average left degree)

36. Why irregular graphs are good Average right degree 2ln(D) implies Pr[right degree =1] ~1/(D+1) D+1 Left node of max degree has on average one neighbor of degree one.

37. Application:Software Distribution Problem • Millions of users want to download a new version of a software package. • 32 megabyte file, at 56 Kbits/second. • Download takes around 75 minutes at full speed.

38. 5 hours 4 hours 3 hours 2 hours 1 hour 0 hours Cyclic Tornado Coding Solution Encoding Copy 2 Encoding File Encoding Copy 1 User 1 Reception User 2 Reception Transmission

39. Cylcic Tornado Coding Solution Features • Users can initiate the download at their discretion. • Users can continue download seamlessly after temporary interruption. • Moderate packet loss is not a problem. • Reception efficiency is near optimal. • Low server load - simple protocol. • Does scale well. • Low network load.

40. Why Now and Not Before? Encoding time (seconds), 1K packets Decoding time (seconds), 1K packets Size Reed-Solomon Tornado Size Reed-Solomon Tornado 4.6 0.06 2.06 0.06 250 K 250 K 500 K 19 0.12 500 K 8.4 0.09 93 40.5 1 MB 0.26 1 MB 0.14 2 MB 442 0.53 2 MB 199 0.19 4 MB 1717 1.06 4 MB 800 0.40 8 MB 6994 2.13 8 MB 3166 0.87 16 MB 30802 4.33 16 MB 13829 1.75 Model: half redundant packets, half message packets

41. Reception Efficiency 10,000 runs Extra packets needed Avg: 5.5% Max: 8.5%

42. Previous Work • Local correction, hierarchical methods • Try to get lost packet from nearby neighbor in multicast tree. • Scalability? Satellite? • Erasure codes, interleaving • Break message into blocks, encode over blocks. • Interleave blocks to protect against bursty loss. • We have better performance, scalability. • Layering • Offer channels at different rates. • We use simple layering in prototype.

43. Cyclic Interleaving Encoding Copy 2 Interleaved Encoded Blocks Encoded Blocks Blocks Encoding File Encoding Copy 1 Transmission

44. k B blocks Cyclic Interleaving: Problems • The Coupon Collector’s Problem • Wait for packets for the last blocks. • Need many blocks for fast decoding. • Tornado twice as fast even for blocks of 20 packets.

45. Scalability over Receivers

46. Scalability over File Size

47. Contributions • Tornado codes • Analysis tools • Simple, effective multicast protocol • Being implemented by Digital Fountain, Inc. • Error-correcting codes • STOC ‘98, ISIT ‘98 • Luby, Mitzenmacher, Shokrollahi, Spielman • Recent improvements • Reudiger, Shokrollahi, Urbanke
