Performance-Optimal Clustering with Retiming for Sequential Circuits

1. Performance-Optimal Clustering with Retiming for Sequential Circuits Tzu-Chieh Tien and Youn-Long Lin Department of Computer Science National Tsing Hua University Hsin-Chu, Taiwan, R.O.C. NTHU-CS

2. Outline • Introduction • Previous Work • Proposed Approach • Experimental Results • Conclusion and Future Research NTHU-CS

3. Retiming 3 5 2 critical path delay = 8 1 retiming 3 5 2 critical path delay = 7 1 NTHU-CS

4. 3 5 2 1 Performance-Driven Clustering • Minimize clock period under cluster-size constraint NTHU-CS

5. 3 5 2 1 Combining Clustering and Retiming clustering w/o retiming consideration clustering w/ retiming consideration 3 5 2 3 5 2 1 1 inter-cluster delay = 2 critical path delay = 8 critical path delay = 7 NTHU-CS

6. Problem Definition • Given • a sequential circuit G, • a target clock period c, and • an area-bound number M • Find • a clustered/retimed/node-replicated circuit Gr • clock period less than or equal to c • each cluster is of size M or less NTHU-CS

7. Previous Work • P. Pan, A. K. Karandikar, and C. L. Liu, “Optimal Clock Period Clustering for Sequential Circuits with Retiming,” IEEE T-CAD, June 1998. • Optimal under the unit gate delay model • Near-optimal for the general gate delay model • J. Cong, H. Li, and C. Wu, “Simultaneous Circuit Partitioning/Clustering with Retiming for Performance Optimization,” DAC’99. • 100X more efficient but still near-optimal NTHU-CS

8. This Work • Optimal for the general gate delay model • More (2X) efficient than Pan’s approach NTHU-CS

9. Pan’s Approach • Label each node v an l-value, l(v) • Find a clustered-retimed circuit such that all PO’s l-values less than or equal to c • Retiming solution • Resulting clock period less than c + max. gate delay NTHU-CS

10. Pan’s l-value of a Node • Total w1edge weight of the longest path from PI’s to the node • w1weightof edge e from u to v: w1(e) = - c * w(e) + d(v) • w(e):number of FF’s along e target c = 6 2 5 3 w1(e) 2 - 1 3 0 l(v) 0 2 1 4 4 < 6 NTHU-CS

11. Pan’s l-value Labeling • Traveling the whole circuit for updating l-values until no more updating in any node • Time complexity NTHU-CS

12. Our Approach • Modified l-value definition • Optimal for general delay model • Based on W.-J. Chen, “A Study on the Relationship Between Retiming and Loop Folding,” Master thesis, National Tsing-Hua Univ., Taiwan, R.O.C., Aug. 1994. • FIFO to aid circuit traveling during labeling • Improve run time • Time complexity NTHU-CS

13. Modified l-value Labeling • If an FF’s position is occupied by a gate v, • detected by target c = 6 2 5 3 l(v) 0 2 1 5 8 8 > 6 NTHU-CS

14. 3 5 2 2 1 3 1 5 1 3 3 3 5 5 2 3 1 3 5 Example (target c = 7, inter-cluster delay = 2) 7 3 9 12 5 l(v) 3 1 3 10 12 1 l(v) 3 1 12 7 NTHU-CS

15. 3 5 2 1 3 5 5 2 Example (Cont’) (target c = 7, inter-cluster delay = 2) 3 5 2 1 clustering connecting & retiming merging 3 3 5 3 5 2 1 1 NTHU-CS

16. 3 5 2 2 1 3 1 5 1 3 3 3 5 5 2 3 1 3 5 Example (target c = 6, inter-cluster delay = 2) 7 3 9 11 5 l(v) 3 1 3 10 11 1 l(v) 3 1 11 7 NTHU-CS

17. 3 5 2 2 1 3 1 5 1 3 3 3 5 3 2 1 3 5 Example of Pan’s Approach (target c = 6, inter-cluster delay = 2) 6 3 6 8 5 l(v) 3 1 3 10 1 l(v) 3 1 8 6 NTHU-CS

18. 3 5 2 1 Example of Pan’s (Cont’) (target c = 6, inter-cluster delay = 2) 3 5 2 1 3 clustering connecting & retiming merging 3 3 5 3 5 2 1 1 2 NTHU-CS

19. Experimental Results • 26 ISCAS-89 Benchmark Circuits • Pan’s approach produces suboptimal results for 11 circuits • Our approach produces optimal result for every circuit • Our CPU time consumption is 50% of Pan’s NTHU-CS

20. Conclusion and Future Research • First exact algorithm for performance-optimal clustering with retiming under general gate delay model • Twice as fast as Pan’s near-optimal heuristic • Future research is to improve run time efficiency NTHU-CS

21. NTHU-CS

22. NTHU-CS

23. NTHU-CS

24. Experimental Results NTHU-CS

25. Experimental Results (Cont’) NTHU-CS
