  1. Atmospheric mercury monitoring in relation to model testing and validation John Munthe and Ingvar Wängberg IVL Swedish Environmental Research Institute

  2. Presentation topics • Mercury species in air • Mercury in wet deposition • Mercury deposition in forested areas/throughfall, litterfall • Monitoring needs for model testing and evaluation

  3. Mercury species in air • GEM (Gaseous Elemental Mercury), Hg0, elemental mercury vapour. Normally >98% of total mercury in air, long residence time, global distribution. Sampled on gold traps with filter to remove TPM and denuder to remove RGM • RGM (Reactive Gaseous Mercury), operationally defined but thought to be mainly HgCl2. Sampled on KCl coated denuders. • TPM, (Total Particulate Mercury),HgP,particulate mercury. Hg(II) or Hg0, associated with particles. Sampled on filters, usually quartz. • TGM (Total Gaseous Mercury). Sum of GEM and RGM. Sampled on gold traps without filter and denuder.

  4. Mercury species in air - availability of monitoring data -TGM • TGM at a few sites in Northern Europe with varying time resolution (from hourly to weekly samples) • Manual and automated methods are used • Variability relatively small, hemispherical background of 1.5 ng/m3, peaks of 2-4 ng/m3 from European emission • Need high time resolution for model validation • New EU directive will require more extensive monitoring from 2006/7 • Question of priorities.

  5. Mercury species in air - availability of monitoring data - RGM and TPM • RGM. No routine measurements in Europe. Campaigns as part of research projects. • TPM. Monitoring at few sites in northern Europe • High variability from <2 to 100 pg/m3. • Direct emissions (RGM) from (some) combustion sources, formation in atmosphere (OH, halogens)= large local and temporal variability • Manual and automated methods available but relatively work intensive for RGM, easier for TPM • Voluntary in EU directive, should be at "super stations"

  6. TGM from Mace Head Ralf Ebinghaus, GKSS

  7. TGM from MOE 1997-1998 (5 campaigns)

  8. 40 35 30 25 20 TGM ng m-3 15 10 5 0 13/12 16/12 19/12 22/12 25/12 28/12 31/12 3/1 TGM 600 m from point source (Chlor alkali plant), annual emissions 50 kg/yr

  9. RGM from MOE 1997-1998 (5 campaigns)

  10. TPM from MOE 1997-1998 (5 campaigns)

  11. RGM Automated (NEU) and manual (RÖR) Ralf Ebinghaus, GKSS, J. Sommar, Göteborgs Universitet

  12. TPM, november 1999

  13. Mercury species in air, measurements for modelling purposes • TGM: Methods well developed and available. Need high time resolution to be able to identify small peaks above background. • RGM: Methods relatively complicated, could be simplified? Need data with temporal and spatial resolution, better emission data, better understanding of chemistry • TPM: Methods available. Need data with temporal and spatial resolution, higher time resolution.

  14. MERCYMS Field Measurements at Cabo de Creus, Spain 42o19’ N, 3o 19’ W • FP 5 project, coordinated by N Pirrone, CNR IIA • Measurements at 5 coastal stations, 4 campaigns in 2004 • Several ship cruises • Measurements in Spain conducted by IVL and Göteborg University in cooperation with Ministry of Environment and MCV

  15. Autumn 2003 Winter 2004 20.0 20.0 -3 15.0 -3 15.0 10.0 10.0 TPM pg m TPM pg m 5.0 5.0 0.0 0.0 21 22 23 24 25 26 27 28 29 30 31 1 19 20 21 22 23 24 25 26 27 28 29 30 10 10 10 10 10 10 10 10 10 10 10 11 01 01 01 01 01 01 01 01 01 01 01 01 2003 2004 Summer 2004 Spring 2004 20.0 35.0 30.0 15.0 -3 25.0 20.0 10.0 TPM pg m 15.0 10.0 5.0 5.0 0.0 0.0 19 20 21 22 23 24 25 26 27 28 29 30 31 1 26 27 28 29 30 1 2 3 4 5 6 7 07 07 07 07 07 07 07 07 07 07 07 07 07 08 04 04 04 04 04 05 05 05 05 05 05 05 2004 2004 TPM Results MERCYMS

  16. Autumn 2003 Winter 2004 10 10 Day Day 8 8 Night Night -3 -3 6 6 RGM pg m RGM pg m 4 4 2 2 0 0 22 23 24 25 26 27 28 29 30 31 1 11 19 20 21 22 23 24 25 26 27 28 29 30 10 10 10 10 10 10 10 10 10 10 01 01 01 01 01 01 01 01 01 01 01 01 Spring 2004 Summer 2004 20 10 Manual Manual 16 8 -3 Automatic Automatic -3 12 6 RGM pg m RGM pg m 8 4 4 2 0 0 26 04 28 04 30 04 02 05 04 05 06 05 08 05 19 07 21 07 23 07 25 07 27 07 29 07 31 07 02 08 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 00:00 MERCYMS RGM Results

  17. MERCYMS Summary of results Average mercury concentrations at Cabo de Creus Season TGM TPM Manual Autom DGM RGM RGM -3 -3 -3 -3 -3 ng m pg m pg m pg m ng m Autumn 1.64 9.6 2.3 - - Winter 1.47* 9.1 0.2 - - Spring 2.00* 9.5 1.2 1.9 - Summer 2.13* 11.2 1.3 4.8 24 *0.5 h average values collected within the wind sector 300-90o at wind speeds > 4 m s-1

  18. Mercury in precipitation-examples from Swedish network • Monthly sampling period • Bulk samplers • HCl preservatives added • 2 samplers in parallel • Analysis using CVAFS • 4 stations in Sweden, 1 in Finland (1999) • 3 stations in Sweden, 1 in Finland (2001) • 2 stations in Sweden, 1 in Finland (2004) • 1 station in Sweden, 1 in Finland (2005)

  19. Wet deposition

  20. Precipitation amounts using different collectors 100 EMEP 90 Hg bulk 80 HM bulk 70 60 50 40 30 20 10 0 01 03 05 07 09 11 Total Total Total Total Total Total

  21. Investigation of sampler design and collection efficiency • Investigation conducted at 33 stations in Sweden • Parallel samplers at all sites • Bucket and funnel in summer and “snow sack” during winter

  22. Precipitation amounts at different stations and %difference between 2 funnel & bottle collectors

  23. Precipitation amounts at different stations and %difference between 2 snow sack collectors

  24. Precipitation measured with 4 different samplers

  25. Precipitation sampling • Occasional large variability in individual samples between different types of samplers • Not systematic • “Snow sack” samplers give higher total precipitation amounts • Need standardised methods and/or correct to common precipitation fields

  26. Deposition in forested ecosystems OF 10 g/km2 Litterfall 20 g/km2 TF 20 g/km2 Reemission ? g/km2 Runoff 2 g/km2 Total deposition = wet + dry-reemission = Throughfall + litterfall - reemission = 40 g/km2

  27. Deposition of total mercury in forests

  28. Deposition in relation to critical loads • 2 different critical load models for Hg, one based on limitations in fish concentrations, the other on accumulation in soil • For calculating accumulation in soils, need total deposition • EMEP measurements only wet deposition, total deposition 2-4 times higher in forested areas • Reemissions unknown • Models include the above but very little data available to verify and test model output.

  29. Final words • A successful implementation of protocols on mercury will require larger efforts on measurements from most countries • Air concentrations (species), wet deposition, total deposition in forested ecosystems, air surface exchange • Super stations are recommended (see conclusions from previous TFM&M meetings and CLRTAP Heavy metal workshops) • Currently no EU funded research projects on atmospheric mercury - FP7? • EU directive may lead to better situation
