  1. Creation Process: A “Life Cycle” Approach to Concept thru Fabrication/Production •Pre-determined Sites/Planning •Access Control •Perimeter Control •Population andVisitor Management • Match Asset Availability with Population • Cradle to Grave – Design thru Implementation • Engineering • Fabrication • Mass Production • User Deployability • Life Cycle Asset Management

  2. The Modular SMT iBunker™ iFORTRESS: PRODUCTS THAT PROTECT MISSION CRITICAL TECHNOLOGY AND ASSETS, PREVENTING INCIDENTS FROM BECOMING EVENTS WITH: THE MODULAR MCF iFORTRESS™ MODULAR, PANELIZED ENCLOSURES THAT SURROUND AND CONTAIN MISSION CRITICAL FACILITIES, PREVENTING HUMAN OR ENVIRONMENTALLY CAUSED FAILURE BY PROVIDING AN UNCOMPROMISED LEVEL OF STRUCTURAL SECURITY™

  3. • THE iMARC™ iFORTRESS PRODUCT LINE • THE iMODAL iFORTRESS™ • THE i19/i23 RACK BUNKER™ Self contained Watertight MT Resistant Secure

  4. The iFORTRESS Modular TranShelter™ iFORTRESS PRODUCT LINE

  5. RESPONSE AND DESIGN CRITERIA Challenges Faced: • Displaced Population • Separated Families/Friends • Fear/Panic • Civil Unrest • Lack of: • Community • Belonging • Order • Where to go/What to do • Services • Medical • Police • Communications • Postal • Basic Human Provisions • Food/Water/Power • Shelter Prime Objective: Determine most beneficial, least cost option available to manage, secure, own, and operate FEMA’s short term and long term “Crisis Management Assets”.

  6. RESPONSE AND DESIGN CRITERIA Challenges Faced with a Disaster of Mass/Societal Scale • Anticipate Complex Psycho-Social, fGeographical, Environmental, Economic .dynamics • Provide Sense of Preparedness • Re-Establish Authority/Services • Re-Establish Community • Create Order/Familiarity • Provide Shelters that provide jtruesense of Thought/Care/Security • Provide rapidly deployed, dscalable, and orderly solutions/settings • Allocate structural resources/assets that are: • Effective • Flexible • Manageable • Can be easily Inventoried/Maintained • Re-deployable

  7. Excellence Without Exception • Modular • Factory Engineered • Rapidly Deployed • Intuitive • Few Tools • Few Men (Manpower) • Structural Security™ • Fully Tested/Comprehensive Assembly • Four Principles of Structural Security™ • Structural • Hydro-dynamic • Fire/Thermal • Environmental iFORTRESS PHILOSOPHY

  8. The iFORTRESS Modular TranShelter™ Conceptual Inspiration Plus Purpose • Transportable • Road/Sea/Air • Self-contained • Lightweight • Quickly Deployed • Weather tight (r49) • Manageable Asset – Bar coded - CMMS

  9. The iFORTRESS Modular TranShelter™ • 20’ or 40’ • Modular TranShelter™ t tethered or lifted off trailer • Self contained 1,200 Ft²

  10. Interlocking Panels • Internal “Bunk” System • Low voltage Int/Ext lighting (Battery) • Fixed Exterior Monitoring Devices • “GREEN” Environmentals The iFORTRESS Modular TranShelter™ • 20’ or 40’ • Modular TranShelter™ t tethered off trailer • Self contained 1,200 Ft² • Accommodate 1 – 72 Occupants

  11. Reverse process • Modular TranShelter™ t return to inventory/maintenance • PDA Manageable • Scan condition/damage • Determine Inventory or Maintenance • Maintain inventory at Territorial Logistic f Center (TLC) for Storage/Re-deployment The iFORTRESS Modular TranShelter™

  12. SHORT/LONG TERM iModal™ iModal™ surgical supplies SITUATION - ASSET MANAGEMENT FOOD FOOD SUPPLIES • 89 FAMILIES TO 6,408 INDIVIDUALS • APPRX. 20 ACRES iModal™ iModal™ iModal™ • (89) RESIDENTIAL SSKU: MTRD 4030 • (3) MED. CLINIC S SKU: MTMC 4030 • (1) SURGICAL iMODAL™S SKU: iMSG 4030 • Psycho-Socio: • Understanding • Compassion • Restoration of.civil order with: • Familiarity • Community • “Real” care • Communication • Services • (1) MED SPPLY iMODAL™S SKU: iMSY 4030 SUPPLIES • (3) POLICE COMMAND S SKU: MTPC 4030 6 4 2 • (3) COMMAND iMODAL™S SKU: iMCD 4030 7 • (4) GENERAL SUPPLYS SKU: MTSY 4030 5 3 1 • (2) MED. RESIDENTIAL S SKU: MTMR 4030 • (1) POLICE RESIDENTIAL S SKU: MTPR 4030 Apprx. 1/8 mile SECOND ST. 3RD AVE 2ND AVE MAIN ST. 1ST AVE FIRST ST. WELCOME - PROCESSING CENTER US POST OFFICE Apprx. ¼ mile • Economical

  13. SHORT/LONGTERM SITUATION - ASSET MANAGEMENT • 89 FAMILIES TO 6,408 INDIVIDUALS • APPRX. 20 ACRES • (89) RESIDENTIAL SSKU: MTRD 4030 • (3) MED. CLINIC S SKU: MTMC 4030 • (1) SURGICAL iMODAL™S SKU: iMSG 4030 • (1) MED SPPLY iMODAL™S SKU: iMSY 4030 • (3) POLICE COMMAND S SKU: MTPC 4030 • (3) COMMAND iMODAL™S SKU: iMCD 4030 • (1) GENERAL SUPPLYS SKU: MTSY 4030 PROTECTED – SELF CONTAINED INVENTORY TERRITORIAL LOGISTICAL CENTER (TLC) CMMS: INVENTORY MANAGEMENT SYSTEM MAINTENANCE

  14. • “Keep Everyone . in the . Neighborhood” • “Both Sides of . the River.” • Stackability in . Deployment – . City Application • Sense of . Community • Visitor vs. . Indigent Population . Behavior Management

  15. Excellence Without Exception • Modular TranShelter™ • Standardized/Familiar (Home-like) Setting • Create community environments • Main Street/1st Avenue • Provide Entry Points • Assign Residence (1 Main St) • Create Rations Depot (General Stores) • iFortress iModal™ • Create sterile medical facilities • Establish Police and Communication NOCS • Deploy Secure Frontline IT infrastructure • i19/i23 Rack Bunker™ • Distributed Communication HUB’s • Secure Remote Facilities

  16. LEAST COST OF OWNERSHIP iFortress Provide: • Greatest Degree of Efficiency • Lower Operating Cost • Tax Benefit • 2 to 5 year Lease Options * • Operating vs Capital Expense • Greatest Degree of Risk Mitigation • Engineered – Tested – Proven • Disaster Preparedness • Evolutionary paradigm • Greatest Degree of Flexibility • Modular and Life Cycle Approach • Inventory and Re-deployment Capable • Manageable Asset versus sunk or lost cost acquisitions To be a part of the Structural Security™ evolution go to www.ifortress.com
