  1. Searching – Linear and Binary Searches

  2. Comparing Algorithms P1 P2 Should we use Program 1 or Program 2? Is Program 1 “fast”? “Fast enough”?

  3. You and Igor: the empirical approach Implement each candidate Run it Time it That could be lots of work – also error-prone. Which inputs? What machine/OS?

  4. Toward an analytic approach … How to solve “which algorithm” problems without machines, test data, or Igor!

  5. Input (n = 3) Input (n = 4) Input (n = 8) Output Output Output The Big Picture Algorithm How long does it take for the algorithm to finish?

  6. Primitives • Primitive operations • x = 4 assignment • ... x + 5 ... arithmetic • if (x < y) ... comparison • x[4] index an array • *x dereference (C) • x.foo( ) calling a method • Others • new/malloc memory usage

  7. N Σ j = 1 How many foos? for (j = 1; j <= N; ++j) { foo( ); } 1 = N

  8. N M Σ Σ j = 1 k = 1 How many foos? for (j = 1; j <= N; ++j) { for (k = 1; k <= M; ++k) { foo( ); } } 1 = NM

  9. N j N Σ Σ Σ j = 1 k = 1 j = 1 How many foos? for (j = 1; j <= N; ++j) { for (k = 1; k <= j; ++k) { foo( ); } } N (N + 1) 1 = j = 2

  10. How many foos? for (j = 0; j < N; ++j) { for (k = 0; k < j; ++k) { foo( ); } } for (j = 0; j < N; ++j) { for (k = 0; k < M; ++k) { foo( ); } } N(N + 1)/2 NM

  11. How many foos? T(0) = T(1) = T(2) = 1 T(n) = 1 + T(n/2) if n > 2 T(n) = 1 + (1 + T(n/4)) = 2 + T(n/4) = 2 + (1 + T(n/8)) = 3 + T(n/8) = 3 + (1 + T(n/16)) = 4 + T(n/16) … ≈ log2 n void foo(int N) { if(N <= 2) return; foo(N / 2); }

  12. What is Big-O? Big-O refers to the order of an algorithm runtime growth in relation to the number of items Focus on dominant terms and ignore less significant terms and constants as n grows SortingBigOh

  13. What is Big-O? Big-O refers to the order of an algorithm runtime growth in relation to the number of items I. O(l) - constant time (Push and pop elements on a stack) II. O(n) - linear time The algorithm requires a number of steps proportional to the size of the task. (Finding the minimum of a list) III. O(n2) - quadratic time The number of operations is proportional to the size of the task squared. (Selection and Insertion sort) IV. O(log n) - logarithmic time (Binary search on a sorted list) V. O(n log n) - "n log n " time (Merge sort and quicksort) SortingBigOh

  14. How would you find the first locker with a chinchilla in it?

  15. It’s the 6th one from the left

  16. Searching • Linear search: also called sequential search • Examines all values in an array until it finds a match or reaches the end • Number of visits for a linear search of an array of n elements: • The average search visits n/2 elements • The maximum visits is n • A linear search locates a value in an array in O(n) steps

  17. Pick a Number • Pick a number between 1 and 100. • You want to determine my number in the least amount of guesses possible. • How do you do it?

  18. Binary Search • Locates a value in a sorted array by • Determining whether the value occurs in the first or second half • Then repeating the search in one of the halves

  19. Binary Search 15 ≠ 17: we don't have a match

  20. Binary Search • Count the number of visits to search an sorted array of size n • We visit one element (the middle element) then search either the left or right subarray • Thus:     T(n) = T(n/2) + 1 where T(n) is time to search an array of size n • If n is n/2, then      T(n/2) = T(n/4) + 1 • Substituting into the original equation:     T(n) = T(n/4) + 2 • This generalizes to:    T(n) = T(n/2k) + k

  21. Binary Search • Assume n is a power of 2,    n = 2mwhere m = log2(n) • Then:    T(n) = 1 + log2(n) • Binary search is an O(log(n)) algorithm

  22. Comparison of Sequential and Binary Searches

  23. Assignment • Program a linear/sequential search of an array of Strings • Output the index where the element was found. Output must be user friendly • “Your value was found at index 13”; • “Your value was found at index -1” or “Your value was not found” • Program a binary search of an ArrayListof Integer • Recursive • “Your value was found in the array” or “Your value was not found in the array”
