  1. Implementing Advanced Intelligent Memory Josep Torrellas, U of Illinois & IBM Watson Ctr.David Padua and Dan Reed, U of Illinois torrella@watson.ibm.com, padua@cs.uiuc.edu, reed@cs.uiuc.edu September 1998

  2. Technological Opportunity We can fabricate a large silicon area of Merged Logic and Dram (MLD) Question: How to exploit this capability best to advance computing?

  3. Pieces of the Puzzle • Today: 256 Mbit MLD process with 0.25um Includes logic running at 200 MHz E.g. 2 IBM PowerPC 603 with 8KB I+D caches take 10% of the chip • Manufacturers: IBM Cmos-7LD technology available Fall 98 Japanese manufacturers (NEC,Fujitzu) are in the lead • In a couple of years: 512 Mbit MLD process at 0.18um

  4. Key Applications Clamor for HW • Data Mining (decision trees and neural networks) • Computational Biology (DNA sequence matching) • Financial Modeling (stock options, derivatives) • Molecular Dynamics (short-range forces) • Plus the typical ones: MPEG, TPCD, speech recognition All are Data Intensive Applications

  5. Our Solution: Principles 1. Extract high bandwidth from DRAM: > Many simple processing units 2. Run legacy codes w/ high performance: > Do not replace off-the-shelf uP in workstation > Take place of memory chip. Same interface as DRAM > Intelligent memory defaults to plain DRAM 3. Small increase in cost over DRAM: > Simple processing units, still dense 4. General purpose: > Do not hardwire any algorithm. No special purpose

  6. Architecture Proposed P.Host L1,L2 Cache P.Mem Cache Plain DRAM P.Array DRAM FlexRAM Network

  7. Proposed Work • Design an architecture based on key IBM applications • Fabricate chips using IBM Cmos 7LD technology • Build a workstation w/ an intelligent memory system • Build a language and compiler for the intelligent memory • Demonstrate significant speedups on the applications

  8. Example App: DNA Matching BLAST code from NIH web site sample DNA database of DNA chains Problem: Find areas of database DNA chains that match (modulo some mutations) the sample DNA chain

  9. How the Algorithm Works 1. Pick 4 consecutive aminoacids from the sample bbcf 2. Generate 50+ most-likely mutations becf

  10. Example App: DNA Matching 3. Compare them to every position in the database DNAs becf 4. If match is found: try to extend it sample DNA becf ? ? database of DNA chains becf

  11. P.Arrays 2 • Total of 64 per chip (90 mm ) • SPMD engines, not SIMD. Cycling at 200 MHz • 32-bit datapath, integer only, including MPY. 28 instruc. • Organized as a ring, no need for a mesh • Each P.Array 1 Mbyte of DRAM memory. Can also access the memory of N and S neighbors 2 1-Kbyte row buffers to capture data locality 8 Kbyte of SRAM I-memory shared by 4 P.Arrays

  12. P.Array Design ALU Switches Input Reg. R.Reg. Sense AMP/Col. Dec Controller Port 0 Port 1 DRAM Block Addr. Gen. Port 2 Switches Instr. Mem ROW Decoder Broadcast Bus

  13. P.Mem • IBM 603 Power PC with 8 KB D + 8 KB I cache 2 • About 15 mm • 200 MHz • Also included: memory interface

  14. DRAM Memory • 512 Mbit (64 Mbyte) with 0.18um • Organized as 64 banks of 1 MB each (one per P.Array) • 2.2V operating voltage • Internal memory bandwidth: 102 Gbytes/s at 200 MHz • Memory access time at 200 MHz: • 2 cycles for row buffer hit • 4 cycles for miss

  15. Memory Control Block Memory Control Block 512 row x 4k columns 256kB Block 256kB Block 2Mb Block 8Mb Block PArray PArray Basic Block Basic Block Basic Block Mutiplier 8kB Instruction Memory (4-port SRAM) (4 PArray,4MB DRAM, 8kB 4-Port SRAM, 1 Multiplier) Memory Control Block Memory Control Block 1MB Block 1MB Block PArray PArray Basic Block Basic Block Basic Block Basic Block Broadcasting Pmem Broadcasting Basic Block Basic Block Basic Block Basic Block Basic Block Basic Block Basic Block Basic Block Chip Architecture

  16. 1MB Block 1MB Block Basic Block 512 row x 4k columns 2Mb Block 256kB Block 256kB Block Memory Control Block Memory Control Block PArray PArray PArray PArray Mutiplier Memory Control Block Memory Control Block 8kB Instruction Memory (4-port SRAM) 8Mb Block

  17. Language & Compiler • High-level C-like explicitly parallel language that • exposes the architecture • Compiler that automatically translates it into • structured assembly • Libraries of Intelligent Memory Operations (IMOs) • written in assembly

  18. Intelligent Memory Ops • General-purpose operations such as: • Arithmetic/logic/symbolic array operations • Set operations. Iterators over elements of a set • Regular/irregular structure search and update • (CAM operations) • Domain-specific operations: e.g. FFT

  19. Performance Evaluation • Hardware performance monitoring • embedded in the chip • Software tools to extract and interpret • performance info

  20. Preliminary Results 1 2 0 Uniprocessor 1 0 0 1 FlexRAM 8 0 Relative Execution Time 4 FlexRAM 6 0 4 0 2 0 0 MPEG2 Chroma/Keying

  21. Current Status • Identified and wrote all applications • Designed architecture based on apps & IBM technology • Conceived ideas behind language/compiler • Need to do: chip layout and fabrication • development of the compiler • Funds needed for: processor core (P.Mem) • chip fabrication • hardware and software engineers

  22. Conclusion • We have a handle on: • A promising technology (MLD) • Key applications of industrial interest • Real chance to transform the computing landscape

  23. Current Research Work Josep Torrellas, U of Illinois & IBM Watson Ctr. torrella@cs.uiuc.edu http://iacoma.cs.uiuc.edu September 1998

  24. Current Research Projects • 1. Illinois Aggressive COMA (I-ACOMA): Scalable • NUMA and COMA architectures • 2. FlexRAM: Avanced Intelligent Memory • 3. Speculative Parallelization Hardware • 4. Database Workload characterization: TPC-C, • TPC-D, Data mining > All projects are in collaboration with IBM Watson > Project 4 is also in collaboration with Intel Oregon

  25. Publications 1997 and 98 1.Architectural Advances in DSMs: A Possible Road Ahead by Josep Torrellas, Ninth SIAM Conference on Parallel Processing for Scientific Computing Spring 1999. 2.A Direct-Execution Framework for Fast and Accurate Simulation of Superscalar Processors by Venkata Krishnan and Josep Torrellas, International Conference on Parallel Architectures and Compilation Techniques (PACT), October 1998. 3.Hardware and Software Support for Speculative Execution of Sequential Binaries on a Chip-Multiprocessor by Venkata Krishnan and Josep Torrellas, International Conference on Supercomputing (ICS), July 1998. 4.Comparing Data Forwarding and Prefetching for Communication-Induced Misses in Shared-Memory MPs by David Koufaty and Josep Torrellas, International Conference on Supercomputing (ICS), July 1998. 5.Cache-Only Memory Architectures by Fredrik Dahlgren and Josep Torrellas, IEEE Computer Magazine, to appear 1998. 6.Executing Sequential Binaries on a Multithreaded Architecture with Speculation Support by Venkata Krishnan and Josep Torrellas, Workshop on Multi-Threaded Execution, Architecture and Compilation (MTEAC'98), January 1998. 7.A Clustered Approach to Multithreaded Processors by Venkata Krishnan and Josep Torrellas, International Parallel Processing Symposium, March 1998. 8.Hardware for Speculative Run-Time Parallelization in Distributed Shared-Memory Multiprocessors by Ye Zhang, Lawrence Rauchwerger, and Josep Torrellas, Fourth International Symposium on High-Performance Computer Architecture, February 1998. 9.Enhancing Memory Use in Simple Coma: Multiplexed Simple Coma by Sujoy Basu and Josep Torrellas, Fourth International Symposium on High-Performance Computer Architecture, February 1998. 10.How Processor-Memory Integration Affects the Design of DSMs by Liuxi Yang, Anthony-Trung Nguyen, and Josep Torrellas, Workshop on Mixing Logic and DRAM: Chips that Compute and Remember, June 1997. 11.Efficient Use of Processing Transistors for Larger On-Chip Storage: Multithreading by Venkata Krishnan and Josep Torrellas, Workshop on Mixing Logic and DRAM: Chips that Compute and Remember, June 1997. 12.The Memory Performance of DSS Commercial Workloads in Shared-Memory Multiprocessors by Pedro Trancoso, Josep-L. Larriba-Pey, Zheng Zhang, and Josep Torrellas, Third International Symposium on High-Performance Computer Architecture, January 1997. 13.Reducing Remote Conflict Misses: NUMA with Remote Cache versus COMA by Zheng Zhang and Josep Torrellas, Third International Symposium on High-Performance Computer Architecture, January 1997. 14.Speeding up the Memory Hierarchy in Flat COMA Multiprocessors by Liuxi Yang and Josep Torrellas, Third International Symposium on High-Performance Computer Architecture, January 1997.
