  1. Michael LeGore TJHSST CSL Traffic Based Pathway Optimization

  2. Purpose • To create an algorithm to find an optimal path using the heuristic of time. • To train the algorithm to avoid traffic hotspots at peak hours. • To use traffic data to estimate travel time on roads. • To optimize algorithm based on results of analysis.

  3. Background • Path finding algorithms principally use distance as a heuristic. • Many consumers are concerned only with travel time. • Traffic patterns in certain area at certain times can be used to accurately predict travel times.

  4. Background: A* Search • Algorithm to find the optimal path. • Searches through current node and adds each segment to search space. • Iterates over search space until the minimum pathway returned is at the destination. • Uses Heuristic to estimate distance to destination.

  5. Traffic Based Algorithm • Instead of dealing with distance, algorithm finds path based on travel time • Travel Time is estimated from data VDOT • Estimate can take into account contexts such as weather, time of day, and other traffic fluctuations.

  6. Implementation • Ruby for programming • A* Search with a modified heuristic to find path • Use VDOT traffic data to model the average speed. • Feed this data into A* Search • Use it to find the optimal path • Tweak algorithm based on results.

  7. Development • Search Algorithm • Algorithm is an A* search with a modified heuristic. • Interpreting of Traffic Data • Needed to provide a heuristic for travel time • Provides data to estimate the speed of cars. • Speed used to find the time spent on each road segment.

  8. VDOT data • Gives three main factors: • AAWT – Average Annual Daily Traffic • AAWDT – Average Annual Weekday Traffic • K Factor – The ratio of AAWT to design (peak) hour traffic • Ratio of AAWT to AAWDT • K value used to factor in Rush-Hour effects

  9. Limitations of VDOT Data • Only provides data over time • Does not model based on time of day • Gives peak hour traffic concentration but not time of peak hour(s). • Only gives concentrations of traffic • Does not correlate with the TIGER data used for the road shapes

  10. Demonstration • Input Addresses • Input time of day • Returns optimal path for that time of day.

  11. Original Implementation/Plan • Traffic Simulation • Use traffic simulation to feed data back into the algorithm • Keep track of travel times of agents • Unfeasible given time and computing constraints • TIGER data not adequate for an agent based model.

  12. Possible Extensions • Find more complete data for estimating travel time • Integrate more factors into the heuristic • Weather • Holidays • More? • Distributed Approach to data collection • Integrated into GPS devices • iPhone app?

  13. Things I learned • Data collection as a single person is not possible • Writing a sophisticated traffic simulator to model 1 Million+ agents is not at all feasible in the current state of computing • Data for traffic can be very fragmented and not standardized

  14. Conclusion • Time can be a good heuristic for finding a path • An A* search is easily modifiable to accommodate many types of heuristics with different effects • Proper data is necessary for such an algorithm to work

  15. Questions?
