  1. Mobile Concierge EM 385 Innovative System Design Adam Hecht William Hespe Michael Munley Gus Rath Richa Soin

  2. Team Roles Adam Hecht Project Leader Development of functional architecture William Hespe Research of current technology / “state of the art” Michael Munley Design Alternatives / Analysis Concept Selection Gustaf Rath Nonfunctional Requirements Quality Function Deployment Richa Soin Stakeholder Identification Stakeholder Requirements

  3. Introduction The opportunity exists to enable visitors to locate points of interest in metropolitan areas. Our vision is to create a system that will allow users the ability to locate restaurants, stores, parks, and other interesting places. The primary customer(s) of the mobile concierge system would be frequent travelers, tourists, and visitors.

  4. But what will it do… • Locate you • Suggest points of interest based on your inputs • Locate said points of interest • Provide expert reviews • Make reservations for hotels and restaurants • Purchase tickets for theaters, movies, sports events, etc.

  5. Needs Analysis:Research Maps • TomTom personal navigation • Garmin • Mapquest Travel Guides • Frommer’s • AAA • Zagat Survey Competition • Mobile Food Guide • American Express Centurion Service • Google Search • Mio DigiWalker H610 • CitySearch

  6. Stakeholder Requirements • Visitors • Provide a response in less than 10 seconds • Must be a mobile and compact service • Provide directions to the location • Allow users to make reservations • Manufacturers • Use standardized components (interchangeability) • Utilize tested and previously implemented technology • Maintenance • Self Diagnostic • 99.9% availability. • Regulatory Bodies • Conform to all regulations at each level of government. • Mobile Service Provider • The system must conform to TIA/EIA networking, 802.11x, standards

  7. Acceptance Criteria Customers will be able to • Locate restaurants, theaters, stores, parks, and other interesting places. • Purchase or make reservations for said services. • Have 99% coverage in major U.S. metropolitan areas.

  8. Alternate Concepts • Kiosk • Cell Phone Add-in • PDA/Travel Device • Car Navigation System

  9. Pugh Matrix

  10. Context Diagram Tourist & Visitors Point of Interest info. Request Mobile Concierge System Status Repairs Maintenance Service Provider System Errors Updates and Management

  11. Use Case Scenarios Use Cases • Find Point of Interest • Request Directions • Access Ratings • Detect Errors • Update system • Check system status • Make Reservations • Request Transportation • Create User Profile • Select Services

  12. QFD Analysis

  13. System Requirements • Inputs • Mobile device keystrokes • Update patches • HTTP mobile services web page • Online activity selections • Outputs • Requests (Password, activity type, selection confirmation) • Error indication • Main Menu • Maintenance personnel access • Location suggestions

  14. System Requirements (Cont.) • System-Wide • Self-diagnostic • 99% up-time • Meet FCC regulations • Multiple service providers • GSM and CDMA compatible • Lifetime: 3 years

  15. External Systems Diagram

  16. Triggers Inputs Outputs Context Diagram

  17. CORE Functional Architecture Perform Log-In Use Mobile Concierge System Maintain System

  18. Use Case Traceability

  19. Traceability Through Functional Architecture

  20. Traceability: Level 1

  21. Use Case vs. CORE Make Reservation Access Ratings Select Services

  22. Technical Performance Metrics • Must meet industry communications standards • TCP/IP • IEEE 802.11x protocols • Serial Communications Standards (RS-232, RS-485, Etc.) • Physical Weight: 4-8 Oz • Processing Power: 500MHz • Range: Greater than 10 Miles

  23. Risk Identification and Mitigation Equipment failure • Planned failures vs unexpected • Self diagnostic Different Standards • Multiple Vendors Low readiness for change • Advertising campaign; convince people that Mobile Concierge is better than internet search Poor customer service/delivery • Provide technical support with online information and telephone

  24. Conclusion • Good foundation for senior design work • Feasible product with potential user base • Next Steps • Component level design • Relationships with external entities • Costing / Value Engineering

  25. Questions?
