Presentation Transcript

  1. The Challenges • Develop the next generation of value-oriented card printers • Bring dual-sided card printing into the mainstream by making it more affordable and convenient

  2. The Result: Zebra P120i The Most Affordable Dual-Sided Card Printer

  3. The Next Generation of Value Printers • Completely new – inside and out • Small form factor based on new card feederand card flipover subassembly designs • Utilizes modern, high-strength plasticsfor reduced size and weight (WEEE Compliant) • Modern industrial design – fits well into mostoffice and retail environments

  4. The Zebra P120i Changes the Game • New level of affordability – more than $700 less than the next cheapest dual-sided card printer • Now there’s a dual-sided printer that is only $200-$500more than a single-sided printer! • Some customers will trade down from Performance-category printers like the Zebra P420iBUT… • Many customers will switch from single-sided printing, now that the cost is comparable

  5. Say ‘Hello’ to the Back of the Card!100% More Printable Area • Easier to read text information • Larger photos for better identification • Better looking cards • Less cluttered design on the front • Functional items such as bar codes on the back • Better corporate branding • Ability to group related text information • Mirror-image card design (same info on both sides) ensures that security information is always visible

  6. P120i Information • Key Message • Product Advantages • Product Specifications • P120i Compared to P420i • Customer Profile • Target Markets & Applications • Competitive Analysis • Cost of Ownership • Summary

  7. P120i Key Message • Advanced design delivers a revolutionary new dual-sided, full-color card printer at an unprecedented price point. • Affordable • Versatile • Easy-to-Use • Compact

  8. P120i Advantages Affordable •  Low initial investment - €2,395 list price • Intuitive design reduces training costs

  9. P120i Advantages Versatile • Dual-sided or Single-sided printing • Full-color or Monochrome printing • Automatic card-feed or CardSense™ single card-feed (field upgradeable option) • Magnetic encoder, 3 track HiCo/LoCo (factory-installed, available Q1-2006)

  10. P120i Advantages Easy-to-use • Load-N-GoTM ribbon cartridge with i Series auto-ribbon detection and integrated card-cleaning roller* • 16-digit LCD informs users of daily operation and routine cleaning messages • Blue touch-points show users which parts are safe to touch *Patent Pending

  11. P120i Advantages Compact • Advanced compact and lightweight design fits easily into any environment • Integrated card feeder and flipper components turn the card on the short side* • Made from durable carbon fiber reinforced polycarbonate with silicone * Patent Pending

  12. Compact & Transportable Fits into Most Operating Environments • Width: 7.9 in (201mm) • Depth: 12.9 in (328mm) • Height: 8.5 in (216mm) • Weight: 9.5 lbs (4.3kg)

  13. P120i Specifications • 30 Sec/Card Full-Color, Single-Sided Print Speed • 35 Sec/Card Full-Color front/mono reverse, Dual-Sided Print Speed • 30 mil Card Thickness • 100 Card-Capacity Feeder • 45 Card Output Hopper Capacity • USB Communication

  14. Easier Service & Maintenance • Tool-less printhead replacement • Easily removable side covers • Modular design for component replacement

  15. Load-N-Go™ Ribbon • * Patent Pending • Drop-in ribbon cartridge with integrated cleaning roller • i Series automatic ribbon detection & auto-configuration Integrated Cleaning roller ID Contact Chip

  16. P120i Options • CardSenseTM single card-feed kit (field upgradeable) • Starter Kit (200 - 30 mil PVC cards and1 YMCKOK ribbon) • Cleaning Kit contains 4 sets of long cleaning cards (print engine) and small cleaning cards (feeder) • Magnetic encoder (30 mil cards only), 3 track HiCo/LoCo (factory-installed, available Q1-2006)

  17. CardSense™ Single Card-feed Kit • CardSense™ enables users to feed and return cards through the front slot of the printer (similar to how an ATM works) • Ideal for businesses that use multiple card media • Easy to switch between single-feed and automatic-feed modes • €25 list price CONFIDENTIAL

  18. Zebra TrueColours® Supplies • Ribbon Cartridges • Load-N-Go™ ribbon cartridge with integrated card-cleaning roller • i Series technology • YMCKO: 200 cards/cartridge • YMCKOK: 165 cards/cartridge • Monochrome: 1000 cards/cartridge in black, blue, or white • Cards • PVC and PVC Composite • Magnetic stripe and smart cards • 30 mil card thickness

  19. P120i Ship Kit • Convenient printer driver and user documentation • Windows® 2000 and XP (Microsoft® Certified) • User documentation (electronic format) • Quick Start (hard copy) • Operator Training CD • Power cord • USB cable • One long cleaning card (print engine), one small cleaning card (feeder) and one cleaning swab • Sample test card • Optional Starter Kit

  20. Zebra P120i compared to P420i

  21. Dual-Sided Customer Priorities P120i • Value and affordability • Low-to-moderate volume printing • Entry-level user • Small space • Single card-feeding option P420i • High performance and duty cycle • Ethernet connection • Metal case • Smart card encoding • Electronic lock

  22. Value Printer for Dual-Sided Card Printing •  Low initial investment - €2,395list price • Intuitive easy-to-use design reduces training costs • Compact size fits into most environments

  23. Low-to-moderate volume card printing Value conscious small-to-medium businesses and organizations Space-constrained operating area Entry-level, non-technical operators P120i Customer Profile

  24. Access and ID Card Applications

  25. Membership Applications

  26. Personalized Loyalty and Gift Card Applications

  27. Education Hospitality Event badging Child Identification Other Applications

  28. P120i Summary Affordable • Low initial investment (€2,395 list price) • Intuitive design reduces training costs Versatile • Dual-sided or single-sided printing • Full-color or monochrome printing • Automatic or single card-feed (field upgradeable option) • Magnetic encoder (factory installed, available Q1-2006)) Easy-to-use • Load-N-Go™ ribbon cartridge   • 16-digit LCD display • Compact and lightweight • Blue touch-points
