  1. EMIT DATA ACQUISITION SmartLog V4 DescoEMIT.com Rev: 2011-01-01

  2. Why SmartLogV4? SmartLogV4 (US Patent 6,078,875) Benefits: • Real-Time test data • Eliminates manual/paper logs • Faster, more accurate testing of grounding devices • Track grounding device longevity • Test records available at all times • Archive test data • Satisfies ISO and S20.20 record keeping requirements. SmartLogV4 Key Features: • 1 second test cycles of all grounding devices • No dedicated computer necessary for each SmartLog V4 system • Insures consistent employee testing • Solid State Touch Tester eliminates wearing of previous mechanical button • Decreases test times as much as 1/3rd • Powerful Windows based software • Network & E-mail compatible • Pin Entry satisfies FDA regulations • Software and Hardware Support Readily Available DescoEMIT.com

  3. SmartLog V4 Hardware Clock Features: • Large internal RAM (stores up to 10,000 user ids) • Relay terminal for door unlocking capabilities • 1” x 4” LCD screen that displays 7 different languages • Infrared barcode reader for use with 39 and 128 barcodes • 32 SmartLog V4 devices can be daisy-chained Keypad Features: • 10 digit keypad for optional entering of the employee ID’s Footplate Features: • Heavy duty durable footplate • Split design for testing of individual footwear SmartLogV4 (US Patent 6,078,875) Tester Features: • Solid State Touch Tester • Blue illuminating LED indicating “ready to test” • Tests both single and dual-wire wrist straps • Independent testing of individual footwear • 1 second test cycles of grounding devices • Audible and Visual alarms DescoEMIT.com

  4. SmartLog V4 Improvements SmartLogV4 (US Patent 6,078,875) New Upgrades: • NEW! Time Clock Capabilities* • Collect Time Clock Data and ESD test Data • NEW! Access Control Capabilities* • Control access to specific areas of a facility via a door relay • NEW! V4 Firmware • Faster communication between the TEAM5 Software and SmartLog V4 • NEW! TEAM5 Software • Several new features and remote applications • NEW! Electrode button with Blue illuminating LED • Blue LED provides a visual ready to test indication • NEW! 1 second test cycles • For quicker, more efficient testing of ESD garments • NEW! Large internal RAM • Stores up to 10,000 User ID’s and Test transactions as a stand alone unit • *TEAM 5 Enterprise Features Blue LED indicating ready to test DescoEMIT.com

  5. SmartLog V4 Hardware SmartLogV4 (US Patent 6,078,875) Easy to Install: • Includes everything needed for single unit installations: • SmartLog V4 Tester • 10-digit Numeric Keypad • Infrared Barcode Reader (clock) • 15” x 14” yellow back plate • AC power adapter • Heavy duty footplate • Additional mounting and connection hardware • Mounts on just about any wall • New back plate design hiding all connecting wires • No need for a designated computer • Microsoft Windows compatible • Daisy Chaining of up to 32 SmartLog V4 devices • Technical support available for hardware and software setup up DescoEMIT.com

  6. SmartLog V4 Accessories SmartLogV4 (US Patent 6,078,875) Optional Readers: • Magstripe Reader* • For use with track 2 Magstripe cards. • Proximity Reader* • Can be programmed to work with customers existing badges • * Offered as a custom. Contact EMIT Customer Service for more information SmartLogV4 Built in relay terminal to be used with electronic doors or turnstiles Optional Accessories: • 50443 - Laser Barcode Scanner • Eliminates card wear and allows for quicker scanning of the • employee barcodes. • 50461 - Ethernet Adapter • Allows for a universal connection to your network. • 50422 - Limit Comparator • Offers in house calibration of the SmartLog V4 DescoEMIT.com

  7. TEAM5 Software Levels of TEAM5 (US Patent 6,078,875) SmartLogV4 TEAM5: • Auto or Manual Polling of data to computer • Auto or Manual Reports to Department or Shift Managers • Web Status Monitor offers remote status of all SmartLog V4’s • Scheduled Leave Times for employees Test Log Window SmartLogV4 TEAM5 Enterprise: • Auto or Manual Backups of test data and user preferences • Access Control and Time Clock Capabilities • Calibration Notifications of each SmartLog V4 • Remote Admin Applications Test Machine Window DescoEMIT.com

  8. TEAM5 Software What’s New? (US Patent 6,078,875) • NEW!Access Control Feature • When enabled, the SmartLog is capable of controlling access to specific areas of a facility via a door relay actuator • NEW! Time Clock Feature • When enabled, the SmartLog is capable of collecting Time Clock Data and ESD Test Data • NEW! Scan Ports Feature • Clicking this starts a scan of all com ports for any available SmartLogs • NEW! Web Status Monitor • View the number of transactions completed on each SmartLog that day • NEW! PIN Checking Feature • When enabled, users must enter a PIN number in addition to scanning badge before ESD Testing, gaining Access Control or Entering Time Clock Punch • NEW! Location Field • Assign a SmartLog to a specific location in your facility • NEW! Transaction Field • View the number of transactions completed on each SmartLog that day • NEW! ID Counter • View the number of users loaded into each SmartLog system DescoEMIT.com

  9. SmartLog V4 New Look! (US Patent 6,078,875) • Admin Password • The Admin Password controls access to the TEAM Server Program • Email • When enabled, TEAM will allow test or status reports out to management, supervisors and/or human resources • Auto Start • When enabled, TEAM will automatically start with Windows startup • Support • Contact EMIT by email via the software for immediate support • Schedule Reports • When enabled, users must enter a PIN number in addition to scanning badge before ESD Testing, gaining Access Control or Entering Time Clock Punch • Network Admin • TEAM5 Enterprise has several network applications and interfaces. Assign each to a network folder that can be viewed by approved personnel • Daily Shutdown / Restart • Schedule TEAM shutdowns to allow Windows Updates or Scans to be performed • Backups • Manually backup up users test data and preferences. Schedule multiple backups throughout the day and week DescoEMIT.com

  10. SmartLog V4 Need More Information? For a demonstration contact EMIT for your local sales representative. DescoEMIT.com or 909-664-9980 30-day demo program available. DescoEMIT.com
