  1. Measuring the Semantic Web Rosa Gil Iranzo GRIHO, Universitat de Lleida, Spain Roberto García González rhizomik.net

  2. Outline • Motivationwhy to measure? • Approachcomplex systems • Measuringapplying statistical tools • Resultsis the semantic web a complex system? • Conclusions

  3. Motivation • Semantic Web, an open evolving system. • TimBL: “Looking for a metric” in “The Fractal nature of the Web”, Design Issues. • How is it measured? What’s the metric?

  4. Motivation • Why to measure? • From the TimBL“Weaving the Web” Semantic Web plan… • Where we are now? • How is it evolving? • Are we going where it was planned? • …

  5. Approach • Semantic Web as complex as many other systems: • metabolic networks • acquaintance networks • food webs • neural networks • TheWWW • …

  6. Approach • This complex systems are studied using Complex Systems (CS) Analysis. • Statistical tools for graph models: • Degree Distribution • Small World • Clustering Coefficient • …

  7. Approach • Model the system as a graph. • CS graph characteristics: • Degree Distributionpower law, P(k) ≈ k - r • Small Worldsmall diameter, d ≈ drandom • Clustering Coefficienthigh clustering, C >> Crandom

  8. Measuring • Is the Semantic Web a CS? • It is already a graph. • Crawl all DAML Ontologies Library: • 2003: 56,592 nodes, 131,130 arcs • 2005: 307,231 nodes and 588,890 arcs • Statistical study of the graph.

  9. Network Nodes <k> C <d>  DAMLOntos(2003-4-11) 56,592 4.63 0.152 4.37 -1.48 DAMLOntos(2005-1-31) 307,231 3.83 0.092 5.07 -1.19 WWW ~200 M 0.108 3.10 -2.24 WordNet 66,025 0.060 7.40 -2.35 WordsNetwork 500,000 0.687 2.63 -1.50 Results

  10. Results • It is a small worlddiameter smaller than random graph, d=4.37 while drand=7.23 • It has high clusteringC=0.152 while Crandom=0.0000895 • It is scale freepower law degree distribution, P(k)≈k –1.19

  11. Results CDF (Cumulative Distribution Function) Degree

  12. Conclusions • The Semantic Web is a Complex System. • Behaves like a living system (neural network, food web, proteins net,…), i.e. the same dynamics. • Same behaviour 2003-2005.

  13. Conclusions • Just exploring applications: • Degree dynamics for trust computation. • Ontology alignment (clusters, centrality,…). • Metadata high volumes management. • etc. • More information and tools at: http://rhizomik.net/livingsw

  14. Thank you for your attention Roberto García <roberto@rhizomik.net>Rosa Gil <rgil@diei.udl.es>
