  1. SOOT By Joe Palmer Information taken from http://www.sable.mcgill.ca/soot/tutorial/pldi03/tutorial.pdf

  2. General Overview • Developed by Sable Research Group out of McGill University in 1996-1997 • Used to optimize Java Bytecode • 4 source languages • 4 intermediate representations used

  3. Sources Languages • Primarily takes Java Source as its input • Can also take: • SML • Scheme • Eiffel

  4. I.R.’s • Baf: • Streamlined, stack-based representation of bytecode • Abstracts type dependent variations of expressions into a single expression • Jimple: • Stack-less, typed, 3-Address representation of bytecode • Mix between java source and java bytecode • Linearization of a single expression into 3 separate statements • Only refers to 3 local vars or conts at once • Only 15 jimple instructions are used • Compared to 200 possible instructions in java bytecode! • Shimple: • SSA-form version of Jimple • Each local var has a single static point of definition (never reassign) • Uses Phi-Nodes for control flow • Grimp: • Similar to Jimple but allows trees of expressions together with a representation of a “new” operator • Expressions are “aggregated” main IR used!!

  5. Phases of the Optimization

  6. Analysis • Tested using 8 SPECjvm98 benchmarks running on JDK 1.2 • Showed 8% improvement when optimized bytecode is run using an interpreter • 21% improvement when optimized bytecode is run using a JIT compiler • Used in research with traditional compiler analyses, analyses for software engineering, analysis for distributed programs, and software verification • Ptolemy Project • Bandera • Canvas Project

  7. Strengths and Future Enhancements • Used as a common infrastructure with which researchers could compare common analyses • Enhancements coming: • Attribute management • Attribute legends • Improved visual attributes in source • Interactive CFGs • Growable graphical callgraph • Making conversion from Java to Jimple more stable and complete
