  1. Fall 2010 The Chinese University of Hong Kong CSCI 3130: Automata theory and formal languages AmbiguityParsing algorithm for CFGs Andrej Bogdanov http://www.cse.cuhk.edu.hk/~andrejb/csc3130

  2. Ambiguity • A grammar is ambiguous if some strings have more than one parse tree E  E + E | E * E | (E)| N N  1N | 2N | 1 | 2  E E E E * E + E 1+2*2 + E E V V E * E V V 2 V V 1 = 5 = 6 1 2 2 2

  3. Disambiguation • Sometimes we can rewrite the grammar to remove the ambiguity E  E + E | E * E | (E)| N N  1N | 2N | 1 | 2 same precedence! F F T T Divide expression into terms and factors F F 2 * (1 + 2 * 2)

  4. Disambiguation E  E + E | E * E | (E)| N N  1N | 2N | 1 | 2 An expression is a sum of one or more terms E  T | E + T Each term is a product of one or more factors T  F | T * F Each factor is a parenthesized expression or a number F  (E) |1 | 2

  5. Parsing example E E  T | E + T T  F | T * F F  (E) |1 | 2 E T + T F F T * E ( ) F E + T E T T F + * T F F F 2 * (1 + 1 + 2 * 2) + 1

  6. Disambiguation • Disambiguation is not always possible • There exist inherently ambiguous languages • There is no general procedure for disambiguation • In programming languages, ambiguity comes from precedence rules, and we can do like in example • In English, ambiguity is sometimes a problem: He ate the cookies on the floor

  7. Parsing • Do we have a method for building a parse tree? • Can we tell if the parse tree is unique? S → 0S1 | 1S0S1 | T T → S | e input: 00111

  8. First attempt • Maybe we can try all possible derivations: S → 0S1 | 1S0S1 | T T → S |  x = 00111 S 0S1 00S11 01S0S11 0T1 when do we stop? 1S0S1 10S10S1 ... T S 

  9. Problems • How do we know when to stop? S → 0S1 | 1S0S1 | T T → S |  x = 00111 S 0S1 00S11 01S0S11 when do we stop? 0T1 1S0S1 10S10S1 ...

  10. Problems • Idea: Stop derivation when length exceeds |x| • Not right because of -productions • We want to eliminate -productions S → 0S1 | 1S0S1 | T T → S |  x = 01011 S  0S1  01S0S11  01S011  01011 1 3 7 6 5

  11. Problems • Loops among the variables (S→T→S) might make us go forever • We want to eliminate such loops S → 0S1 | 1S0S1 | T T → S |  x = 00111

  12. Removal of -productions • A variable N is nullable if there is a derivation • How to remove-productions * N • Find all nullable variables N • For every production of the form A → N, • add another production A →  • If N →  is a production, remove it • If S is nullable, add the special productionS →    

  13. Example • Find the nullable variables grammar nullable variables B C D S  ACD A a B   C  ED |  D  BC | b E  b • Find all nullable variables 

  14. Finding nullable variables • To find nullable variables, we work backwards • First, mark all variables A s.t. A   as nullable • Then, as long as there are productions of the formwhere all of A1,…, Ak are marked as nullable, mark A as nullable A → A1… Ak

  15. Eliminating e-productions D  C S  AD D  B D  e S  AC S  A C  E S  ACD A a B   C  ED |  D  BC | b E  b nullable variables:B, C, D  • For every production of the form A → N, • add another production A →  • If N →  is a production, remove it

  16. Dealing with loops • A unit production is a production of the formwhere A1 and A2 are both variables • Example A1 → A2 grammar: unit productions: S → 0S1 | 1S0S1 | T T → S | R |  R → 0SR S T R

  17. Removal of unit productions • If there is a cycle of unit productionsdelete it and replace everything with A1 • Example A1 → A2 → ... → Ak→ A1 S T  S → 0S1 | 1S0S1 | T T → S | R |  R → 0SR S → 0S1 | 1S0S1 S → R |  R → 0SR  R T is replaced by S in the {S, T} cycle

  18. Removal of unit productions • For other unit productions, replace every chainby productions A1 → ,... , Ak→  • Example A1 → A2 → ... → Ak→  S → 0S1 | 1S0S1 | R |  R → 0SR S → 0S1 | 1S0S1 | 0SR |  R → 0SR S → R → 0SR is replaced by S → 0SR, R → 0SR

  19. Recap • After eliminating e-productions and unit productions, we know that every derivationdoesn’t shrink in length and doesn’t go into cycles • Exception: S → • We will not use this rule at all, except to check if e  L • Note • e-productions must be eliminated before unit productions * S  a1…ak where a1, …, ak are terminals

  20. eliminate unit, e-prod Example: testing membership S →  | 01 | 101 | 0S1 |10S1 | 1S01 | 1S0S1 S → 0S1 | 1S0S1 | T T → S |  x = 00111 01, 101 S 0S1 0011, 01011 00S11 strings of length ≥ 6 only strings of length ≥ 6 10011, strings of length ≥ 6 10S1 10101, strings of length ≥ 6 1S01 only strings of length ≥ 6 1S0S1

  21. Algorithm 1 for testing membership • How to check if a string x ≠ e is in L(G)  • Eliminate all e-productions and unit productions • Let X := S • While some new rule R can be applied to X • Apply R to X • If X = x, you have found a derivation for x • If |X| > |x|, backtrack • If no more rules can be applied to X, x is not in L   

  22. Practical limitations of Algorithm I • This method can be very slow if x is long • There is a faster algorithm, but it requires that we do some more transformations on the grammar G = CFG of the java programming language x = code for a 200-line java program algorithm might take about 10200 steps!

  23. Chomsky Normal Form • A CFG is in Chomsky Normal Formif every production (except S → e)is • Convert to Chomsky Normal Form: A → a A → BC or Noam Chomsky A → BcDE A → BX1 X1→ CX2 X2→ DE A → BCDE C → c break up sequences with new variables replace terminals with new variables C → c

  24. Algorithm 2 for testing membership SAC S  AB | BC A  BA | a B  CC | b C  AB | a – SAC – B B SA B SC SA B AC AC B AC x = baaba b a a b a Idea: We generate each substring of x bottom up

  25. SAC – SAC – B B SA B SC SA B AC AC B AC b a a b a Parse tree reconstruction S  AB | BC A  BA | a B  CC | b C  AB | a x = baaba Tracing back the derivations, we obtain the parse tree

  26. Cocke-Younger-Kasami algorithm table cells Input: Grammar G in CNF, string x = x1…xk 1k … … • For cells in last rowIf there is a production A  xiPutA in table cell ii • For cells st in other rows If there is a production A  BC whereB is in cell sj and C is in cell jtPutA in cell st 23 12 22 kk 11 x1 x2 … xk s j t k 1 Cell ij remembers all possible derivations of substring xi…xj
