FBD Practice. 1. Book at rest on table. F N. Σ F y = ma y F N – F g = 0. F g. 2. Girl holding rope. T. Σ F y = ma y T – F g = 0. F g. 3. Free Falling Egg. Σ F y = ma y – F g = ma y. F g. 4. Book accelerating to right. Σ F y = ma y F N – F g = 0 Σ F x = ma x
