  1. Wireless CCTV Solution 2011.11.23

  2. ProjectDescription and Requirement • Total 20 camera points in the 15km x 9 km Area • Each camera point having multi megapixel IP cameras system • One camera site located 12km away • Two camera sites are at 9km range • 17 camera sites are within 3km range • Each Camera site using AV8185DN camera system, ( 2MP Camera x4) , require a minimum transmitting bandwidth: 6~8 Mbps (Brand: ArecontVision)

  3. ProjectDesign • Long Range ultra high capacity wireless backhaul bridge system is to transmit the camera site at 8 ~12km • Middle Range Super high capacity wireless bridge system is t transmitting the camera sites within 3km • Create independent wireless link for each sites • Camera Site no. 18 could be non line of sight, may request for repeater site if necessary (Repeating Site can be decide after site survey)

  4. Location map 9 km 15 km

  5. Location map Camera Site within 3km

  6. Location map Central Site Height 1365m Distance 8.5 km Distance 9 km Site 20 height 1305m Site 19 height 1305m Camera Site at 9km

  7. Location map Central Site Height 1365m Distance 12000m Hill 1400m Site 18 height 1305m Camera Site at 12km

  8. Location map Distance 8.5km Central Site Height 1365m Central Site Heigt 1365m Optional Repeating Point (1) Distance 12000m Distance 9.5 km Optional Repeating Point (2) Hill 1400m Site 18 height 1305m Site 18 height 1305m Camera Site No. 18 by link by repeater point (to be selected after servey)

  9. Benefit of ALCON Wireless System • Fast Deployment. • Range expandable. • Flexible of camera location changing. • Video / Audio transmitting. • Sensor /Alarm compatible. • Heavy Duty & All Weather Outdoor Design, especially for low temperature purpose.

  10. (Center Site )

  11. Equipment Description Wireless: • Alink-5X FDD: Long Range Super high capacity wireless backhaul bridge system for 15km • JPRO-5006P: Middle Range Super high capacity wireless bridge system for 3km Range. • Quantity: Alink-5X FDD x8 Units; JPRO-5006P x 34 Units

  12. Camera Site Table

  13. Camera Site table

  14. Alink-5X FDD

  15. JPRO-5006P

  16. Thank You C4U – ALCON www.cordless4u.com
