  1. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS D.Abate¹, G.Furini¹, S.Migliori¹, S.Pierattini¹ ENEA Research Centre, UTICT Bologna Italy {dante.abate, graziano.furini, silvio.migliori, samuele.pierattini}@enea.it XXIIIth International CIPA Symposium Prague, Czech Republic, September 12 - 16, 2011

  2. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it Distributing an high-definition 3D model on the Internet means: • Download the model • powerful hardware • appropriate navigation software • compromise solution

  3. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • Different resources and techniques allow visualizing 3D models on the web. The solutions proposed here are suitable for different users and different goals

  4. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • 3D Modeling Next Engine Desktop 3D Scanner Meshlab v1.3.0 (64bit) 3D Studio Max 9 UV modifier Acquasantiera, Medieval Museum, Bologna Acquasantiera3D Virtual Model

  5. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • Output • High-Definition Remote Rendering on a HPC infrastructure • 3D No Plugins (3DNP) • QuickTime VR Object (QTVR) • Virtual Reality Mark Up Language (VRML)

  6. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • High-Definition Remote Rendering on a HPC infrastructure

  7. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • This project uses the ICT infrastructure of ENEA-GRID and in particular the graphic cluster built up for CRESCO project • CRESCO HPC infrastructure: cluster divided into sections • total peak of 28 TFLOPS.

  8. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • Architecture • 3D Repository • Database Queries and Upload System • Client • Viewer

  9. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • DEMO

  10. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • 3D No Plugins (3DNP)

  11. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • 3D No Plugins (3DNP) • java script • able to upload an image series on a website • simulate a 3D view

  12. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it Python script for Blender

  13. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it 3D No Plugins Web Page Embedded

  14. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • QuickTime VR Objects (QTVR Object)

  15. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • QuickTime VR Objects (QTVR Object) • Apple's Movie Player • VR Worx suite

  16. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • Virtual Reality Mark Up Language (VRML)

  17. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • Virtual Reality Mark Up Language (VRML) • Download: • - high-definition model, 6 million polygons (490 MB) • - a low-definition model, 250 thousand polygons (32 MB) • the necessity to download the 3D model itself from the web and consequently the need of a high bandwidth connection; • the installation of a VRML viewer; • the loss of control on the 3D model and on its intellectual rights by the former owner when external users get in possession of it.

  18. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it

  19. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • CONCLUSIONS • The parameters intended to be preserved for this study were: • • real time interaction • • high-definition • • intellectual rights attached to the model

  20. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it

  21. MULTIPLE VISUALIZATION WEB APPROACH FOR CULTURAL HERITAGE OBJECTS www.utict.enea.it • Thank You for your Attention • Any Questions? • dante.abate@enea.it
