  1. Encoding

  2. Objectives • Understand basic encoding schemes • Understand basic framing schemes • Know bit stuffing • Ethernet lab introduction

  3. Non-Return to Zero (NRZ) • Problem: Consecutive 1s or 0s • Low signal (0) may be interpreted as no signal • High signal (1) leads to baseline wander • Unable to recover clock 0 0 1 0 1 1 1 1 0 1 0 0 0 0 1 0 Bits NRZ

  4. NRZI and Manchester • Non-return to Zero Inverted (NRZI): Make a transition from the current signal to encode a one, and stay at the current signal to encode a zero; • solves the problem of consecutive ones. • Manchester: Transmits the XOR of the NRZ encoded data and the clock; only 50% efficient.

  5. Example Manchester encoding allows the clocks to be synchronized NRZI eliminates consecutive 1s and baseline wander Consecutive zeros can still make it difficult to recover clock Bits 0 0 1 0 1 1 1 1 0 1 0 0 0 0 1 0 NRZ Clock Mancester NRZI

  6. 4B/5B • Problem: consecutive zeros • Idea: Every 4 bits of data is encoded in a 5-bit code, with the 5-bit codes selected to have no more than one leading 0 and no more than two trailing 0 (i.e., never get more than three consecutive 0s). • Resulting 5-bit codes are then transmitted using the NRZI encoding. Achieves 80% efficiency. • We already dealt with consecutive 1s with NRZI

  7. 4B/5B • At most one zero on each end • data • 1111 1000 0011 1101 • 4B/5B • 11101 10010 10101 11011 • NRZI • 0 10110 11100 11001 01101

  8. Framing

  9. Overview • Problem: Breaking sequence of bits into a frame • Must determine first and last bit of the frame • Typically implemented by network adapter • Adapter fetches (deposits) frames out of (into) host memory

  10. Four Approaches • Clock Based • fixed length frames, high reliability required • Sentinels • Special character to delineate frames, replace character in data stream • Character Count • Frame length at certain position in frame • Physical layer invalid codes • requires physical layer redundancy

  11. Byte-Oriented Protocols • Sentinel Approach • PPP protocol uses 0x7e=01111110 as the flag byte to delimit a frame • When a 0x7e is seen in the payload, it must be escaped to keep it from being seen as an end of frame 16 8 8 8 14 8 Addr Flag Prot Payload Checksum Flag Cont

  12. PPP Escape Character • To escape a character first send the escape character '}'. Then send the character to be escaped XORed with 001000002. To escape '~', send the escape character '}' followed by the ASCII value of '~' (011111102) XORed with 001000002.

  13. 8 16 16 8 Beginning Ending Header Body CRC Sequence Sequence Bit-Oriented Protocols • HDLC: High-Level Data Link Control (also SDLC and PPP) • Delineate frame with a special bit-sequence: 01111110

  14. Bit Stuffing • Sender: any time five consecutive 1s have been transmitted from the body of the message, insert a 0. • Receiver: should five consecutive 1s arrive, look at next bit(s): • if next bit is a 0: remove it • if next bits are 10: end-of-frame marker • if next bits are 11: error

  15. State Machine 0 1 0 1 0 1 0 1 0 1 Insert 0

  16. Bit stuffing Example • Original Data • 001111111000011111100 • Bit Stuffed • 00111110110000111110100 • Receiver • 0011111011000011111010001111110 End of Frame

  17. Ethernet

  18. Overview • History • Developed by Xerox PARC in mid-1970s • Roots in Aloha packet-radio network • Standardized by Xerox, DEC, and Intel in 1978 • Similar to IEEE 802.3 standard • Manchester encoding, synchronous transmission

  19. Frame Format Addresses: • Unique, 48-bit unicast address assigned to each adaptor • Example: 8:0:2b:e4:b1:2 • Broadcast: all 1s • Multicast: first bit is 1
