RACING

RACING. SKIS ALPIN RACING SUMMARY. MAJORS NEW PRODUCTS OFFER. New FIS Rules GS M&W 35m&30m, PIII 65mm Max New Plates offer All products, GS, SL & Juniors New GS WC Adultes Sizes 183-188-190-195 New Slalom Junior Sizes 126-132-139-146-150

hope
Télécharger la présentation

RACING

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. RACING

  2. SKIS ALPIN RACING SUMMARY MAJORS NEW PRODUCTS OFFER • New FIS Rules GS M&W 35m&30m, PIII 65mm Max • New Plates offer All products, GS, SL & Juniors • New GS WC Adultes Sizes 183-188-190-195 • New Slalom Junior Sizes 126-132-139-146-150 • New Race Maxflex Binding Din 12 • New SG Junior Sizes 205cm & 196cm • Modifications WC Racing Boots Lengh Boots (+3mm) Liner, lacets, Wider toe box, Softer padding, Lifter sole keyed • Modification WC Boots ZJ Pre-grind sole, 43mm Fis rules, 0° canting sole • Carry Over SL WC Adultes Plates excepted & Graphisme • Carry Over GS Junior Plates excepted & Graphisme • Carry Over Junior Boots RS WC 110, 90, 70, 65

  3. New FIS Rules(1/09/2012) FIS level skiers are Concerned for 13/14 LENGHT RADIUS >=65mm <=65mm >=65mm <=65mm Minimun Porfil Width

  4. Programme SKIS ALPIN RACING INTERFACES In order to stay on our statement of (n+1) relative Race WC products; we develop the same plates as current season in WC 1/ R20 WC Long: 589 mm Insert metal Bdings Mxf; Axial²WC; Demo (264-341mm) 2/ R20 Racing Long: 589 mm Insert Composite Bdings Mxf; Axial²WC; Demo (264-341mm) 3/ R20 Pro Long: 489 mm Insert Composite Bdings Axial²100; Axium100/70 (266-316) Axium Rental (254-335) 589mm R20 WC & RACING 489mm R20 Pro - 51 mm Vs IBox Height = 14mm Racing iBox 540mm • R20 WC & R20 Racing • R20 Pro • Interface Jr Short to Optimise with short skis ( From 150 to 126 in SL and 165 to 135 in GS). • Alu insert for adultes & Jr • Composite with Plastic Inserts for Jr & Tweeners • Compatible Mxf + Demo/ Speed Set + New 200Mxf Guide • « Tweeners » only with R20 Racing

  5. SPEED COURSE WC GSFis WC New GS adultes (DD) 4 news Sizes, New Fis Rules Sizes : 195-190 (35m) * 5 cm Tolerance for Fis Race 188-183 (30m) * 5 cm Tolerance for Fis Race 195cm & 188cm are news WC Fis Rules Skis, we needs skis with 5cm tolerances 188cm for mens and 183cm for womens. 190cm & 183cm are importantes for sponsored kids who needs those new Fis skis rules early season in case of qualifications for EC races…. Size 182cm in 25m radius, 175cm in 23 m radius and 170cm in 19m radius on « tweeners » categorie for specials prices points. • Structures (DD) 4 New Sizes : 195-190-188-183 & (DA) Sizes: 182-175-170 • New interface R20WC (Alu inserts) On sizes 183-188-190-195 • New interface R20 Racing (Composite inserts) On sizes 170-175-182 • « EarlyRise » Rocker ( 100/1,5mm) • Cascade Tips technologie. • New graphic

  6. TEAM OMEGLASS WC SL Junior • New Structure (AX) Sizes 126-132-139-146-150 • New Slant Nose Switchable • New interface R20 Pro (-50mm Vs R18 Racing & -109mm Vs R20 racing) • New boosted Structures : Titanal under the foot on sizes 139-146-150 • New « EarlyRise » Rocker • ( 100/1,5mm) on sizes 139-146-150 • ( 70/1mm) on sizes 126-132 • Rectangulaire ( under the foot) + Minicap shape ( extremities) • Wood core • Side Cut • 126 : 115 / 65 / 95 R = 8.4 m • 132 : 115 / 65 / 95.5 R = 9.2 m • 139 : 116 / 65 / 97 R = 9.9 m • 146 : 116 / 65 / 100 R = 10.2 m • 150 : 117 / 65 / 101 R = 10.6 m

  7. SPEED OMEGLASS WC SLFis WC • Structure AW • 3 New Sizes : 150-155-165 • Plastic tips 2012 • New interface R20WC ( Alu inserts ) Sizes 155-165 • New interface R20WC ( Composite inserts ) Sizes 150 • OBS! It will be round nose • « EarlyRise » Rocker ( 100/1,5mm) • New graphic Jan 2014

  8. TEAM COURSE WC GSJunior • Structure (DY), Sandwich construction. Sizes 124 – 130 – 135 – 144- 151 – 158 – 165. • New interface R20 Pro (-50mm Vs R18 Racing & -109mm Vs R20 racing) • Available on All sizes 135 up to 165 • Sizes 124 & 130 only available Flat • New technologie Cascade Tip & Early Rise Rocker for sizes 144-151-158- 165 • Rectangular side wal + Mini Cap for 158 -151 - 144 - 130 -124 • Full Rectangular structure + Chamfer on sizes 135 & 165 • F/M for size 165 / Ti for sizes 144-151-158 / 100% Reinforced FiberGlass • Wood core • Side cut: • 165 = (DA) F/M 109 – 66 - 89 R = >17 m Cascade/Rocker • 158 = Ti 104 – 65,5 - 86 R = >17 m Cascade/Rocker • 151 = Ti 101,5 – 65 – 84,5 R = 17 m Cascade/Rocker • 144 = Ti 101 – 64,5 – 84,4 R = 15,3m Cascade/Rocker • 135 = (DW)100% Fglass 102 – 65,5 - 84 R = 14,3 m • 130 = 100% Fglass 96 – 64 - 81 R = 14,2 m • 124 = 100% Fglass 93 – 63 – 79 R = 13,5 m

  9. TEAM OMEGLASS Multi–Event Junior • Structure AR • Sizes 125-130-135-140-145 • Rectangulaire WC construction • Fiber Glass + PU 145-140-135-130 cm • Fiber Glass + Wood 125 cm • Side Cut • 145 = 115- 64- 95 R = 10,6m • 140 = 112- 65- 95 R = 10,4m • 135 = 112- 65 – 95 R = 9,6 m • 130 = 110- 65 – 95 R = 9,1 m • 125 = 108 – 65 – 95 R = 8,5

  10. SPEED WC DH & SG SG & DH Junior & Adultes • Men SG new Fis Rules • 210cm ( Tolerance -5cm) = 205 cm • Raduis R= >45m • Women SG new Fis Rules • 205cm ( Tolerance -5cm) = 200m • Radius R= >40m • Rossignol Groupe WC Sizes 13/14 = • Men; Sizes 212 cm, R> 46m • Women; Sizes 209 cm, R>41m • Junior Offer : • Men & Women 205cm > 45m ( FIS) • Men & Women 196cm > 35m, PIII = 65cm Max ( Junior) • 186 cm Carry Over • 176 cm Stop ! • Men DH Fis Rules • 218cm R= >50m • Women DH Fis Rules • 216cm R= >50m

  11. SPEED ASSAULT WC WC & Team Ski Cross Skis Gamme de SX Dynastar Keep focus on our SX strategie, keep the best SX TEAM with Dynastar & Lange until Sochi Add 2 skis references ( Adultes & Junior), on existing structures, no investment ….with specificity graphics and Technics (Flat tips). • Structure ( DA ) 185 – 182 – 175 - 170 • New R20 Racing • Cascade Technologie • Rocker « Early Rise » • Starting Gate tip • Rectangulaire + Chamfer • Fiber/metal • Wood Core • Structure ( DY) 165 – 158 – 151- 144 • New R20 Pro • Cascade Technologie • Rocker « Early Rise » • Starting Gate tip • Rectangulaire + Chamfer • Fiber/metal • Wood Core SX Skis Club division, are more & more present on some ski resorts all over the world. Kids don’t want to get the same skis as Alpin Racers ….. Really good opportunity for Dynastar

  12. BINDING RACING SPX Racing 12 MAXFLEX The Maxflex technologie is well accepted world wide in the Racing. … Bindings is a very expensive segment & technologie and Rossignol Group is one of the major player ! No much competitors and Bindings is an opportunity for grow racing Turn over. Today the technologie MXF didn’t perform enought for Junior Racers ( With Mxf 200 & 150) in terms of Pricing and weight. The idea is to propose a lighter and sheaper version of the excisting technologie. The Price and the weight of the Mxf 15 is to hight for « Tweeners » price point. Solution : Using toe piece ACS4 (compare to BRLC) we gain in cost and reduce the total weight of 300 grs/pairs !!

  13. BINDING RACING SPX Racing 12 MAXFLEX New AFD ACS4 Composite toe piece • Composite toe piece for lightness and comfort (ACS4 Vs BRLC) • Weight improvement : - 300 g on toe pieces • Better weapon against Salomon & Atomic X12 for the Race Junior Program • Estimated quantities = 6 000 pairs / year • Street Price 219€ Vs 249€ MXF 150 and same price as Axial² WC 140

  14. Lange 13-14 • Objectives: WC: • Align with racing dpt developments • Decrease bootfitting time (ZJ) • Rationalize where possible Juniors: • Carry over RS as it is benchmark in the market

  15. New WC mold length • Longer soles to guarantee safety when the boot is pushed • Trend to push boots in WC • Unconventional and dangerous binding releases • Company policy: grinding to have ISO compliant boots after pushing 3 mm longer soles on all sizes. Pushing and grinding when required Soles table by size: NOTE: NO pushing is allowed out of LANGE Racing DPT Additional grinding on toe

  16. New WC liner • Wider lycra toe box: roomier toe box especially after bootfitting • New softer tongue padding: better instep to shinbone wrapping • Thinner upper and padding: more volume • New stronger eyelets: more durable • Flat additional sole in the box to create full size

  17. New WC mold length RACING SKI BOOTS 13-14 • WC Boots Objectives: • Lifter easier assemble • New 3mm Lifter Sole + Keyed

  18. ZJ specifics • Jr liner: same improvemnets as ZC/B/A + softer padding • Ground sole: • ISO sole: ready to step into bindings 43 mm FIS • 0° cant sole • Materials and rear cut: • size 225-245: softer material than ZA, no rear cut, print on shell ZJ • size 255-295: same material as ZA, rear cut, print on shell ZJ 43mm Fis Norms Heel and toe

  19. 13-14 WC range • WC Boots Objectives: • - Reduce Sizes SKU ( ZC only)

  20. 13-14 RS range RS 140 Last: 97mm Liner: WC fit, lacing system Buckles: 4 Alu micro, screwed Velcro: Cam lock Size: 240-305 MP RS 130 Last: 97mm Liner: Pro fit Buckles: 4 Alu micro, screwed Velcro: 50 mm Size: 220-305 MP RS 130 wide Last: 100mm Liner: Control fit Buckles: 4 Alu micro Velcro: 50 mm Size: 240-305 MP

  21. 13-14 RS junior range RS 110 sc Last: 97mm Liner: Control fit Buckles: 4 Race Alu micro Velcro: 40 mm Size: 210-285 MP RS 90sc Last: 97mm Liner: Jr race fit Buckles: 4 Alu micro Velcro: 40 mm Size: 210-285 MP RS 70sc Last: 97mm Liner: Jr race fit Buckles: 4 Alu micro Velcro: 28 mm Size: 210-285 MP RSj65 Last: junior Liner: jr fit Buckles: 4 Alu micro Velcro: 28 mm Size: 220-275 MP RESTYLED SC = Short Cuff
