  1. Berkeley Nucleonics Instrumentation Since 1963…

  2. Management Team • David Brown, President • 15 Years, BA Management • Mel Brown, Director of Finance • 45 Years, MS Electrical Engineering • John Yee, Director of T&M Application • 35 Years, MS Electrical Engineering • Jim McQuaid, Director of Radiation Detection Applications • 10 Years, BS Nuclear Physics • Robert Corsetti, Director of Sales • 5 Years, BS Neuroscience

  3. Test and Measurement • Industry Leading Specifications • Amp Stability, Interface Options, Low Jitter • Widest Range of Signal Generators • High Voltage, NIM, Optical, TTL, ARB, Pulse • Measurement Instruments • Scope, Digital Multimeter, Frequency Counter • Price / Performance • Channel Cost, Feature-Rich

  4. Nuclear Detection • Radiation Detection Pagers and Identifiers • Spectroscopic Portal Monitors • Accredited Training Programs • Reachback and Program Support • US DoD, US DHS, Health Physics Certified • Domestic and International Support Offices

  5. Life Sciences • Video Microscope • Feature-Rich Microscope • Academic, Research, Investigative, Industrial • High Voltage Stimulators • Neuroscience Research

  6. Flagship Products Test and Measurement NIM Pulsers and Power Supplies Radiation Detection Special Function and Custom Development Scanning Microscopes

  7. Model PB-5 NIM Precision Pulse Generator

  8. MODEL PB-5 Summary The Model PB-5 provides unprecedented performance in a precision pulse generator. It includes a full-featured, highly flexible ramp generator, parameter programmability and flash memory. As a precision pulse generator, the PB-5 surpasses or equals all existing designs in the important performance areas of resolution, linearity and stability. The pulse repetition rates, which are variable over a broad range, go up to 0.5 MHz. The higher rates are required when testing for MCA and PHA linearity because of the high number of data points required for a statistically valid test. The built-in ramp generator allows you to control ramp duration, the number of ramps and ramp limits. Now you can test the entire range of your system or just a portion of that range. This ramp generator and precision pulse generator combination allows you to tackle the most demanding applications.

  9. MODEL PB-5 Features •  Tail, Ramp, Built-In Pulse Function •  Multiple operational modes for linearity checks •  Higher rates for faster MCA testing •  Fast automated testing of nuclear components •  Completely programmable using RS-232 •  Built-in ramp generator for sweeps and automated tests •  Excellent linearity, stability and resolution (PPB)

  10. Model PB-5 Features and Applications •  Temperature Stability +/-5ppm (world's best), allows testing of circuits, vulnerability tests, QC •  Pulse Types: Flat Top or Tail Pulse for Radiation Simulation Testing •  Remote: RS-232 and Labview Support, PB-5 User Software also included •  Rise Time: Adjustable from front panel or remote •  Fall Time (Decay): Adjustable •  Amplitude Resolution: 155uV steps
