  1. WSUS, MU and WU oh my! SMB Technology Network Susan Bradley, Patchaholic

  2. We’re going to assume • You’ve done your homework • http://www.vladville.com/2005/12/sbs-show-8-patch-management-with-susan.html • Think risk management

  3. WU and MU The basics of Windows and Microsoft Update

  4. WU versus MU • Windows Update • Just patches Windows • http://update.microsoft.com/windowsupdate • Microsoft update • http://update.microsoft.com/microsoftupdate • Patches [at this time] • Windows • Office • Exchange • More to come • Engine is the same - Troubleshoot the same

  5. MU is optional • Opt in to MU

  6. MU steps • Accept EULA • Need to install software to get it to use it • Downloads activeX files • \Windows\Downloaded Program Files • The following ActiveX controls will be installed: • MUWebControl Class • WUWebControl Class

  7. Is it safe? • If first visit will get ‘authenticode’ prompt

  8. Checking for updates

  9. Two options to install • Express Install: This option is recommended and provides the easiest method for installing high priority updates. • Custom Install: This option enables a user to select which specific updates are installed.

  10. Better ‘history’ interface

  11. Revert to WU • Go back • Click on Change settings • Check the box

  12. Test connectivity • https://update.microsoft.com/v6/ClientWebService • If you see this: • You are good to go

  13. File updated • Windows Genuine Advantage control • Windows Installer 3.1 • Background Intelligent Transfer Service (BITS) update

  14. Auto updates options • Download • Will allow you to install them at a later time

  15. But don’t forget the help files

  16. Troubleshooting • SUS Support file • http://download.microsoft.com/download/b/b/1/bb139fcb-4aac-4fe5-a579-30b0bd915706/MPSRPT_SUS.EXE • Operating System and Service Pack Level • Right-click My Computer and select Properties • Internet Explorer Version and Service Pack Level • Check the Help > About interface in Internet Explorer

  17. Items to gather for troubleshooting • Internet Explorer Cipher Strength • Check the Help > About interface in Internet Explorer • Network Configuration (local area network [LAN], DSL, Firewall, Etc) • Tried using the Windows Update v6 Troubleshooter? • Has anything changed on the machine recently?

  18. In the SUS reporting tool • Windows Update logs (both Version 4 and Version 6) • ReportingEvents.log this shows what error was returned to our servers. • Internet Explorer Registry key data to help with proxy or access issues • Windows Update Registry key to help with policy and Automatic Updates issues • Service Output file to show what services are running on the machine and which are stopped.

  19. SUS reporting tool • Application and System event logs • BITS Admin log to help investigate download issues • Update.exe installation logs to help with installation failure issues • Setuplog to help investigate installation issues • Setupapi.log to help investigate driver installation issues

  20. Log files • Start, then click Run, type WINDOWSUPDATE.LOG and then click OK. • windows update.log • Is the v4 version • WindowsUpdate.log • Is the v6 version

  21. Common errors • 0x80072EE2 – 0x80072F78 – 0x80072F76 – 0x80072EFD • 836941 - You receive an "Error 0x80072EE2" or "Error 0x80072EFD" error message when you try to use Windows Update • Add Windows Update Web sites to the Trusted Sites list

  22. Common Errors • 0x80070424 • How to troubleshoot problems accessing secure Web pages with Internet Explorer 6 Service Pack 2 (870700) • This Windows Update error code is caused by unregistered DLL files for Windows Update or Internet Explorer. On Windows XP SP2 and later this may be resolved using the “iexplore /rereg” command.

  23. Common Errors • 0x80244001/0x800A01AD • These Windows Update error codes can be caused by a damaged Windows XP XML subsystem. The first step to take is to reregister this component using the command “regsvr32 msxml3.dll”. If this does not resolve the issue, check for more recently updated MSXML Parser and MSXML components from the following link:http://www.microsoft.com/downloads/results.aspx?productID=&freetext=msxml&DisplayLang=en

  24. Common Errors • When accessing the Update site, you receive the 0x800A01AE error. • This issue may happen if the current session of Internet Explorer has cached an older version of Wuapi.dll • Re-register the Windows Update DLL with the commands below • Click Start, click Run, type cmd, and then click OK. • Type the following commands. Press ENTER after each command.regsvr32 wuapi.dllregsvr32 wuaueng.dllregsvr32 wuaueng1.dllregsvr32 wucltui.dllregsvr32 wups.dllregsvr32 wups2.dllregsvr32 wuweb.dll

  25. Common Errors • 0x80248011 • This Windows Update error code is normally related to inconsistent or damaged information in the c:\windows\softwaredistribution folder. Stopping the Automatic Updates service then renaming the c:\windows\softwaredistribution folder to SDOLD then restarting the Automatic Updates service normally is the fix for this issue.Note: Renaming this folder will clear the display of previous successful and failed updates.

  26. Common Errors • 0x800B0001 • This Windows Update error code is related to 3 particular DLL files that are not registered in windows correctly. Registering the following files with REGSVR32 normally fixes this issue: • Softpub.dll • Mssip32.dll • Initpki.dll

  27. Common Errors • 0x8024402C • This Windows Update error can be caused by a damaged installation of BITS and corrupted information in the SoftwareDistribution folder. The solution is normally to re-download the BITS updates (KB883357 and KB842773) from the Microsoft.com website, then stop the Automatic Updates service and rename the SoftwareDistribution folder to SDOLD. Reboot the computer and return to Windows Update.

  28. Diagnose tools • Look at WindowsUpdate.log from the bottom up • To enable site tracing for a single visit to the Windows Update site, add “&dev=true” to the end of the URL, as in the example below:http://update.microsoft.com/windowsupdate/v6/default.aspx?ln=en&dev=true

  29. Troubleshooting • Most third party firewalls such as Norton Personal Firewall block SVCHOST (Generic Host Process Win32) communication by default. This can cause issues with Windows Update as SVCHOST communication is required by the Windows Update client to connect to the Windows Update Servers on the internet.

  30. WSUS basics Are you ready to patch?

  31. WSUS • Patches the same pieces as MU • More to come • Clients ‘check in’ with server • Not push • Pull • Can force a push if need be via scripting • http://www.microsoft.com/downloads/details.aspx?FamilyId=3BA03939-A5A9-407B-A4B0-1290BA5182F8&displaylang=en

  32. WSUS installation • Install on server • Will default go on port 8530 • On standard loads up a MSDE instance • Remember …clients may need in registry http://servername:8530 or Group • Beginners guide to WSUS • http://uphold2001.brinkster.net/vbshf/wsus/wsus_faq.htm

  33. WSUS issues • Clients may not check in • Manually put in registry • Sync process takes a long time • About 24 hours if you pull down all files

  34. Install • Double-click the installer file WSUSSetup.exe. • Note: • The latest version of WSUSSetup.exe is available on the Microsoft Web site for Windows Server Update Services at http://go.microsoft.com/fwlink/?LinkId=47374. • 2. On the Welcome page of the wizard, click Next. • 3. Read the terms of the license agreement carefully, click I accept the terms of the License Agreement, and then click Next. • 4. On the Select Update Source page, you can specify where clients get updates. If you select the Store updates locally check box, updates are stored on the WSUS server and you select a location in the file system to store updates. If you do not store updates locally, client computers connect to Microsoft Update to get approved updates. • Keep the default options, and click Next. • Select Update Source Page

  35. Install • Needs a LOT of space • 6 GB

  36. WMSDE is default • On the Database Options page, you select the software used to manage the WSUS database. By default, WSUS Setup offers to install WMSDE if the computer you are installing to runs Windows Server 2003. • If you cannot use WMSDE, you must provide a SQL Server instance for WSUS to use, by clicking Use an existing database server on this computer and typing the instance name in the SQL instance name box. For more information about database software options besides WMSDE, see the “Deploying Microsoft Windows Server Update Services” white paper. • Keep the default options, and click Next. • Database Options Page

  37. WSUS install Now up to 8 gigs

  38. WSUS on SBS will chose 8530

  39. On premium – set up the rule [pre done on SBS] • http://windowsupdate.microsoft.com • http://*.windowsupdate.microsoft.com • https://*.windowsupdate.microsoft.com • http://*.update.microsoft.com • https://*.update.microsoft.com • http://*.windowsupdate.com • http://download.windowsupdate.com • http://download.microsoft.com • http://*.download.windowsupdate.com • http://wustat.windows.com • http://ntservicepack.microsoft.com

  40. Proxy settings • On the WSUS console toolbar, click Options, and then click Synchronization Options. • 2. In the Proxy server box, select the Use a proxy server when synchronizing check box, and then type the proxy server name and port number (port 80 by default) in the corresponding boxes. • 3. If you want to connect to the proxy server by using specific user credentials, select the Use user credentials to connect to the proxy server check box, and then type the user name, domain, and password of the user in the corresponding boxes. If you want to enable basic authentication for the user connecting to the proxy server, select the Allow basic authentication (password in clear text) check box. • 4. Under Tasks, click Save settings, and then click OK in the confirmation dialog box.

  41. To get to WSUS • Admin tools • http://servername:8530/WSUSAdmin/

  42. WSUS sync

  43. WSUS console Missing the computers!

  44. Adding the WUAU template • 1. In Group Policy Object Editor, click either of the Administrative Templates nodes. • 2. On the Action menu, click Add/Remove Templates. • 3. Click Add. • 4. In the Policy Templates dialog box, click wuau.adm, and then click Open. • 5. In the Add/Remove Templates dialog box, click Close.

  45. Getting the clients to ‘check in’ • In Group Policy Object Editor, expand Computer Configuration, expand Administrative Templates, expand Windows Components, and then click Windows Update. • In the details pane, click Specify Intranet Microsoft update service location. • Type the HTTP URL of the same WSUS server in both Set the intranet update service for detecting updates and Set the intranet statistics server. For example, type http://servername:8530 in both text boxes, where servername is the name of your WSUS server. • Click OK, and then configure the behavior of Automatic Updates

  46. Known issue of ‘compression’ • Get the hotfix • Or ‘kick them’ to check into the system

  47. Assigning groups • Two methods • Group policy • Move computers

  48. GPMC • Add a new policy

  49. Editing Group policy • Why NOT edit an existing one? • SP redeployed these and would blow off your customizations • Add new • Right mouse click on edit

  50. Drill down to the setting • Computer config • Admin • Components • Windows Update
