  1. 我國6Bone規劃及建置經驗 中華電信研究所 前瞻技術研究室 嚴劍琴 中華民國八十九年十月十九日

  2. Contents • IPv6 通訊協定簡介 • Worldwide Testbed -- 6Bone • IPv6 推廣現況 • 國外 IPv6 發展現況 • 我國 IPv6 發展及建置經驗 • 總結

  3. IPv6 通訊協定簡介

  4. Introduction • Driving motivation: Limitation imposed by the 32-bit address in IPv4 • NAT(Network Access Translator) is a short-term solution but not the best • To provide a platform for new Internet Functionality Improvement rather than derivative of IPv4 • Addressing Capacity, Routing Capacity, Support for QoS, Auto-configuration, Security inter-operability and so on • Related IETF working Groups • IPng (ipngwg) working group under Internet Area • IPng Transition (ngtrans) working group under Operations and Management Area

  5. IPv6 vs. IPv4 Packet Data Unit maximum 65535 octets minimum 20 octets IPv4 Header Data Field IPv4 PDU maximum 65535 octets Fixed 40 octets 0 or more IPv6 Header Extension Header Extension Header Transport-level PDU IPv6 PDU

  6. IPv4 vs. IPv6 Header IPv4 Packet Header IPv6 Packet Header Service Type Traffic Class Ver IHL Total Length Ver Flow Label Next Header Hop Limit Identification Flags Offset Payload Length TTL Protocol Header Checksum Source Address Source Address Destination Address Options + Padding 32 bits Destination Address

  7. IPv6 Extension Headers (1/2) • Hop-by-hop options header • Routing header • Fragment header • Authentication header • Encapsulating security payload header • Destination options header 40 octets 0 or more IPv6 Header Extension Header Extension Header Transport-level PDU IPv6 PDU general form

  8. IPv6 Extension Headers (2/2) Octets: • IPv6 specification recommended order: • IPv6 header • Hop-by-hop options header • Destination options header • Routing header • Fragment header • Authentication header • Encapsulation security payload header • Destination options header 40 IPv6 header Variable Hop-by-hop options header Variable Routing header 8 Fragment header Variable Authentication header Variable Encap security payload header Variable Destination options header 20 (optional variable part) TCP header Variable Application data = Next header field IPv6 packet with all extension headers

  9. Packet Format of IPv6 vs. IPv4 • Header size becomes fixed • Option fields are replaced by extension headers • hop-by-hop, routing header, fragment header, authentication header, encapsulating security payload, destination options header • Decreased number of field, increased total size • Six fields are suppressed • IP header length, type of service, identification, flags, fragment offset, header checksum • Three fields are renamed • Total length: payload length • Protocol type: next header • Time to live: hop limit • Two fields are added • traffic class, flow label

  10. Addressing Features • Address Capacity • 32-bit address  128-bit address • Give brand-new start for address aggregation (CIDR, Classless Inter-Domain Routing) • Addressing Capability • Unicast, Anycast and Multicast • Anycast address • More efficient routing (intermediate nodes) • More efficient access to mirrored servers (destination nodes) • Single interface with multiple address • support renumbering in a nondisruptive manner

  11. Routing Capability • Size of packet header is fixed • Revised option mechanism • Most bypassed by routers • Hint in header (Routing option) • The number of fields in packet header is reduced • 12 fixed + options 8 fixed • Suppressed: header length, type of service, identification, flag, fragment offset, header checksum • Modified: length, protocol type, time to live • Added: priority, flow label • Packet fragmentation is not allowed by routers • Path MTU (Max. Transfer Units) discovery protocol • At least 1280 octets

  12. More Flexible for QoS Mechanism • New “Flow” concept • Defined by source address + flow label • Routing only on flow DA, priority, hop-by-hop, routing option must be the same on a given flow • When used with RSVP • DA+SA(+DP+SP) SA+flow label • Solve layer violation with routers • Still work with encryption • Can be used with other Reservation Procedures • Define QoS of a flow in hop-by-hop options

  13. Other Improvements • More flexible Autoconfiguration • Stateless autoconfiguration (New) • Stateful autoconfiguration (V6 version of DHCP, Dynamic Host Configuration Protocol) • Improved Support for Security, Mobility and ARP, etc. • Provide inter-operability • more efficient process

  14. Transition Mechanism (1/2) • Simple Internet Transition (SIT) • Dual-stack strategies • IPv6-over-IPv4 Tunneling • Important features • Incremental upgrade and deployment • Minimal upgrade dependencies • Easy Addressing • Low start-up costs • Tunneling techniques • Configured Tunneling • Tunnel end point address should be determined from configuration information on tunnel starting point • For Host-to-Router and Router-to-Router tunnel

  15. 0:0:0:0:0:0 IPv4 Address Transition Mechanism (2/2) • Automatic Tunneling • IPv4-compatible IPv6 address is used as IPv6 destination address • For Host-to-Host and Router-to-Host tunnel Dual-stack node Dual-stack node IPv4 Tunnel Dual-stack node IPv6 H Payload IPv6 H Payload IPv4 H IPv6 H Payload

  16. Worldwide Testbed - 6Bone

  17. 6Bone (1/2) • A worldwide testbed : http://www.6bone.net/ • Virtual network • Layered on IPv4-based Internet to support routing of IPv6 packets • To provide the early policies and procedures for IPv6 transport • Operational from June/July on 1996 • Will be replaced in a transparent way by • Production ISP • User network IPv6 Internet-wide transport • Addressing Architecture • global aggregatable unicast address • TLA 0x1FFE is assigned to 6Bone by IANA for testing

  18. 6Bone (2/2) • Three types of sites • Backbone Site (pTLA sites) • With its own pTLA assignments • To aggregate routing for other transit sites or leaf sites • With BGP4+ peering with a couple of backbone sites • Transit Site • To aggregate routing for leaf sites • with at least one BGP4+ peering with its backbone site • Leaf Site • With static route peering

  19. IPv6 island IPv6 island IPv6 island IPv6 island IPv6 island 6Bone Architecture Backbone Site Backbone Site Leaf Site Tunnel (BGP4+) Tunnel (BGP4+) IPv4 network Tunnel (Static) Backbone Site Transit Site

  20. Logical Structure of the 6Bone Network

  21. Growth of the 6Bone Sites

  22. 6Bone Test Address 128 001 TLA RES NLA SLA Interface ID 001 0x1ffe NLA1 NLA2 SLA Interface ID 13 8 24 16 64 3FFE:3600::/24 CHT-TL

  23. How to join the 6bone • EQUIPMENT NEEDS • ROUTERS • WORKSTATIONS • FINDING A POINT ON THE 6BONE TO ATTACH TO • MAKING 6BONE REGISTRY ENTRIES FOR YOUR SITE • CONFIGURING YOUR IPv6 ROUTER AND WORKSTATION • GETTING IPv6 ADDRESSES AND BUILDING YOUR TUNNEL TO THE 6BONE • DNS SUPPORT

  24. IPv6 推廣現況

  25. IPv6相關組織 (1/2) • Organizations are set up to promote the deployment of IPv6 network • 6REN • CAIRN, CANARIE, CERNET, CHT, DANTE, ESnet, FREEnet, Internet2, NTT, Sprint, vBNS, WIDE, ... • IPv6 Forum (Funding members: 51, General members:28) • IANA begins to delegate the IPv6 address space to the ARIN 、 RIPE NCC and APNIC RIRs (regional Internet registries) since July 1999 • APNIC • CONNECT-AU、 WIDE-JP 、 NUS-SG、 KIX-KR 、 JENS-JP 、 NTT-JP 、 HINET-TW 、 ... • ARIN • ESNET-V6 、 ARIN、 VBNS 、 CANET3

  26. IPv6相關組織 (2/2) • RIPE • DE-SPACE 、 EU-UUNET 、 UK-BT 、 CH-SWITCH 、 AT-ACONET 、 UK-JANET 、 DE-DFN 、 NL-SURFNET 、 RU-FREENET 、... • Emerging Products and Equipment • Router • Telebit、Bay、Cisco (Beta) 、Hitachi (NR60) …. • Host • Window NT 、Linux 、Sun Solaris 、HP …..

  27. 6REN (1/2) • 6REN (IPv6 Research & Education Network) is established in October of 1998 • Primary Goals • To provide production quality IPv6 packet delivery services • To develop operational procedures for IPv6 networks • To promote the deployment of IPv6 networks • To enable early IPv6-ready application testing and deployment • A voluntary coordination without fee • Participates must use production IPv6 addresses and provide production quality IPv6 service. • The “6Tap” project sponsored by Canarie and ESnet • To facilitate the easy interconnection of 6REN participants • Over ATM interconnections

  28. 6REN (2/2) native IPv6 BGP peering sessions Native IPv6 peers 6TAP router ATM switch for IPv6 @star tap Wide area ATM links from StarTAP participants worldwide Local OC3 link Native IPv6 peer ATM PVCs pre-configured

  29. IPv6 Forum • Established in April 1999 by Internet vendors and research and education networks • IBM, Cisco, Compaq, HP, Sun, MCIWorldcom, Microsoft, UUNET, Telebit Communications, Thomson CSF, Case, Acer, NTT, Hitachi, French G6, 6REN, WIDE of Japan, ... • To dramatically improve the market and user awareness of IPv6 • by providing world-wide, equitable access to knowledge and technology • to work closely with the Internet Engineering Task Force (IETF) • The membership fee per organization is US$ 2500, per annum.

  30. Production IPv6 Address (1/2) • Assign sub-TLA to applicants • Slow Start Mechanism are used • To issue small address blocks until the provider can show an immediate requirement for larger blocks. • The first allocation to a TLA registry will be a 2001::/35 block • Right now, in Bootstrap Phase FP TLA Res NLA SLA Interface ID 8 24 16 13 64 001 0x0001 sub-TLA Res NLA SLA Interface ID 16 13 13 13 6 64

  31. Production IPv6 Address (2/2) • Examples of assigned sub-TLAs • APNIC • ETRI-KRNIC-KR-19991124 2001:230::/35 • NTT-JP-19990922 2001:218::/35 • HINET-TW-20000208 2001:238::/35 • CONNECT-CC-AU 2001:0210::/35 • ARIN • ESNET-V6 2001:0400::/35 • ARIN-001 2001:0400::/23 • VBNS-IPV6 2001:0408::/35 • CANET3-IPV6 2001:0410::/35 • RIPE-NCC • DE-SPACE-19990812 2001:0608::/35 • UK-BT-19990903 2001:0618::/35 • CH-SWITCH-19990903 2001:0620::/35 • AT-ACONET-19990920 2001:0628::/35

  32. 國外IPv6發展現況

  33. WIDE v6 Working Group • WIDE-sTLA internal structure • <2><---0----0----1> <-0----2----0--><-RES-><---------------> • <2><---0----0----1> <-0----2----0---0---0-><-----WIDE------> • 0010|0000|0000|0001|0000|0010|0000|0000|0000|0000|0000|0000| • <-APNIC> <NLA1><--NLA2---> • /16 /24 /32 /35 /40 /48 • BackBone Infrastructure • 2001:200:0:XX::/48 • All WIDE POPs are allocated this address w/ XX(POP#) • for WIDE BoneBone Infrastructure. • NLA1(Next Level Aggregator 1) • 2001:200:[0-1]x00::/40 • x=1->f (0 is reservation for WIDE BackBone) • WIDE-NLA1 2001:200:0100::/40 • allocate WIDE-NLA2(/48) for other organizations. • POP(Point Of Presence) • 5bit boundary • 2001:200:01yy::/45 • yy=0->f • NLA2 • 2001:200:01yz::/48 • y:POP number • z:Orgnizatrion ID[0-8](identify in one POP)

  34. WIDE v6 Working Group • [WIDE INTERNAL] • WIDE-CAMP 2001:0200:0000:ff00::/56 2000/06/26 • NSPIXP6 2001:0200:0000:1800::/64 1999/10/ • SFC-U-TOKYO-VLAN 2001:0200:0000:1c04::/64 2000/06/12 • [NLA2] • org name ipv6 address connect-pop link issue date • ================ ================ ============ ======== ========== • nui-org-net 2001:0200:0140::/48 komatsu tunnel 2000/01/14 • SonyCSL-NET 2001:0200:0120::/48 otemachi ATM 2000/01/14 • Ehime Univ. 2001:0200:0150::/48 hiroshima tunnel 2000/02/02 • Tokyo Univ. 2001:0200:0180::/48 nezu tunnel 2000/02/02 • Uwajima Internet Community 2001:0200:0121::/48 otemachi tunnel 2000/02/03 • Uwajima Municipal Hospital 2001:0200:0122::/48 otemachi tunnel 2000/02/03 • N+I Shownet 2001:0200:0123::/48 otemachi ether 2000/02/08 • JSAT-NET 2001:0200:0124::/48 otemachi ATM 2000/03/30 • WASEDA-NET 2001:0200:0125::/48 otemachi tunnel 2000/04/09 • Tokyo University of Technology 2001:0200:01a8::/48 hachioji tunnel 2000/04/19 • TNT-WIDE 2001:0200:0148::/48 kyoto ether 2000/06/09 • YDC-WIDE-IPV6-01 2001:0200:0100::/48 Tokyo Serial 2000/07/24 • NABECHAN.ORG 2001:0200:0126::/48 otemachi tunnel 2000/07/24 • RESEARCHLAB-NET 2001:0200:0127::/48 otemachi tunnel 2000/07/26 • [NLA1] • org name ipv6 address connect-pop link issue date db • ================ ================ ============ ======== ========== == • WIDE-NLA1 2001:0200:0100::/40 otemachi 2001/01/14 yes • ITJIT-NET 2001:0200:0200::/40 otemachi tunnel 2000/01/14 yes • IMASY 2001:0200:0300::/40 otemachi tunnel 2000/01/20 yes • NTTv6Net 2001:0200:0400::/40 tokyo T1 2000/01/25 no • INTEC 2001:0200:0500::/40 otemachi ether 2000/02/09 no • KDD-Labs 2001:0200:0600::/40 otemachi tunnel 2000/02/09 yes • NTT-MY 2001:0200:0700::/40 otemachi ATM 2000/02/21 yes • AIII 2001:0200:0800::/40 Nara Ether 2000/04/18 yes • APAN 2001:0200:0900::/40 otemachi ATM 2000/05/11 yes

  35. ETRI Advance Standards Research Team • Head : Kim, Yong-Jin • Reserch Issues • IPv4/IPv6 Next Generation Internet Address Translator • Standardization planning of Next Generation Mobile Communications • Standardization of Next Generation Internet Protocols • Related Information • Research Results • IPv6 Forum Korea • ITU-T SG13/Q.20 • Simulation Study Group • OSIA TG-Deployment • http://pec.etri.re.kr/index2.htm

  36. NTT-JP

  37. NTT-JP

  38. IIJ–IPv6 Trial Service

  39. IIJ–IPv6 Trial Service

  40. CERNET IPv6 Testbed • 預計2000年底將實現的結構

  41. CERNET IPv6 Testbed • 試驗床的内部實現拓樸(1)

  42. CERNET IPv6 Testbed • 試驗床的内部實現拓樸(2)

  43. ESNET-V6 • ESnet is working to make this transition from IPv4 to IPv6 as seemless as possible for our customers. We are one of the few Internet Service Providers to be a participate in the 6Bone backbone. Our engineering staff is also testing many of the network services we are all familiar in an IPv6 environment. • 6Bone • 6Tap • 6ren • Whois Server • Tunnel Registration • Address Delegation • http://www.es.net/hypertext/welcome/pr/ipv6.html

  44. VBNS-IPV6

  45. CA*net3 IPv6

  46. UK-BT NAT-PT Project • BT Labs have developed an implementation of NAT-PT designed to run on a router running the FreeBSD operating system and using the KAME IPv6 stack. • We are making this implementation available for download to promote its use as an IPv4/IPv6 interoperability mechanism. • http://www.labs.bt.com/projects/nat_pt/index.htm

  47. SWITCH IPv6 Pilot • SWITCH has been assigned an experimental pseudo-TLA (pTLA) for use on the 6bone. The prefix of this pTLA is 3ffe:2000::/24. The following prefixes under the pTLA have been assigned to sites that are connected to the 6bone via SWITCH: • 3ffe:2000:0000::/48 SWITCH • 3ffe:2000:0400::/48 ETHZ • 3ffe:2010:0000::/48 EPFL • 3ffe:2000:0c00::/48 UniBE • 3ffe:2022:0001::/48 ISBE • 3ffe:2000:1000::/48 TLAB-CHUR • 3ffe:2022:0003::/48 FH-Aargau • 3ffe:2022:f000::/48 TELEPORT • 3ffe:2024:0001::/48 TK-LINZ • 3ffe:2028:0001::/48 SIMMCOMM • 3ffe:2028:1000::/36 SOLNET • 3ffe:202a:0001::/48 SIMULTAN • 3ffe:202a:0002::/48 TILINK

  48. UK-JANET • The JANET Managed Bandwidth Service, initial trials are now taking place in the UK. Southampton has a 512Kbit MBS link to the European TF-TANT network. • Southampton, UCL and Lancaster are embarking on a triangular IPv6 network over JANET, a project which should lead to IPv6 connectivity to Internet 2. • Numerous router and workstation/OS vendors already support IPv6; these trials will report on interoperability issues and application developments. • http://www.ja.net/conferences/networkshop/abstracts/ipv6.html

  49. DE-DFN JOIN Project

  50. Euronet*Internet IPv6 Experimental HTTP-Server
