  1. Using WebUtil to Interact with the Client

  2. Objectives • After completing this lesson, you should be able to do the following: • Describe the benefits of the WebUtil utility • Integrate WebUtil into a form • Use WebUtil to interact with a client machine

  3. Formsbuilt-Ins WebUtilbuilt-Ins WebUtil Overview • WebUtil is a utility that: • Enables you to provide client-side functionality on Win32 clients • Consists of: • Java classes • Forms objects • PL/SQL library

  4. Benefits of the WebUtil Utility • Why use WebUtil? • Developer has only to code in PL/SQL (no Java knowledge required) • Free download (part of Forms 10g in a patch set) • Easy to integrate into a Forms application • Extensible • WebUtil provides: • Client-server parity APIs • Client-server added value functions • Public functions • Utility functions • Internal functions

  5. Integrating WebUtil into a Form Step 1:Attach the WEBUTIL library. Library

  6. Integrating WebUtil into a Form Step 2:Subclass the WEBUTIL object group. Alert ObjectLibrary Items Objectgroup Canvas Window

  7. When to Use WebUtil Functionality Pre-FormWhen-New-Form-Instance When-New-Block-Instance (first block) Form starts JavaBeans are instantiated Any trigger after form startsand while form is running

  8. Forms Built-Ins / Packages HOST GET_FILE_NAME READ_IMAGE_FILE WRITE_IMAGE_FILE OLE2 TEXT_IO TOOL_ENV WebUtil Equivalents CLIENT_HOST CLIENT_GET_FILE_NAME CLIENT_IMAGE.READ (WRITE)_IMAGE_FILE CLIENT_OLE2 CLIENT_TEXT_IO CLIENT_TOOL_ENV Interacting with the Client

  9. Example: Opening a File Dialog on the Client DECLARE v_file VARCHAR2(250):=CLIENT_GET_FILE_NAME('','', 'Gif Files|*.gif|JPEG Files|*.jpg|', 'Select a photo to upload',open_file,TRUE);

  10. Example: Reading an Image File into Forms from the Client DECLARE v_file VARCHAR2(250):= CLIENT_GET_FILE_NAME('','', 'Gif Files|*.gif|JPEG Files|*.jpg|', 'Select a photo to upload',open_file,TRUE); it_image_id ITEM := FIND_ITEM ('employee_photos.photo'); BEGIN CLIENT_IMAGE.READ_IMAGE_FILE(v_file,'',it_image_id); END;

  11. Example: Writing Text Files on the Client DECLARE v_dir VARCHAR2(250) := 'c:\temp'; ft_tempfile CLIENT_TEXT_IO.FILE_TYPE; begin ft_tempfile :=CLIENT_TEXT_IO.FOPEN(v_dir || '\tempdir.bat','w'); CLIENT_TEXT_IO.PUT_LINE(ft_tempfile,'dir ' || v_dir || '> '|| v_dir || '\mydir.txt'); CLIENT_TEXT_IO.PUT_LINE(ft_tempfile, 'notepad ' || v_dir || '\mydir.txt'); CLIENT_TEXT_IO.PUT_LINE(ft_tempfile,'del '|| v_dir || '\mydir.*'); CLIENT_TEXT_IO.FCLOSE(ft_tempfile); CLIENT_HOST('cmd /c ' || v_dir || '\tempdir'); END; 1 2 3 4

  12. Example: Executing Operating System Commands on the Client DECLARE v_dir VARCHAR2(250) := 'c:\temp'; ft_tempfileCLIENT_TEXT_IO.FILE_TYPE; begin ft_tempfile :=CLIENT_TEXT_IO.FOPEN(v_dir || '\tempdir.bat','w'); CLIENT_TEXT_IO.PUT_LINE(ft_tempfile,'dir ' || v_dir || '> '|| v_dir || '\mydir.txt'); CLIENT_TEXT_IO.PUT_LINE(ft_tempfile, 'notepad ' || v_dir || '\mydir.txt'); CLIENT_TEXT_IO.PUT_LINE(ft_tempfile,'del '|| v_dir || '\mydir.*'); CLIENT_TEXT_IO.FCLOSE(ft_tempfile); CLIENT_HOST('cmd /c ' || v_dir || '\tempdir'); END;

  13. CLIENT_OLE2.OBJ_TYPE CLIENT_OLE2.LIST_TYPE CLIENT_OLE2.CREATE_OBJ CLIENT_OLE2.SET _PROPERTY CLIENT_OLE2.GET_OBJ _PROPERTY CLIENT_OLE2.INVOKE_OBJ CLIENT_OLE2.CREATE _ARGLIST CLIENT_OLE2.ADD_ARG CLIENT_OLE2.INVOKE CLIENT_OLE2.DESTROY _ARGLIST CLIENT_OLE2.RELEASE_OBJ Example: Performing OLE Automation on the Client You can use the following for OLE automation:

  14. Example: Obtaining Environment Information about the Client CLIENT_TOOL_ENV.GETVAR(:control.env_var, :control.env_value);

  15. Summary • In this lesson, you should have learned that: • WebUtil is a free extensible utility that enables you to interact with the client machine • Although WebUtil uses Java classes, you code in PL/SQL • You integrate WebUtil into a form by attaching its PL/SQL library and using an object group from its object library; then you can use its functions after the form has started and while it is running • With WebUtil, you can do the following on the client machine: open a file dialog box, read and write image or text files, execute operating system commands, perform OLE automation, and obtain information about the client machine

  16. Practice 24 Overview • This practice covers the following topics: • Integrating WebUtil with a form • Using WebUtil functions to: • Open a file dialog box on the client • Read an image file from the client into the form • Obtain the value of a client environment variable • Create a file on the client • Open the file on the client with Notepad • Use OLE automation to create a form letter on the client
