  1. GUCS (Groupe Utilisateur CATIA/Smarteam) CATIA FORUM 08 DECEMBER 2011

  2. Overview • GUCS PLMWG GrACQ in 2012 • External contact • Follow-up enhancementrequest • Data • Reminder Y. Muttoni 9e Catia forum 08/12/2011

  3. Monthly communal meetings between GUCS and PLMWG to discuss issues such as document life cycles Y. Muttoni 9e Catia forum 08/12/2011

  4. Monthly communal meetings between GUCS and PLMWG to discuss issues such as document life cycles Y. Muttoni 9e Catia forum 08/12/2011

  5. Regular communal meetings between GUCS and GrACQ to discuss issues such as cartouche modification. Y. Muttoni 9e Catia forum 08/12/2011

  6. External contact 150 Catia users Catia V5 – Smarteam since 2004 Y. Muttoni 9e Catia forum 08/12/2011

  7. External contact • Next step : Video conference on specific topic • Methodology • Reverse engineering • Life data management • Next release CATIAV5/Smarteam • Training Y. Muttoni 9e Catia forum 08/12/2011

  8. External contact • Regular meetings at Lyon 4-5 times per year on CATIA/Smarteam. • Necessary to have with IN2P3 a common version of CATIA. • Thanks fortheir presentation in this forum. Y. Muttoni 9e Catia forum 08/12/2011

  9. External contact • Cern participants • 3 Mechanical designer • 2 Integration designer • 2 Support CAD • Caec chairman • GS-ASE group leader • GUCS Chairman PedrettiAirlight Energy Manufacturing Julius Blum Smarteam/Enovia V6 ALSTOMEngineering process TechvizVisualization solutions for 3D applications FraunhoferProcess and Methodology Contact with external firms Present for users: CATIA V5 - Smarteam Future for users: CATIA V6 – Enovia V6 and Dassault Time to be defined 4-5 years??? Necessary to keep an eye on it Y. Muttoni 9e Catia forum 08/12/2011

  10. REQUESTS FOLLOW-UP (1/2) Y. Muttoni 9e Catia forum 08/12/2011

  11. REQUESTS FOLLOW-UP (1/2) Y. Muttoni 9e Catia forum 08/12/2011

  12. REQUESTS FOLLOW-UP (2/2) https://espace.cern.ch/cad-service/default.aspx Y. Muttoni 9e Catia forum 08/12/2011

  13. REQUESTS FOLLOW-UP (2/2) https://espace.cern.ch/cad-service/default.aspx On request of the EN department leader a list of the top enhancement requests will be provided for year 2012 Y. Muttoni 9e Catia forum 08/12/2011

  14. DATA 150 Users produce the data • The past has shown the need to clean up data regularly remind the vms to unix transition and the CAD migration from Euclid to Catia. • When you start a new design (part or product) check if the model does not exist in smarteam. • A cleaning of the vacuum equipment 3D model has started in smarteam. • Clean your 3D model not used and not useful. • Using the 3D models catalogue. Y. Muttoni 9e Catia forum 08/12/2011

  15. Reminder • Do not forget to discuss with your local correspondent. We meet them once a month. • Map link local correspondent • The methodology task is on the way R. Betemps will make a presentation at the next forum. • Smarteam refresh course is always available for all the users having followed the standard course. • In case of problems use the CAD Support mail. The GUCS members read them regulary. • The CATIA forum is for you but to continue we need you (topics, ideas, news…). Y. Muttoni 9e Catia forum 08/12/2011

  16. Y. Muttoni 9e Catia forum 08/12/2011

  17. Thank you for your attention Special thanks to Jean-Pierre for the forum CATIA organization Questions? Y. Muttoni 9e Catia forum 08/12/2011
