Kuali Coeus (KRCA) Developers Bootcamp

1. Kuali Coeus (KRCA)Developers Bootcamp Jack Frosch – Kuali Foundation (Lead Developer) Bryan Hutchinson - Cornell (Development Manager)

2. Topics About Kuali Coeus Tools Coding Standards Introduction/Lesson Overview Lessons!

3. About Kuali Coeus (KRCA) Eight partner schools Cornell, Indiana, Michigan State, MIT, Arizona, CSU, UC Davis, ISU Based on a MITs Coeus Full Featured Research Admin suite 13+ years of development work Still going! Consortium model

4. More About KRCA First Release - July 2008 Proposal Development Budget Grants.gov S2S Second Release - 2009 Awards IRB/Human Participants COI Beyond Functional Parity with Coeus

5. Project/Development Tools Eclipse (eclipse.org) Our primary development tool Leading free and open source IDE Pluggable architecture offers extensibility Maven (maven.apache.org) Provides dependency management and lifecycle goals (like Ant tasks) Subversion Source Code Management and Repository

6. Project/Development Tools Confluence (www.atlassian.com) Wiki used for collaboration FishEye (www.atlassian.com) Source code visualization Continuum (continuum.apache.org) A Continuous Integration server Sakai Group mailing lists

7. Project/Development Tools Cobertura (cobertura.sourceforge.net) Test coverage and reporting Can be run by developer and part of CI CheckStyle (checkstyle.sourceforge.net) Code style verification tool Can be run by developer and part of CI

8. Coding Standards Coding standards assist readability and maintainability Derived from Past experience The Elements of Java Style (“Little Green Book”)

9. Coding Standards Some Highlights Favor readability over complexity Methods should do one thing in < ~30 lines Struts Actions and Forms should not have business logic JavaDoc comments required Tests required for non-trivial public, protected and default visibility methods

10. Coding Standards Favor using Java 5 features where applicable Bos must override equals() and hashCode() Let Eclipse write them for you Constants must be used instead of literals, except for trivial loop indices, 0, 1, etc. If in doubt, check out the Little Green Book See Confluence Topic: KCRA Coding Standards - Post Release 1.0

11. How Bootcamp Works High-level Overview of Concepts Discussion/Demo/Review of Code based on slides Exercises Sample Application mimicking KRCA functionality Ask questions any time! Be engaged - You will get out what you put in!

12. Lesson Overview Day 1 BOs / Maintenance Documents Exercise 1 Exercise 2 Day 2 Transactional Documents Exercise 3 Web Components - Struts, KNS custom tags Exercise 4

13. Lesson Overview Day 3 Services Exercise 5 Lists Exercise 6 Rules Exercise 7 Document Authorizer Exercise 8

14. Documents and BOs Kuali is “Document based” Two Types of Documents Transactional Documents Maintenance Documents

15. Transactional Documents Represent a business function Apply for funds (by creating a proposal) Manage Human Participants (by creating a protocol, amendment, etc…) Complex rules and approval process Lots of data Potentially long living Focus on Transactional Documents later in the week

16. Maintenance Documents Manage (create/alter) Reference Data What is “reference data” In DB terms, it’s a table used by the entire system as a FK from other tables People, Organizations, Units, Sponsors, etc… What else would be reference data? Simple documents to perform CRUD operations

17. Business Objects Business Objects (BOs) are Java Beans Properties Getters/Setters Two categories Reference Data (CRUD via Maint Docs) Those used in Transactional Documents (Document Composition) Map to a single table in the DB

18. Spring BeanData Dictionary (DD) Controls the behavior of BOs Defined in Spring Bean XML Named like <moduleBeans>.xml E.g. AwardBeans.xml, BudgetBeans.xml Inquiries and Lookups Attributes - Properties of the BO UI Controls - Lookups, Maint Docs, Trans Docs Size & Shape Validation Required-ness

19. Database - OJB Kuali uses OJB as an ORM tool OJB - ObJectRelationalBridge ORM - Object-Relational Mapping Configure Write Java Code (not SQL) Related data elements are stored together Model complex database relationships

20. Using OJB OJB Repository XML Class Descriptor Define the Java Class and the Table Name Field Descriptor Java Property Name Column Name JDBC Type Conversion (boolean to char, custom datatypes, etc…) Primary Key Optimistic Locking

21. OJB - Getting more advanced Model Relationships Collection Descriptor Reference Descriptor More on these later ...

22. Demo / Code Review

23. Exercise 1

24. OJB - repository.xml Reference Descriptor Relationships to Reference data 1:1 (Proposal:Sponsor) Not saved/deleted when the related object is saved Collection Descriptor Relationships where a parent can have many children 1:M (Proposal:Investigators; Investigator:Unit) “Reverse Foreign Key” Save with the Parent

25. Maintenance Docs How we manage Reference Bos XML based: <BO Class Name>MaintenanceDocument.xml BO Class Maintainable Class - API for customization Business Rules - API to perform validation Document Authorizer - Customize AuthZ for a doc Document Type - Reference to KEW Maintainable Section(s) and Item(s) - what and how attributes are presented Attributes, Locking Key, Default Existence Checks…

26. Values Finders User to present a list of options in the UI Drop-down Radio Group Queries the database and returns a list of valid values PersistableBusinessObjectValuesFinder 80% - BO Class, Key/Label Attributes Names Custom Values Finders 20% - Extend KeyValuesBase, Implement KeyValuesFinder XML (DD) and Code (Class file)

27. Demo / Code Review

28. Exercise 2

29. Database - JPA Kuali is migrating to JPA/Hibernate for ORM JPA: Java Persistence API ORM: Object-Relational Mapping Hibernate is the JPA Provider Configured in META-INF/persistence.xml and META-INF/orm.xml Object properties and relationships are modeled in BOs using JPA annotations

30. Using JPA Persistence.xml defines Persistence Units Define a datasource; i.e. Oracle, MySQL Provider properties; i.e. for Hibernate Orm.xml is used to Declare global sequences Declare entity mappings (i.e. when not using annotations Declare lifecycle callback methods … and more

31. Using JPA JPA annotations on BOs @Entity: Indicates object is persistable @Table: To name the table @Id: Field(s) forming primary key @Version: Field for optimistic locking @Column: To name the column, specify length (String data), precision and scale (numeric data), and other column data

32. Using JPA Id values are auto-generated by JPA Version field is used during updates to determine if record has been update (Optimistic Locking) KRCA uses Pessimistic Locking of its BO documents, so Optimistic Locking exceptions are rare events

33. JPA - Getting More Advanced Object relationship annotations are used to model relationships between Bos @Embeddable: An entity without a table @Embedded: Included embedded entity columns in same table @OneToOne: One-to-one with join @OneToMany: Most frequent relationship @ManyToMany: Uses intermediate join table

34. Transactional Documents Composed of a Document class and multiple BOs Document Composition BOs have a reference to the Document class/table (FK Relationship) Transactional Document classes are special BOs Super BOs with additional behavior

35. Transactional Document Similar to Maint Doc DD files Add Attributes (since these are BOs) No lookups (we use KEW for Doc Search) No Inquiries Similar to other OJB mappings Lots of relationships defined Other mappings should not refer back to the Document class

36. Demo / Code Review

37. Exercise 3

38. Web stuff in Kuali/KRCA Struts Pseudo MVC Forms, Actions, Mappings Struts in Kuali Heavily customized Addresses common Struts anti-patterns Simplifies development Single Action Mapping

39. Struts Action Classes Object Hierarchy for KRCA: -KraTransactionalDocument ----KualiTransactionalDocumentBase ------KualiDocumentActionBase --------KualiAction ----------DispatchAction

40. Struts Form Classes Document is placed in the Form POJO Form Base handles type conversion Object Hierarchy for KRCA: -ProposalDevelopmentForm ----KualiTransactionalDocumentFormBase ------KualiDocumentFormBase --------KualiForm ----------PojoFormBase ------------ActionForm (Struts base form)

41. Building the UI JSPs/Custom Tags JSTL and JSP Expression Language Preferable to Struts tags when possible Kuali Rice Tags page.tag and documentPage.tag tab.tag documentControls.tag htmlControlAttribute.tag

42. KRCA Custom Tags Build complex JSPs Maintainability Methodology is approximate, but in general: 1 JSP per page Generally, 1 .tag per panel on the page

43. HTMLControlAttribute.tag <kul:htmlControlAttribute /> Replaces struts <html:xxx /> Uses Spring Bean entries to determine: Type of control (text, drop-down, etc) Length Max Length Spring Bean Attributes

44. Demo / Code Review

45. Exercise 4

46. Services and DAOs Services: Implements Business Logic not in BOs Perform a calculation; Save a Document Services are defined as Interfaces and Implemented as classes Spring manages the resolution of Interface to actual code - Spring Beans XML Accessing Services Dependency Injection Service Locator (KraServiceLocator) Data Access Objects - DAOs Similar to Services, but have knowledge of the data model

47. Demo / Code Review

48. Exercise 5

49. Lists of Data Old stuff JPA, BOs, Spring Beans, etc New stuff Document changes Special getter Deletion Aware Lists Action Form - Methods for add/delete JSP/tag - Accessing properties of a list

50. Demo / Code Review
