  1. GDB &Transport Protocols CS176A Ramya Raghavendra

  2. What is Gdb? • GDB is the GNU Project debugger • Gdb provides some helpful functionality • Allows you to stop your program at any given point. • You can examine the state of your program when it’s stopped. • Change things in your program, so you can experiment with correcting the effects of a bug. • Also a command-line program • Is also available on spinlock/coredump

  3. Using Gdb: • To start gdb with your hello program type: gdb HelloProg • When gdb starts, your program is not actually running. • You have to use the run command to start execution. • Before you do that, you should place some break points. • Once you hit a break point, you can examine any variable.

  4. Useful gdb commands • runcommand-line-arguments • Begin execution of your program with arguments • break place • place can be the name of a function or a line number • For example: break main will stop execution at the first instruction of your program • delete N • Removes breakpoints, where N is the number of the breakpoint • step • Executes current instruction and stops on the next one

  5. Gdb commands cont. • next • Same as step except this doesn’t step into functions • printE • Prints the value of any variable in your program when you are at a breakpoint, where E is the name of the variable you want to print • helpcommand • Gives you more information about any command or all if you leave out command • quit • Exit gdb

  6. GDB Basics • How to setup the environment to dump core files: • csil% ulimit –c unlimited • How to open a core file • csil% gdb –q ./executable corename (the parameter –q is optional. The will prevent GDB from printing out extra garbage when it initially loads) • What to do when a core file is loaded up • (gdb) bt (backtrace) • Will show you the stack when the program crashed • More useful to run your program with GDB. • csil% gdb –q ./executable • Set breakpoints: (gdb) b <line number> OR b <function name> • Run the program: (gdb) r <commandline params> • The program will break when it reaches a breakpoint • Print value of a variable: (gdb) print <variable name> • Step through a function: (gdb) s • Skip to the next instruction: (gdb) n • Continue until the program exits or another breakpoint is reached: (gdb) c

  7. Transport Protocols • NAK only • x-1, x+1 => x was missed • NAK is sent for x • GBN (Go Back N) • Sender is allowed to transmit multiple packets • No more than N unACKed packets in pipeline

  8. GBN(Cont) • [0,base-1] – already transmitted and ACKd • [base,nextseqnum-1] - sent, not ACKd • [nextseqnum,base+N-1] – can be sent next • >base+N+1 – cant be used • Problem 2: receiver has received k-1 • Sender got ACKS for all • Sender did not get any ACK

  9. Sample RTT • SampleRTT – time between the segment is sent and ACK is received • Estimated for every transmitted and unACKed segment • NOT for retrasmitted packets. WHY? • P1 – no ACK • P2 - ACK

  10. Fast Retrasmit • Timeout triggered retransmissions : delay • Duplicate ACK • Packet already has been ACKed • n,n+1,n+2 : sent Sent Recv ACK n n n n+1 --- n+2 n+2 n

  11. O=100KB, S=536B, RTT=100ms • Minimum latency = 2RTT+O/R • W = min{w: w >= (RTT+S/R) ------------------------- S/R
