  1. Fall 2009 Module 8 Inverters

  2. Inverters • Converts the DC power produced by the solar modules into AC power used on the utility grid

  3. History • Inverters have been the weaker link in PV systems • Early inverters were unreliable • Early inverters were inefficient which penalized an entire system

  4. Inverter Types • Square Wave • Modified square wave • Sine wave

  5. Square wave • Step-function or “square” alternating current output • Considerable harmonic distortion • For small resistive heating loads

  6. Modified Square Wave • Complex circuits used to switch DC into AC. • More appropriate for operating a wide variety of appliances • Still noise will be picked up by sensitive equipment

  7. Sine Wave • High quality wave form • Most common inverters today • Little harmonic distortion

  8. The wave…comparison

  9. Inverter manufacturers • SMA (Sunny Boy) • Fronius • Xantrex • Outback • PV Powered • Kaco • Enphase – Micro Inverters

  10. The Guts

  11. Some examples

  12. Enphase Micro-Inverter

  13. All Installed

  14. Installing SMA

  15. Optional Inverter Features • Remote control operation and data-monitoring • Load transfer switch-allows system to meet critical loads during power failure • Series and Parallel connectivity for multiple inverters • Individual module performance monitoring

  16. Ideal Inverter Features – now standard • Maximum power point tracking (MPPT) • Low harmonic distortion • Near perfect Sine wave shape • Ground Fault Protection • AC/DC disconnects • Weatherproof enclosure

  17. Specifying an inverter • Grid Tied:Watts Output AC-computed STC rated watts of PV panels • Stand-Alone: based on peak load • Input Voltage-usually between 75 and 480 VDC, called the window or range • Insure that the voltage will not drop or exceed this range because of climatic conditions or inverter will not function • Output Voltage:120, 240, 208, 480 • Frequency: U.S. is 60Hz

  18. Specifying an inverter • Grid Tied:Watts Output AC-computed STC rated watts of PV panels • Stand-Alone: based on peak load • Input Voltage-usually between 75 and 480 VDC, called the window or range • Insure that the voltage will not drop or exceed this range because of climatic conditions or inverter will not function • Output Voltage:120, 240, 208, 480 • Frequency: U.S. is 60Hz

  19. Grid Tied Inverter Sizing • Sized based on the amount of watts we pass through the system at any one time • Size of inverter is the labeled watts • an SMA 3000 is a 3000 watt inverter • The most power that will pass through this inverter is 3000 watts • If the output is 240 volts, the current will be 12.5 amps • 3000W ÷ 240v = 12.5 amps

  20. String Sizing Software

  21. And sized by… • PV system component package (grid tied) • The Grid Tied PV system will be based on other factors • Budget • Roof Size • Rebate/Tax incentives
