  1. Required Slide SESSION CODE: WSV321 Managing Server Core without Breaking a Sweat! Joachim Nässlander Solution Architect Microsoft Infrastructure and EUC Dell Inc.

  2. The goal of a Server Core installation is to get it on the network and make it remotely manageable.

  3. 75 Minutes of What? • How Core was born • Why Core? • Installation scenarios • Initial configuration • Local Management • Remote Management

  4. How Core Was Born • Customer feedback • Removal of requirements • Four inital roles • Focus areas • Side benefits

  5. Why Core? • Footprint • Attack surface • Management • Patching

  6. Footprint ”The memory footprint in RAM for Server Core has been reduced to less than 100MB, compared to roughly 130MB for Windows Server 2008 and 244MB for Windows Server 2003, which didn’t have a Server Core install option.” (Ward Ralston, http://www.windowsitpro.com/article/virtualization/why-you-need-windows-server-2008-r2.aspx) Windows Server 2008 R2 Core HD ~3.0 GB RAM 512 MB for install (runs on 64!) Windows Server 2008 R2 HD ~7.0 GB RAM 512 MB for install

  7. Footprint – Disk Usage

  8. Reducing Disk Usage pkgmgr/up:<package to remove> Remove all packages you won’t need Reboot 23 packages can be remove, gain ~200 MB

  9. Patches ”Over time, the number of reboots for patching or security updates is significantly reduced for a Server Core installation of which the benefits are obvious.  In some cases, customers can see up to a 60% reduction in patch requirements and the number of reboots on a monthly basis.”(David B Cross, http://blogs.technet.com/b/windowsserver/archive/2010/05/07/server-core-best-practice-for-applications-on-windows-server.aspx)

  10. Patches Source: Microsoft bulletins / Andrew Mason

  11. Installation Manual installation Automated deployment Template

  12. Is it Core? Separate SKU 0C Datacenter (core installation) 27 Server Datacenter without Hyper-V (core installation) 0E Server Enterprise (core installation) 29 Server Enterprise without Hyper-V (core installation) 2A Microsoft Hyper-V Server 0D Server Standard (core installation) 28 Server Standard without Hyper-V (core installation) 1D Web Server (core installation)

  13. Is It Core? Joachim NässlanderSolution Architect Microsoft Infrastructure & End User ComputingDell Inc. DEMO

  14. Is it Core? WMI / WMIC / PowerShell WMI: “Select OperatingSystemSKUfrom Win32_OperatingSystem” WMIC: ”OS get operatingsystemsku” 14 = E = Enterprise Core Convert to HEX Complete table of available SKU’s: http://msdn.microsoft.com/en-us/library/ms724358.aspx

  15. Initial Configuration Joachim NässlanderSolution Architect Microsoft Infrastructure & End User ComputingDell Inc. DEMO

  16. Sconfig • Cons • Not all roles Pros Developed by Microsoft Actively maintained Included

  17. Core Configurator • Cons • Must install • Needs .Net / PowerShell Pros Developed by a team Actively maintained Shotgun interface Download: http://coreconfig.codeplex.com/

  18. Core Configuration Console R2 • Cons • No support • Privately developed • Not all roles supported • Not shotgun Pros Standard commands Free No installation / features needed Easily extended Download: http://ccc.codeplex.com or http://www.nullsession.com

  19. Smart-X Core Configurator • Cons • Needs install • Not free Pros Shotgun interface Developed by company Download: http://www.smart-x.com

  20. CMD • Cons • Steep learning curve • Ineffective Pros Included Well documented Support

  21. PowerShell / VBScript / WMI • PowerShell • VBScript • WMI • Remote support • Reusable

  22. PowerShell • Add .Net Framework • Add PowerShell • Configure

  23. PowerShell C:\> start /wait ocsetupNetFx2-ServerCore (WoW-64) C:\> start /wait ocsetupMicrosoftWindowsPowerShell (Wow-64) C:\> powershell PS C:\> import-module ServerManager PS C:\> set-executionpolicyremotesigned (unrestricted) PS C:\> enable-psremoting

  24. Local Management of Roles • Specific commands for roles • Active Directory • DSADD, DSGET + more • DNS • DNSCMD • Network Configuration / Firewall / DHCP • NETSH

  25. Local Management Joachim NässlanderSolution Architect Microsoft Infrastructure & End User ComputingDell Inc. DEMO

  26. Firewall Configuration • Locally • NETSH • Remote • Group Policy • MMC / Server Manager

  27. Remote Management of Roles • Firewall configuration • Server Manager • Remote Server Administration Tools / MMC

  28. Remote Management Joachim NässlanderSolution Architect Microsoft Infrastructure & End User ComputingDell Inc. DEMO

  29. Conclusion • Learning curve • Security • Management

  30. Required Slide Speakers, please list the Breakout Sessions, Interactive Sessions, Labs and Demo Stations that are related to your session. Related Content • WSV319 | Manage Your Enterprise from a Single Seat: Windows PS Remoting • WSV07-INT | New Remote Management Technologies in Windows Server 2008 R2 • WSV18-HOL | Introduction to Windows PowerShell Fundamentals • WSV19-HOL | Advanced Windows PowerShell Scripting • TLC-54 | Windows PowerShell and Server Management

  31. Required Slide Resources Learning • Sessions On-Demand & Community • Microsoft Certification & Training Resources www.microsoft.com/teched www.microsoft.com/learning • Resources for IT Professionals • Resources for Developers • http://microsoft.com/technet • http://microsoft.com/msdn

  32. Required Slide Complete an evaluation on CommNet and enter to win!

  33. Sign up for Tech·Ed 2011 and save $500 starting June 8 – June 31st http://northamerica.msteched.com/registration You can also register at the North America 2011 kiosk located at registrationJoin us in Atlanta next year
