  1. Web Search For a Planet: The Google Cluster Architecture Luiz Andre Barroso Jeffrey Dean Urs Holzle Google

  2. Outline • Introduction • Architecture Overview • Serving a Google Query • Design Principles of Google Clusters • The Power Problem • Parallelism • Hardware-level Application Characteristics • Conclusion

  3. Introduction • Search engines • require high amounts of computation per request • A single query on Google (on average) • reads hundreds of megabytes of data • consumes tens of billions of CPU cycles • Instead of a smaller number of high-end servers • Google combines more than 15,000 commodity-class PCs

  4. Architecture Overview • Provide reliability in software • Use cluster of PCs • Not high-end servers • Design system to maximize aggregate throughput • No server response time can parallelize individual • requests

  5. Serving a Google Query Figure shows Google query-serving architecture

  6. Serving a Google Query(Cont.) • Geographically distributed clusters • Each with a few thousand machines • First perform Domain Name System (DNS) lookup • Maps request to nearby cluster • Send HTTP request to selected cluster • Request serviced locally w/in that cluster • Clusters consist of Google Web Servers (GWSs) • Hardware-based load balancer distributes load among GWSs

  7. Design Principles of Google Clusters • Software level reliability • No fault-tolerant hardware features; e.g. • redundant power supplies • A redundant array of inexpensive disks (RAID) • Use replication • for better request throughput and availability • Price/performance beats peak performance • CPUs giving the best performance per unit price • Not the CPUs with best absolute performance • Using commodity PCs • reduces the cost of computation

  8. The Power Problem • Power is a very big issue • Google servers consumes 400-700 W/sq. ft • Typical commercial data center consumes 70-150 W/sq. ft. • Reducing power would reduce performance but it may not reduce cooling and power issues

  9. Parallelism • Lookup of matching docs in a large index • Many lookups in a set of smaller indexes followed by a merge step • A query stream is of multiple streams each handled by a cluster • Adding machines to a pool increases serving capacity

  10. Hardware-level Application Characteristics • Price/Performancebeats pure Performance • Use dual CPU servers rather than quad • Use IDE rather than SCSI • Use commodity PCs • Essentially mid-range PCs except for disks • No redundancy as in many high-end servers • Use rack mounted clusters connected via Ethernet

  11. Conclusion Web search engine can be implemented like Google using: • Lots of commodity machines. • Parallel algorithms for latency. • Replication for throughput and reliability. • Software based reliability. • This resulting distributed system will have a very good price/performance ratio.
