  1. SIM361 Microsoft System Center Virtual Machine Manager 2012: Server Fabric Lifecycle, Part 2 - OSD, OOB and Agent Management Carmen Summers Senior Program Manager Microsoft Corporation

  2. System Center Virtual Machine Manager 2012 Fabric Services Cloud Deployment • Fabric • Management • Hyper-V Bare Metal Provisioning • Update Management • Hyper-V, • VMware, Citrix XenServer • Dynamic Optimization • Network Management • Power Management • Storage Management • Monitoring Integration

  3. Session Objectives • Understanding of: • VMM 2012 investments in fabric management for VM Hosts • XenServer, VMware and Hyper-V • How VMM 2012 fabric management decreases the cost of maintenance and operations through automation

  4. Host management in VMM 2008 R2 • VMM focus is on “VM Host Management” • Adding VM Hosts into VMM • Managing VM Host properties • Monitoring Host agent states

  5. Multiple Hypervisor Support

  6. Virtual Machine Manager 2012: Architecture Console Self Service Web Portal • Operations Manager • Management Server Windows PowerShell SCVMM Connector • Virtual Machine Manager • Management Server Management Interfaces Windows Deployment Services Server (WDS) VMM Library Server Virtualization Abstraction Layer Windows Software Update Services Server (WSUS) VMware vCenter Hyper-V Hosts and Clusters Citrix XenServer Hosts and Clusters VMware ESX Hosts and Clusters VMware ESX Hosts and Clusters Storage / Networking

  7. ESX Management

  8. ESX ManagementvCenter 4.1 Integration • vCenter datacenter tree structure not imported • Add host and clusters into any host group • Support for using less privileged accounts in vCenter vCenter SCVMM 2008 R2 SCVMM vNext

  9. ESX Management - Networking • vSwitch types supported • Standard, distributed vSwitch • Port group types discovered and used • Standard, distributed port group

  10. ESX Management – VMware Templates • Template in Library • Discover and use VMDK in Library for template creation • Template Import • Import of vCenter template object meta data into VMM Library • Does not copy VMDK to VMM library • Does not remove template in vCenter • New VM workflow uses vCenter to copy VMDK (faster deployment)

  11. VMware Management - VM Management • Thinly provisioned virtual disk in template and VM • Fault Tolerance • Discover and use primary VM • Migration to Library disabled • No support for creating FT VMs • Updating VM hardware properties to match platform

  12. ESX Management - VM Migration • Supported VMware transfer types • Live Migration • Live Storage Migration • Supported VMM transfer types • Network migration to/from Library • Note: Thin provision disks become THICK • Network migration between hosts • Supported copy mechanisms • VMware native HTTPS • No support for SFTP (no need to enable root SSH) • Still requires root credential

  13. Citrix XenServer Management

  14. Benefits of XenServer support in VMM • Management of all hypervisors in your datacenters • More choice for Linux guests in addition to what Hyper-V supports • VMM features get applied to XenServer

  15. XenServer Management • VMM has no dependency on Citrix XenCenter Install Citrix XenCenter SCVMM 2012 Libraries SCVMM 2012 Server Citrix XenServer(s) Hyper-V Integration Pack Storage Repositories

  16. XenServer ManagementHost Management • Host configuration takes place outside of VMM • Standalone & Pooled hosts • Power Control • Shutdown and Power On (if OOB capable hardware), Restart • Maintenance Mode

  17. XenServer ManagementHost Storage • Support all virtual disk storage repositories • iSCSI, NFS, HBA, StorageLink • Shared and Local • All storage must be added to XenServer outside of VMM • ISO repositories • NFS or CIFS • ISO Repository must be Read-Write • Only support attaching ISOs from the VMM library

  18. XenServer ManagementHost Networking • Differences between Hyper-V and XenServer Virtual Switches • VLAN tagging takes place at physical pseudo NIC level • Separate switch for each VLAN • VMM wraps a single Virtual Switch around all of the XenServer switches on a single physical adapter

  19. XenServer ManagementVM Management • PV & HVM VMs are supported • Windows will only run on HVM VMs • VMM will only create HVM VMs from scratch • Standard VM settings available • Use VHDs • No Floppy, No COM ports • Actions • Start, Stop, Save state, Pause, Shut down • Checkpoints • Takes advantage of new checkpoint enhancements in XenServer • Guest console access • Intelligent Placement & Dynamic Optimization • Dynamic Memory is not supported

  20. XenServer demo

  21. XenServer ManagementVM Templates • VMM Templates are supported with XenServer • Generalization/Customization for Windows VMs only • Citrix Tools for VMs must be installed manually • XenServer Templates • Not used by VMM • To import into VMM • Use XenCenter to create a VM • Create VMM Template from this VM • PV properties are retained

  22. Hyper-VManagment

  23. VM Host Lifecycle

  24. VM Host LifecycleKey Investments for VMM 2012

  25. Out-of-band (OOB) Management • Discovery & basic hardware inventory • SMBIOS GUID • Basic asset properties (Mfg / Model / AssetTag / SerialNo, etc.) • Manage power states – query, power on, power off • Collection of system hardware logs • Enabler of scenarios • Bare Metal Deployment • Dynamic Optimization and Power Optimization

  26. Out-of-band Management Interfaces Standards Based - in box • SMASH via WS-MAN (not CLP) • Systems Management Architecture for Server Hardware • IPMI / DCMI • Intelligent Platform Management Interface • Data Center Management Interface Extensible • Configuration Provider Interface

  27. Bare Metal DeploymentGoal Discover bare metal machines and bring them to a fully provisioned state with Hyper-Venabled

  28. 1. OOB Reboot 5. Run GCEs & Configure partitions 3. Authorize PXE Boot 2. Boot from PXE 8. Customize & Domain Join 4. Download WINPE contoso 6. Download VHD 9. Enable Hyper-V 7. Inject Drivers Library server WDS server Bare Metal Server VMM Server Hyper-V Server Host profile VHD Drivers

  29. Bare Metal Deployment of Hyper-VPXE Server • Windows Deployment Server (WDS) on Windows Server 2008 R2 • Installs VMM OSD provider and agent • Coexists with other providers • Responds to VMM initiated PXE requests • Deploys WinPE

  30. Bare Metal Deployment of Hyper-VHost profile

  31. Bare Metal Deployment of Hyper-VAdd resource wizard

  32. OS Deployment demo

  33. In Review: Session Objectives and Takeaways • Understanding of: • VMM 2012 investments in fabric management for VM Hosts • XenServer, VMware and Hyper-V • How VMM 2012 fabric management decreases the cost of maintenance and operations

  34. VMM 2012 Community Evaluation Program • Guided evaluation of Management & Security Products • Access to evaluation bits and VHDs • Access to product group at Virtual Chalk Talks • Community of Participants • Share feedback on product and documentation • Share best practices and experiences • Learn more about programs at • https://connect.microsoft.com/site1211 • Or email mscep@microsoft.com with your interest * Proposed Sessions, dates and Session details subject to change

  35. Related Sessions

  36. Q & A

  37. Track Resources Don’t forget to visit the Cloud Power area within the TLC (Blue Section) to see product demos and speak with experts about the Server & Cloud Platform solutions that help drive your business forward. You can also find the latest information about our products at the following links: • Cloud Power - http://www.microsoft.com/cloud/ • Private Cloud - http://www.microsoft.com/privatecloud/ • Windows Server - http://www.microsoft.com/windowsserver/ • Windows Azure - http://www.microsoft.com/windowsazure/ • Microsoft System Center - http://www.microsoft.com/systemcenter/ • Microsoft Forefront - http://www.microsoft.com/forefront/

  38. Resources • Connect. Share. Discuss. http://northamerica.msteched.com Learning • Sessions On-Demand & Community • Microsoft Certification & Training Resources www.microsoft.com/teched www.microsoft.com/learning • Resources for IT Professionals • Resources for Developers http://microsoft.com/technet http://microsoft.com/msdn

  39. Complete an evaluation on CommNet and enter to win!

  40. © 2011 Microsoft Corporation. All rights reserved. Microsoft, Windows, Windows Vista and other product names are or may be registered trademarks and/or trademarks in the U.S. and/or other countries. The information herein is for informational purposes only and represents the current view of Microsoft Corporation as of the date of this presentation. Because Microsoft must respond to changing market conditions, it should not be interpreted to be a commitment on the part of Microsoft, and Microsoft cannot guarantee the accuracy of any information provided after the date of this presentation. MICROSOFT MAKES NO WARRANTIES, EXPRESS, IMPLIED OR STATUTORY, AS TO THE INFORMATION IN THIS PRESENTATION.
