  1. /*/*/self::*XPath Dongwon Lee, Ph.D. IST 516 Fall 2011

  2. XPath • Path-based XML query language • V1.0 – 1999: http://www.w3.org/TR/xpath • V2.0 – 2003: http://www.w3.org/TR/xpath20/ • Functional, strongly-typed query language http://www.w3schools.com/xpath/xpath_intro.asp

  3. Apps of XPath • XQuery: a full-blown query language for XML • for $x in doc("books.xml")/bookstore/bookwhere $x/price>30order by $x/titlereturn $x/title • XPointer/XLink: a standard way to create hyperlinks in XML • <book title="Harry Potter">  <description  xlink:type="simple"  xlink:href="http://book.com/images/HPotter.gif"  xlink:show="new">  As his fifth year at Hogwarts School of Witchcraft and  Wizardry approaches, 15-year-old Harry Potter is.......  </description></book>

  4. Apps of XPath • XSLT: a style sheet language of XML that can transform XML from one to another format <xsl:stylesheet version="1.0” xmlns:xsl="http://www.w3.org/1999/XSL/Transform"><xsl:template match="/">      <xsl:for-each select="catalog/cd">        <tr>          <td><xsl:value-of select="title"/></td>          <td><xsl:value-of select="artist"/></td>        </tr>      </xsl:for-each> </xsl:template></xsl:stylesheet>

  5. XML Model Trees Hierarchy Order Relational Model Tables Flat Orderless (except ORDER-BY) XPath vs. SQL XPath SQL

  6. XML Model Trees Hierarchy Order Can do all XPath does but not vice versa Turing-Complete general purpose PL Can retrieve, update, and transform XML data FLWOR expression XPath vs. XQuery XPath XQery

  7. XPath Expression • Expression (basic building block) returns one of the 4 objects: • node-set (an unordered collection of nodes without duplicates) • boolean (true or false) • number (a floating-point number) • string (a sequence of characters) . . .

  8. XPath Nodes processing-instruction • <?xml version="1.0” encoding="UTF-8”?> • <notexmlns="http://pike.psu.edu"xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"xsi:noNamespaceSchemaLocation=“note.xsd”> • <to>Tove</to> • <!-- <from>Jani</from> --> • <heading>Reminder</heading> • <body>Don't forget me this weekend!</body> • </note> • Nodes: 7 types • element, attribute, text, namespace • processing-instruction, comment, document namespace document comment text

  9. Location Step • Location Steps are evaluated in order from left to right • Absolute: /step/step/… • Relative: step/step/… • Axis: Specifies the node relationship • Node Test: specifies node type and name • Predicate: Instructions to filter nodes Preferred – Faster to evaluate axis :: node-test [predicate]

  10. 1. Axis • / selects the root of the node hierarchy • <document/> as the default root of XML document • Forward Axis • child::, descendent::, attribute::, self::, descendent-or-self::, following-sibling::, following:: • Backward Axis • ancestor::, preceding-sibling::, preceding::, ancestor-or-self:: • Relative to the current context (Axis::context) • child::emp: “emp” is the child element of current node • attribute::date: “date” is the attribute of current node

  11. Courses Parent Ancestors Self Undergrad Graduate Sibling Descendants Room Instructor Child Name Office Phone Grandchild Node Relationships

  12. 1. Axis Abbreviation • Descendent-or-self::node()  // • child::  / • attribute::  @ • self::node()  . • parent::  .. • Eg • /child::doc/descendent::chapter  /doc//chapter • //doc/attribute::type  //doc/@type

  13. 2. Node Test • node(): matches all nodes • text(): matches all text nodes • ElementName: matches all elements of type ‘ElementName’ • *: matches all elements • @*: matches all attributes

  14. 2. Node Test • * (wildcard) is often used to match unknown XML elements • /catalog/cd/*: all the child elements of all the cd elements of the catalog element • /* : all children of the root <document/> • /*/*: all grandchildren of the root <document/> • //*: all elements of the XML document

  15. 3. Predicate • Path-expresson[ filtering condition ]  Path-expression that satisfies the filtering condition • Eg • //doc [@type=‘PDF’] finds all <doc> elements whose attribute “type” values are ‘PDF’ • This returns <doc> elements, not its attributes “type” • Filtering condition does not affect the returned answers (ie, projection) of XPath • It just adds more constraints to satisfy

  16. Location Step Examples

  17. Examples of usage

  18. IST Example What IST Classes are in Room IST 110? /Courses/*[child::Room=‘110 IST’]

  19. IST Example What IST courses have TA’s? /Courses/*/TA/parent::*

  20. IST Example What rooms are used by IST courses? /Courses/*/Room/text()

  21. Comparison • Comparison can be performed using • =, !=, <=, <, >=, and > • Examples • [child::Room != ‘205 IST’] • [child::Time > 1220] NOTE: When used within Predicate, Child::Room == Child::Room/text()

  22. Math Operators • + : performs addition • - : performs subtraction • * : performs multiplication • div : performs division • mod : returns the remainder of division • Examples: • [child::Time mod 100 = 30]

  23. Node Functions • last() : returns the numeric position of the last node in a list • position() : returns the numeric position of the current node • count() : returns the number of nodes in a list • name(): returns the name of a node • id() : selects elements by their unique ID

  24. Node Function Example Which courses have more than 2 child elements? /Courses/*[count(child::*)>2]

  25. String Functions • concat(string, string) : concatenates the string arguments • starts-with(string, string) : returns true if the first string starts with the second string • contains(string, string) : returns true if the first string contains the second string • Eg, • concat(‘sh’, ‘oe’) = ‘shoe’ • starts-with(‘cat’, ‘ca’) = true • contains(‘puppy’, ‘upp’) = true

  26. String Functions • substring(string, number, [number]) : returns a substring of the provided string • string-length(string) : returns the number of characters in the string • Eg, • substring(‘chicken’, 3, 4) = ‘icke’ • substring(‘chicken’, 3) = ‘icken’ • string-length(‘cat’) = 3

  27. String Functions Examples • //Book [starts-with(child::Title, “X”)] / price • //Book [string-length(Author/FN)=3] / Title <Catalog> <Book> <Title>XML</> <Price>19.9</> <Author> <FN>Joe</> </Author> </Book> <Book> <Title>XSLT</> <Price>22.9</> <Author> <FN>HJ</><LN>Kyle</> </Author> </Book> </Catalog>

  28. Number Functions • sum(node-set) : returns the sum of values for each node in a node set • Eg, sum(//@price) • floor(number) : returns the largest integer that is not greater than the argument • Eg, floor(2.6) = 2 • ceiling(number) : returns the smallest integer that is not less than the argument • Eg, ceiling(2.6) = 3 • round(number) : returns the closest integer to the argument • Eg, round (2.4) = 2

  29. Boolean OPs in XPath • Conjunction: “and” • //Product[@price>10.8 and @year>2000] • Disjunction: ““or” • /Customer[@cname=‘Lee’ or @cid>100] • Disjunction: “|” • Compute both node-sets and return the union • //Book | //Tape • NOTE: some XPath engines currently support only either “|” or “or” disjunction

  30. /AAA/CCC <AAA>           <BBB/>           <CCC/>           <BBB/>           <BBB/>           <DDD>                <BBB/>           </DDD>           <CCC/>      </AAA> /AAA/DDD/BBB <AAA>           <BBB/>           <CCC/>           <BBB/>           <BBB/>           <DDD>                <BBB/>           </DDD>           <CCC/>      </AAA> XPath Lab [www.zvon.org]

  31. //BBB <AAA>           <BBB/>           <CCC/>           <BBB/>           <BBB/>           <DDD>                <BBB/>           </DDD>           <CCC/>      </AAA> /AAA/* <AAA>           <BBB/>           <CCC/>           <BBB/>           <BBB/>           <DDD>                <BBB/>           </DDD>           <CCC/>      </AAA> XPath Lab [www.zvon.org]

  32. /AAA/BBB[1] <AAA>           <BBB/>           <CCC/>           <BBB/>           <BBB/>           <DDD>                <BBB/>           </DDD>           <CCC/>      </AAA> /AAA/BBB[last()] <AAA>           <BBB/>           <CCC/>           <BBB/>           <BBB/>           <DDD>                <BBB/>           </DDD>           <CCC/>      </AAA> XPath Lab [www.zvon.org]

  33. /AAA//BBB[1] <AAA>           <BBB/>           <CCC/>           <BBB/>           <BBB/>           <DDD>                <BBB/>           </DDD>           <CCC/>      </AAA> /AAA//BBB[last()] <AAA>           <BBB/>           <CCC/>           <BBB/> <BBB/>           <DDD> <BBB/>           </DDD>           <CCC/>      </AAA> XPath Lab [www.zvon.org] Position=3 Position =1

  34. Position Explanation • “/AAA//BBB” returns two lists: • Three <BBB> as the children of <AAA> • One <BBB> as the grandchild of <AAA> • Then, position like [1] or [2] applies predicate to answers in each list SEPARATELY • /AAA//BBB[1] returns both: • First <BBB> from the first list -- a child of <AAA> • First <BBB> from the second list -- a grandchild of <AAA> • /AAA//BBB[last()] however returns nothing • last() returns the position of the last node in a list • But there are two lists here and can’t pick which

  35. //@id <AAA>  <BBB id = "b1"/>  <BBB id = "b2"/>  <BBB name = "bbb"/>  <BBB/> </AAA> //BBB[@id=“b2”] <AAA>  <BBB id = "b1"/>  <BBB id = "b2"/>  <BBB name = "bbb"/>  <BBB/> </AAA> XPath Lab [www.zvon.org]

  36. //*[count(BBB)=2] <AAA>           <CCC>                <BBB/>                <BBB/>                <BBB/>           </CCC>           <DDD>                <BBB/>                <BBB/>           </DDD>           <EEE>                <CCC/>                <DDD/>           </EEE>  </AAA> //*[count(*)=3] <AAA>           <CCC>                <BBB/>                <BBB/>                <BBB/>           </CCC>           <DDD>                <BBB/>                <BBB/>           </DDD>           <EEE>                <CCC/>                <DDD/>           </EEE>  </AAA> XPath Lab [www.zvon.org]

  37. XPath Evaluation S/W • Many S/W have built-in support for XPath 1.0 and 2.0 now • Eg, • XPath Visualizer: Windows only • http://xpathvisualizer.codeplex.com/ • XMLSpy: Windows only • <oXygen/>: Mac and Windows • XMLPad: Windows only

  38. #1. XPath Visualizer Answer #2 for //letter/paragraph Answer #1 for //letter/paragraph Minor bug here

  39. #2. XMLSpy Choose Evaluate XPath

  40. #2. XMLSpy Answer #1 for //letter/paragraph

  41. #2. XMLSpy Answer #2 for //letter/paragraph

  42. #3. <Oxygen/> Press Enter key Answer #1 for //letter/paragraph

  43. #3. <Oxygen/> Answer #2 for //letter/paragraph

  44. #4 XMLPad

  45. XPath Evaluation in Programming • XPath Engines / Libraries • Apache Xalan-Java: http://xml.apache.org/xalan-j/ • Saxon: http://saxon.sourceforge.net/ • Jaxen: http://jaxen.codehaus.org/ • PL specific APIs • Java: package javax.xml.xpath + DOM • PHP: domxml’s xpath_eval() (v4), SimpleXML (v5)

  46. Eg. XPath in JAVA public Node findAddress(String name, Document source) throws Exception { // need to recreate a few helper objects XMLParserLiaison xpathSupport = new XMLParserLiaisonDefault(); XPathProcessor xpathParser = new XPathProcessorImpl(xpathSupport); PrefixResolver prefixResolver = new PrefixResolverDefault(source.getDocumentElement()); // create the XPath and initialize it XPath xp = new XPath(); String xpString = "//address[child::addressee[text() = '” +name+"']]"; xpathParser.initXPath(xp, xpString, prefixResolver); // now execute the XPath select statement XObject list = xp.execute(xpathSupport, source.getDocumentElement(), prefixResolver); return list.nodeset().item(0); } http://www.javaworld.com/javaworld/jw-09-2000/jw-0908-xpath.html?page=3

  47. Eg. SimpleXML in PHP <?php    $xml = simplexml_load_file('employees.xml');    echo "<strong>Using direct method...</strong><br />";    $names = $xml->xpath('/employees/employee/name');    foreach($names as $name) {        echo "Found $name<br />";    } echo "<br />";    echo "<strong>Using indirect method...</strong><br />";    $employees = $xml->xpath('/employees/employee');    foreach($employees as $employee) {        echo "Found {$employee->name}<br />";    } echo "<br />";    echo "<strong>Using wildcard method...</strong><br />";    $names = $xml->xpath('//name');    foreach($names as $name) {        echo "Found $name<br />";    }?> http://www.tuxradar.com/practicalphp/12/3/3

  48. Lab #2 (DUE: Sep. 25 11:55PM) • https://online.ist.psu.edu/ist516/labs • Tasks: • Individual Lab • Using an XML files, practice XPath queries • Turn-In • XPath queries and English interpretation • Screenshot of results of XPath queries
