  1. ED 1 DATE: 2003.03.18 SIGN: SKRO 1404 9205-HD ServiceTool

  2. The purpose of this program is to program the Kirk handset and Kirk repeater. One can adjust the volume, alter the start-up text, load flash code and menus and adjust the gain levels of the microphone and loudspeaker for the Kirk Handset. The repeater can be configured to connect to a Kirk System 1500 or a Kirk residential base (e.g. Kirk System 500 or KCS). To utilise this software for registration of repeaters/handset a special hardware kit is needed. This hardware is required to make the connection between your computer and the repeater or the handset. This hardware can be obtained by contacting KIRK telecom A/S.

  3. Hardware repeater programming The hardware package consists of two items (A serial cable and a modular connector adapter). Connect the serial cable to the modular connector adapter. Connect the mains adapter (part of the repeater) to the modular connector adapter. Connect the modular connector adapter to the repeater, the mains adapter to mains (remember to turn the mains on) and the serial cable to the comport of your computer (1 to 4).

  4. Hardware handset programming The Service Tool for Handset includes a Serio Interface and a Serial cable for the handset and an adaptor. Alternative The KIRK Docking Station can be use – with the Power supply disconnected.

  5. Comport Setting/Repeater Select Comport Set Comport Repeater connected Select Baudrate (8600 for 2G4)

  6. KIRK System 1500 Repeater Programming CCFP Ari. No. RFP No. to synchronise on WRFP number Write to the WRFP

  7. KIKR System 1500 Repeater Programming Read from the WRFP Clear data from field

  8. Residential/KIRK System 500 Repeater Programming RFP No. to synchronise on : Always 1 when KIRK System 500 or KCS Write to the WRFP SN. No. Residential Base/Dect-z 500 WRFP number

  9. KIRK System 500 Repeater Programming Read from the WRFP Clear data from field

  10. Comport Setting/Handset Set Comport Handset/PP connected Select Comport

  11. Start-up Text in Handset Write text If it is a Z-3040 this box has to be ticked of Write text to PP

  12. Adjustment of Gain Values in Handset Press when new handset is connected Initial values can be given into PP Values read the first time ! Read gain value Write new setting/values to PP Adjust loudspeaker volume (Max = 0) 1 dB per step Adjust microphone gain (Max = F) 2 dB per step

  13. Load of Menu to Handset Load new menu into the handset

  14. Load of Menu to Handset Select the menu file Open the file

  15. Load of Flash to Handset Load new flash file into the handset

  16. Load of Flash to Handset Start the programming Select the flash file Open the file

  17. Load of Flash to Handset Press power on (PP) and “any key “ (PC) at the same time until the programming has started.

  18. Load of Flash to Handset Programming running Upgrade done

  19. Serial Number Handset Read back of the Serial Number of the handset.

  20. This program was presented by KIRK telecom A/S Langmarksvej 34 DK-8700 Horsens Tlf.: +45 7560 2850 Fax.: +45 7560 2851 www.kirktelecom.dk
