  1. Interface DesignPCB Design Tips Omid Fatemi

  2. Outline

  3. IC Technology • TTL • NMOS • CMOSBiCMOS

  4. IC Fan-Out • Fan-out (low) =

  5. Example

  6. Capacitance Derating • Capacitance of IC pins (5 to 7 pF) • I = CVF • Each 50 – 100 pF capacitor • extra 3 ns delay

  7. Example

  8. Ground Bounce

  9. Transient Current • I = C (dV/dt) • Change in V  peak in I • Decoupling capacitormake less change in V • .01 - .1 microF between Vcc and Gnd

  10. Cross-talk • More distance • Shorter • Ground lines between traces

  11. Transmission Line Ringing

  12. FIT and MTBF

  13. High Speed Design • Between CPU and Cache • Short cycle and access time required •  zero wait state • Timing analysis required • Assume: CPU 60MHz, access time: 10ns

  14. Timing Diagram

  15. Timing Analysis • tflight = tclock skew + tpropagation delay + trise time • Clock skew: • Difference in rising and falling edge of clock cycle for different components • Propagation delay • RC analysis • Transmission line analysis • Rise time • Speed of component driving the line • External capacitive loading should be considered

  16. Problems • 4, 5, 21, 37 • 40, 42
