  1. What is the optimal size for a solar absorber? Stephen Evans Samuel Seager Me 340 Dr. Vladimir Solovjov

  2. The component of direct radiation • Xcosø = Wm/2 • X = Wm/(2cosø) • Qdir = AEa q” = WmL/2cosø(Eaqdir”)

  3. The component of diffused radiation • tan(θ/2) = (Wa/2)/d • θ/2 = arctan(Wa/2d) • θ = 2arctan(Wa/2d) • Percentage of diffused radiation is: η • η = angle of projected/total projected = θ/Π = (2/Π) arctan (Wa/2d) • Qdiff = Aηqdiff = (WmL2/Π)arctan (Wa/2d)

  4. Net energy from radiation • Q = [(WmL/2cosθ)(Eaqdir”) + (2WmL/Π) arctan (Wa/2d)]n - Ea r(Ta4 – T∞4)WaL • Plot with varying Wm to find qmax • Conclusion: The ideal width for the solar collector absorber should be in the range of 40 to 60 inches depending on its surface temperature.
