1. A forward looking DM Ideas for a HEP computing model Fabrizio Furano (CERN IT/GT)

2. The problem • HEP experiments are very big data producers • The HEP community is an aggressive data consumer • Analyses rely on statistics on complex data • Scheduled (production) processing and user-based unscheduled analysis • Performance, usability and stability are the primary factors • The infrastructure must be able to guarantee access and functionalities • The softwares must use the infrastructures well F.Furano - A forward looking DM

3. Structured files • In the present times most computations are organized around very efficient “structured files” • The ROOT format being the most famous • They contain homogeneous data ready to be analyzed, at the various phases of HEP computing • Centrally-managed data processing rounds create the “bases of data” to be accessed by the community F.Furano - A forward looking DM

4. Distributed data • “One site is not enough to host everything and provide sufficient access capabilities to all the users” • In the pre-Grid days the BaBar users were used to “manually choose” the site where they wanted to do analysis (i.e. hosting their favorite skims) by logging into it • We suppose that a worldwide distributed storage is necessary for SuperB, like in many modern experiments •  we start to become interested in what technologies could be available and easy to adopt in the next few years F.Furano - A forward looking DM

5. The minimalistic workflow • In general, an user will: • Decide which analyses to perform for his new research • Develop the code which performs it • Typically a high level macro or a “simple” plugin of some experiment-based software framework • Ask a system about the data requirements • Which files contain the needed information • Ask another system to process his analysis • Collect the results Typically an experiment-based metadata repository and/or file catalogue Typically the GRID (WLCG) or batch farms or PROOF-like things This will likely become also his own computer as the hw performance increases and the sw uses it efficiently F.Furano - A forward looking DM

6. Semi-automated approach • One can: • Choose carefully where to send a processing job, e.g. to the place which best matches the needed data set • Use tools to create local replicas of the needed data files • In the right places • Eventually use tools also to push new data files to the “official” repositories • If overdone this can be quite time and resource consuming • Any variation is possible • E.g. pre-populate everything before sending jobs, guessing the ‘perfect match’ between job needs and storage content F.Furano - A forward looking DM

7. Direct approach • We might want not to be limited by local access • I.e. not pre-arrange all the data close to the computation (really a very tough problem) • The technologies allow more freedom if: • Everything is available r/w through URLs • proto://host/path • The analysis tools support URLs to random access files • The I/O is performed at byte level directly in the file without copying it • The analysis tools exploit advanced I/O features • E.g. ROOT TTree + TTreeCache • At some extent, this can work also via WAN. We will see more and more real-world examples of this. • If overdone, the WAN could become a limiting factor • Less and less… the bandwidth is increasing very fast • HEP data files are big and quite static, better to exploit locality if possible • Use or create locality as an optimization F.Furano - A forward looking DM

8. Outsource? • Cloud services, outsourcing • If this is seen as a possible future need: • Desirable to organise things so that it is possible with a low effort • This could have an impact on some choices, e.g. the data protocols that are supported/used • More difficult to ask a hosting for complex custom systems • Easier to ask for a ‘normal’ service i.e. a Web server F.Furano - A forward looking DM

9. Where is file X • The historical approach was to implement a “catalogue” using a DBMS • This “catalogue” knows where the files are • Or are supposed to be • This can give a sort of “illusion” of a worldwide file system • It must be VERY well encapsulated, however • It would be nicer if this functionality were inside the file system/data access technology • No need for complex systems/workarounds/glue code F.Furano - A forward looking DM

10. The protocol Babel • Some are affectionate to this idea, i.e. using • A protocol (+its tools) to transfer files • A protocol (+its tools) to access them in some sites • A protocol (+ its tools) to access them in other sites • A protocol (+ its tools) to access system X, then Y, then Z • A protocol (+ its tools) to access <put your thing here> • The impression is that these were often workarounds for protocols and tools that were not adequate to the (distributed) HEP use cases, or poorly implemented • This surely highers the cost of development and operation • The Web has use cases that are quite similar to the ones of HEP, and it uses only one • This should be a good inspiration for the evolution of a new computing model F.Furano - A forward looking DM

11. Current and future evolutions F.Furano - A forward looking DM

12. The survivors • Likely, in a few years we will have just a few major alternatives for HEP data processing • XROOTD, ramping up now in the LHC experiments • EOS: an xrootd-based system, tailored to the needs of a big storage farm for HEP (currently only at CERN) • HTTP/WebDAV • Moves the world, slightly less efficient but with highly robust products that support it • By now misses the client implementations of some features that are needed for HEP • NFS4.1 • A relatively new entry, as a refurbishment of a much older one • For some it’s a promising path F.Furano - A forward looking DM

13. Xrootd and Scalla • In 2002 there was the need of a data access system providing basically: • Compliance to the HEP requirements • “Indefinite” scaling possibility (up to 200Kservers) • Maniacally efficient use of the hardware • Accommodate thousands of clients per server • Great interoperability/customization possibilities • In the default config it implements a non-transactional distributed file system • Efficient through LAN/WAN • Not linked to a particular data format • Particularly optimized for HEP workloads • Thus matching very well the ROOT requirements F.Furano - A forward looking DM

14. Xrootd and Scalla (contd.) • Build efficient local storage clusters, virtually no limit to scalability • Aggregating storage clusters into WAN federations • Access efficiently remote data through WAN • Push/pull files SE-to-SE without datamovers or external systems • Build proxies which can cache a whole repository • And increase the data access performance (or decrease the WAN traffic) through a decent ‘hit rate’ • Build hybrid proxies • Caching an official repository while storing local data locally • Keep an eye on the development of EOS at CERN F.Furano - A forward looking DM

15. HTTP/WebDAV • Wikipedia: “A set of methods based on HTTP that facilitates collaboration between users in editing and managing documents and files stored on WWW servers” • We know it because we can browse a repository, or even mount it, with the favourite tools of our desktop/laptop • Clients available in all modern operating systems, supported by various browsers and file managers • Not quite born for HEP, but a well performed R&D activity could do it • Most of the features are there, one could start with it immediately (maybe with suboptimal results for a full-optional HEP model) • Easy to outsource such a service, if based on standard industry components F.Furano - A forward looking DM

16. HTTP/WebDAV (cont.) • In the case it’s chosen for a future data access schema for HEP, some work has to be done to give to a client the funcs needed for HEP (e.g. auth/authz, redirections, sessions, multistreaming) • The implementation in ROOT is a private one, very basic (but works quite well) • Not very easy but a very promising project to work on Courtesy of Alex Alvarez Ayllon (CERN IT/GT) F.Furano - A forward looking DM

17. NFS4.1 • A more modern version of the NFS protocol, adding features, also performance and scalability-oriented • Supports the POSIX semantics and parallel access (pNFS), supported by well known products (e.g. dCache and DPM) • “Contains the protocol elements to support WAN data access” is one of the statements. No HEP-related tests of this are known to me. • It’s a distributed file system, whose client is available in the more recent Linux kernels. In a few years it will be a normal thing to have. • For sure it will be adequate to the needs of a single data center • Provided that there is ‘glue code’ that connects the site to the others • Several HPC gurus (e.g. in Google) are suspicious against pure POSIX data access, supposed to put limits on scaling F.Furano - A forward looking DM

18. Federations • Suppose that we can easily aggregate remote storage sites • And provide an efficient entry point which “knows them all natively” • We could use it to access data directly between sites • A job willing to access data willl not know that the data is in a friend site, it will just access it • We could use it as a building block for a self-referring federation • If site A is asked for file X, A will fetch X from some other ‘friend’ site, though the unique entry point • A itself is a potential source, accessible through the aggregating entry point • The XROOTD framework supports this natively, however it’s a quite general idea that can be applied to other systems F.Furano - A forward looking DM

19. An idea for an analysis facility • It contains: • Institutional data: proxied • Personal user’s data: local only • Data accessible through: • FUSE mount point if useful • Simple data mgmt app • Native access from ROOT (more efficient) • Accessible through WAN • Possibility to travel and still see the same repository from the (connected) laptop, that maybe has also some persistent caching (e.g. one of the new things in ROOT) • Federable with friend sites with the least amount of glue code/systems • Examples of this are in the ALICE CM and in some CMS sites, surely this concept will ramp up and become more popular F.Furano - A forward looking DM

20. Conclusion • “The next level in Storage+Data Access/Data Management” … • A Web-like functional level, tailored to theparticularHEP requirements • Very good examples right now, many others are coming • Interoperability and performance are the key factors F.Furano - A forward looking DM

21. Thank you Questions? F.Furano - A forward looking DM

22. The Data Management • Files and datasets are stored into Storage Elements, hosted by sites • The decision is often taken when they are produced • Processing jobs are very greedy • Up to 15-20 MB/s now. • The GRID machinery (ev. Together with some service of the experiment) decides where to run a job • The service can also be human-based (!) • Matching the locations of the data with the available computing resources is known as the “GRID Data Management Problem”. F.Furano - A forward looking DM

23. An example B C B E A C F Need: F,B D G Need: A,E Need: G,E D F G E G D Need: D,E Need: G,A My distributed sites With pre-filled storage With computing farms My data greedy jobs F.Furano - A forward looking DM

24. WAN data access • In WANs each client/server response comes much later • E.g. 180ms later • With well tuned WANs one needs apps and tools built with WANs in mind • Bulk xfer apps are easy (gridftp, xrdcp, fdt, etc.) • There are more interesting use cases, and much more benefit to get • The WAN direct access for analysis is a reality since quite some time. F.Furano - A forward looking DM
