  1. Development of a Coupled Solar-Biological System for the Disinfection and Elimination of Organic Contaminants in Drinking and WasteWaters in Rural Areas of Colombia(BIOSOLAR-DETOX)

  2. Dr. Cesar Pulgarin Dr. Janeth Sanabria Dr. Norberto Benitez Dr. Miguel Peña Responsibles

  3. Cali Project Location in Colombia

  4. Scientific targets • Drinking Water Treatment by Coupling of Filtration and Helio Photocatalytic Processes • Domestic Wastewater Reusing in Agricultural Activities after Combined Biological Helio-Photocatalytic Treatment • Agroindustrial wastewater treatment by a coupled Helio-photocatalytical-biological system

  5. Schematic Representation of the Water Uses in the Colombian Water Cycle

  6. Natural Receptors highly Contaminated Non Treated Domestic Waste-Waters

  7. Chlorination is a widely used technique for the disinfection of water. Its bacterial inactivation effect has been proven but a great concern is that chemical risks could be enhanced due to by-products formed during the chlorination process. Water disinfection Therefore, the necessity to find low cost, environmental friendly and sustainable alternative, or complement, to chlorination.

  8. Disinfectants and disinfection-by products (DBPs)apparition of chemical riskto human THMs: CHCl3, CHCl2Br, CHClBr2, CHBr3 haloacetates, haloacetonitriles, haloacetaldehydes, haloketones, halofuranones, chloropicrin, chlorate aldehydes, carboxylic acids • Chlorine • chlorine dioxide • chloramine • Ozone • hydrogen peroxide Halogenated compounds, chlorite, chlorate Cyanogen, chloride and others generally thought to be the same DBPs as chlorine, but lower concentration Bromate, hydrogen peroxide bromomethanes, bromoacetates, bromoaldehydes, bromoketones, iodinated Analogs, aldehydes, carboxylic acids Carboxylic acids UV Not DBPs

  9. TiO2- semiconductor photocatalytic process

  10. 1. Drinking Water Treatment by Coupling of Filtration and Helio Photocatalytic Processes Puerto Mallarino DRINKING WATER Plant

  11. Expected Results:Drinking Water Treatment by Coupling of Filtration and Helio Photocatalytic Processes

  12. 2. Domestic Wastewater Reusing in Agricultural Activities after Combined Biological Photocatalytic Treatment GINEBRA Transference and Treatment Station

  13. Expected Results

  14. 3. Agroindustrial wastewater treatment by a coupled Helio-photocatalytical-biological system

  15. PESTICIDES AND POLLUTION • Aerial and manual pesticides application • Cleaning recipients

  16. Inicial wastewater characterization

  17. Expected Results: Agroindustrial wastewater treatment by a coupled Helio-photocatalytical-biological system

  18. Group of Coupled Chemical-Biological Processes (ENAC-LBE) Dr. Cesar Pulgarin Dr. Sandra Parra EIDENAR Chemical Eng. School Dr Janeth Sanabria MSc. Luz E. Barba Dr. Fiderman Machuca MSc. Carlos Dierolf Chemical Dept. Dr. Norberto Benitez Dr. Miguel Peña UNIVALLE-GAOX OTHER INSTITUTIONS NETHERLANS EMBASSY EMCALI COLCIENCIAS Dr. María de la Fuente Project Partners EIER Ecole Inter Etats d’Ingenieurs de l’Equipement Rural Dr. Amadou Hama Maiga Dr. Joseph Wethe

  19. Different Work-Packages

  20. Research Team in UNIVALLE Colombia

  21. Microbiological components Reactor components Chemistry components Student’s Group M.Sc. StudentsSandra Rivera Doctoral StudentsDiana Serrano Doctoral StudentsJulian Rengifo M.Sc. StudentsDorance BecerraLuis Ferney Gonzalez Doctoral StudentsAlejandro MoncayoClaudia Mendoza M.Sc. StudentsAndres López Doctoral StudentsJosé Colina

  22. Student Team in Univalle Colombia

  23. Research Team in EPFL

  24. Realized tasks • Selection of Student group • Selection of the study place • Acquisition of material and equipment • Space arrangements and laboratories conditioning • Bibliographic review • Chemical and microbiological initial characterization of samples • Definition of first step in collaboration between UV-CINARA-EIER • Agreement for the supply of demonstrative solar prototype by a Spanish photoreactor maker.

  25. Photocatalysis as post-treatment of biologically treated wastewaters in the framework of water reuse in agriculture Schéma Représentatif de la Estación de Investigación y Transferencia de Tecnología en el Tratamiento de Aguas Residuales y Re - uso de Ginebra- Valle. Le système de traitement biologique comporte 4 bassins: réacteur UASB (1), lagune anaérobie (2), lagune contenant des plantes aquatiques (3), lagune facultative (4).

  26. Available Reactors Suntest • CPC UV lamp

  27. Initial Chemical characterization of Wastewater of Ginebra Station

  28. Initial Microbiological characterization of Wastewater of Ginebra Station

  29. glyphosate Pesticides used
