EEE 243B Applied Computer Programming

1. EEE 243BApplied Computer Programming Modules and information hiding

2. Review • What are the three concepts used by humans to deal with the complexity of problems? • If I have the following: int a[3] = {1,7,9}; int *p = a; // a pointer int *r = &a[1]; *p = r[0]; //What is the result of this? r[-2] = *p; //What does this do? Maj JGA Beaulieu & Capt MWP LeSauvage

3. Outline • Modular decomposition - (the higher level) • Information hiding • The C module • The C module - function prototypes • A small example • Building with components Maj JGA Beaulieu & Capt MWP LeSauvage

4. Modular decomposition • So far we have seen that we can decompose a large monolithic function (main) into many smaller and cohesive functions • Up to now, all of the functions that we have defined ourselves, have all been defined into one program file; a compilation unit • We have also learned what a function prototype is, and how to declare one within our program file. Maj JGA Beaulieu & Capt MWP LeSauvage

5. Modular decomposition • Large computer programs just do not appear out of nowhere • Well designed software, like any other products of engineering, should be designed with a philosophy of planning and careful implementation • Similar to an office building, a software program should have a well-designed structure; an architecture Maj JGA Beaulieu & Capt MWP LeSauvage

6. Modular decomposition • For large programs, it is not sufficient to decompose a program into functions • The architecture of a large program should be expressed into separate compilation units • These separate compilation units in C are called modules • You already have used several library modules such as stdio, conio, dsound,… • You also have used a locally developed module, the 243_lib skeleton Maj JGA Beaulieu & Capt MWP LeSauvage

7. Information Hiding • The concept of information hiding originates from a seminal paper from David Parnas (1972) • Information hiding: « Each module has a secret which it hides from other modules. » Maj JGA Beaulieu & Capt MWP LeSauvage

8. Information Hiding • The concept of information hiding is key to the concepts of decomposition and abstraction • Hide the information that can or may change and expose a stable interfacethat will not change • The information is ONLY accessed through the interface, never directly – It is hidden Maj JGA Beaulieu & Capt MWP LeSauvage

9. Information Hiding • Why is information hiding important? • If we encapsulate the information that can change in the module implementation and provide the service through a stable interface, then the user of the module does not need to know about the implementation • I can change the implementation to improve the performance, due to hardware/platform changes… • I therefore reduce the coupling between modules. The program is more maintainable Maj JGA Beaulieu & Capt MWP LeSauvage

10. Information Hiding • So what is this secret I am trying to hide? There are three types of information hiding modules: • Behaviour-hiding: Hides something like screen formats, print formats, user menus, communication of data, change in state etc… • Ex: conio.h – hides the way output to screen is formatted and how keys presses are obtained • Design decision-hiding: Hides the kind of data structures and algorithms you use • Ex: tm.h – hides the algorithm and structures for task management • Machine-hiding: Hides platform specific interfacing • Ex: 243_lib.h – hides the brickOS specific functions and some types • Ex: dsound.h – hides the way sounds are played on H/W Maj JGA Beaulieu & Capt MWP LeSauvage

11. Information Hiding • When we apply the concept of information hiding, we can separate our concerns and decompose our problem into cohesive units of compilation • All the software engineering concepts that we have discussed to this point are design concepts • The extent to which each of these concepts can be implemented in the code depends on the support provided by the language Maj JGA Beaulieu & Capt MWP LeSauvage

12. The C Module • C provides two different kinds of files that allow us to define modules • The .h file – or module header: Contains the declaration of functions and attributes that we want other compilation units to have access to. AKA module interface • The .c file – or module body: Contains the definition of the functions that are declared in the module header as well as other internal or helper functions. AKA module implementation Maj JGA Beaulieu & Capt MWP LeSauvage

13. The C Module • When you include a module header in your programs, only the functions and attributes that are declared in the header are available • It is NOT a good idea to give direct access to your variables inside a module Maj JGA Beaulieu & Capt MWP LeSauvage

14. The C Module - Prototypes • A module must have two files with the same name but with the .c and .h extensions (243_lib.c, 243_lib.h) • You must declare a function prototype in the header file for each of the function that you want other modules to have access to • You can also include some derived types in the header. We will see those next week. Maj JGA Beaulieu & Capt MWP LeSauvage

15. Example – great_small.c #include <stddef.h> #include “compare.h” void main(void) { int firstInt = 5; int secondInt = 10; int *pIntG = NULL; int *pIntS = NULL; pIntG = Greater(&firstInt,&secondInt); pIntS = Smaller(&firstInt,&secondInt); printf("Greater: %d Smaller: %d", *pIntG, *pIntS); } //main Maj JGA Beaulieu & Capt MWP LeSauvage

16. Example – compare.h //compare.h the interface of compare blablabla #include <stddef.h> //return a pointer of type int that points //to the greater of two ints int *Greater(int *px, int *py); //return a pointer of type int that points //to the smaller of two ints int *Smaller(int *px, int *py); Maj JGA Beaulieu & Capt MWP LeSauvage

17. Example – compare.c //compare.c the body of compare module blablabla //return a pointer of type int that points //to the greater of two ints int *Greater(int *px, int *py) { return (*px > *py ? px : py); }//Greater //return a pointer of type int that points //to the smaller of two ints int *Smaller(int *px, int *py) { return (*px < *py ? px : py); }//Smaller Maj JGA Beaulieu & Capt MWP LeSauvage

18. Building with components • As modules are developed worldwide, libraries and reusable components emerge • These components are either full executable solutions or piece parts to be assembled into larger systems • Information hiding and abstraction make it possible to build solutions from known components without knowing how they are built • The suite of MS-OfficeTM has been redesigned with this concept in mind Maj JGA Beaulieu & Capt MWP LeSauvage

19. Quiz Time • What is information hiding? • Why is information hiding important? • What do we mean when we say encapsulating? • A header file is also called the module _____________ • A body file is also called the module _____________ Maj JGA Beaulieu & Capt MWP LeSauvage
