1. An Introduction to System Engineering Professor Peter Gorm Larsen (pgl@iha.dk) An Introduction to System Engineering

2. Agenda • What is System Engineering? • Systems require Interdisciplinary Approaches • The Systems Challenge • Software inside Systems • Model-Based System Engineering • What is the Aim of this Study Group? An Introduction to System Engineering

3. System Engineering: Definition (Incose) • Systems Engineering is an interdisciplinary approach and means to enable the realization of successful systems. It focuses on defining customer needs and required functionality early in the development cycle, documenting requirements, then proceeding with design synthesis and system validation while considering the complete problem: • Operations • Performance • Test • Manufacturing • Cost & Schedule • Training & Support • Disposal An Introduction to System Engineering

4. System Engineering: Definition (Incose) • Systems Engineering integrates • All the disciplines and • specialty groups into a team effort forming a structured development process that proceeds from concept to production to operation. • Systems Engineering considers both • The business and • The technical needs of all customers with the goal of providing a quality product that meets the user needs. An Introduction to System Engineering

5. How to make integration? Control system Technical system Information System System organisation Technological System Sub-system technology Sub-system Information Logistic Sub-system human Information and Decision System An Introduction to System Engineering

6. Integration versus specific domains Standards IEEE 1220 EIA 632 ISO 15288 System engineering System Integration Soft-Eng ISO 12207 Expertise for specific domain Chemical Mechanical Implementation of each component An Introduction to System Engineering

7. The SE context An Introduction to System Engineering

8. System Layering An Introduction to System Engineering

9. Standards • IEEE-1220 • INCOSE/EIA-632 • ISO 15288 • Specific : aeronautic . ARP and space ECSS-E10 Standard are guideline for common understanding and Good Practice An Introduction to System Engineering

10. Agenda • What is System Engineering? • Systems require Interdisciplinary Approaches • The Systems Challenge • Software inside Systems • Model-Based System Engineering • What is the Aim of this Study Group? An Introduction to System Engineering

11. Inter-disciplinary involvement An Introduction to System Engineering

12. Systems may be any technology • Mechanical • Electronic • Software • Chemical • Thermodynamic • Human organizations • Biological An Introduction to System Engineering

13. Not everything that has parts is a system • For components to “interact”, there must be an idea of “state” and relationship between states of components: • Two components interact if the state of at least one is impacted by the interaction having occurred • A book, a piece of music, or a photograph have their own components, but not direct interactions between them • This view distinguishes the engineering view of systems from “systems” in some other fields. An Introduction to System Engineering

14. Example system • System: Semi-trailer truck hauling freight • Components: engine, power train, suspension, lubrication system, fuel system, braking system, electrical system, cab, trailer, navigation system, communication system, software modules • Relationships: physical containment, power dependency, control interaction, mechanical connection, thermal interaction An Introduction to System Engineering

15. Physical and Logical Systems • A Logical System is equivalent to a functional role. • Physical Systems may be assigned responsibilities to perform roles that are Logical Systems. • What plays the role of Engine System in a gas-fired generator? • What plays the role of Engine System in a hybrid automobile? • Example of Logical System: • Engine System: An Engine System converts atmospheric air and chemical fuel into rotating mechanical power for use by other machine subsystems. • Examples of Physical Systems: • Toyota Camry Model XLE Automobile • Caterpillar Model 3406 Diesel Engine • Program Module 1750 An Introduction to System Engineering

16. Services • A Service is: • a feature of a system • what system users consume • something that can be measured and be subject to a service level agreement An Introduction to System Engineering

17. The system engineering process An Introduction to System Engineering

18. System hierarchies An Introduction to System Engineering

19. System architecture modelling • An architectural model presents an abstract view of the sub-systems making up a system • May include major information flows between sub-systems • Usually presented as a block diagram • May identify different types of functional component in the model An Introduction to System Engineering

20. An Example of System Components An Introduction to System Engineering

21. Agenda • What is System Engineering? • Systems require Interdisciplinary Approaches • The Systems Challenge • Software inside Systems • Model-Based System Engineering • What is the Aim of this Study Group? An Introduction to System Engineering

22. The Systems Challenge The Man-Made World Is Increasingly Populated by Systems • Transportation, Energy & Power Systems • Manufacturing, Construction Systems • Telecommunication Networks • Man-Made Biological & Health Care Systems • Facility, Properties • Business Processes • Other Man-Made and Natural Systems An Introduction to System Engineering

23. The Systems Challenge These Systems Are Becoming More Complex • Under pressure of demand & competition • Enabled by progress in technology • Becoming more complex at exponentially growing rates An Introduction to System Engineering

24. The Systems Challenge The Growth Of Systems Complexity Eventually Can Outpace Human Ability To: • Describe • Predict • Manage • Monitor • Configure • Evolve • Understand • Install • Operate • Repair • Maintain • Account For • Communicate About • Design and Implement • Manufacture • Diagnose • Control • Maintain Security Of Those Systems . . . An Introduction to System Engineering

25. The Systems Challenge . . . At Least Within Reasonable: • Time • Cost • Effort • Sense of Security from Risk Incose : Faster, Better and Cheaper For a meal : must NOT result in MacDonald Hamburger !! An Introduction to System Engineering

26. Agenda • What is System Engineering? • Systems require Interdisciplinary Approaches • The Systems Challenge • Software inside Systems • Model-Based System Engineering • What is the Aim of this Study Group? An Introduction to System Engineering

27. Software and systems engineering • Proportion of software in systems is increasing. Software-driven general purpose electronics is replacing special-purpose systems • Problems of systems engineering are similar to problems of software engineering • Software is (unfortunately) seen as a problem in systems engineering. Many large system projects have been delayed because of software problems An Introduction to System Engineering

28. Expressing Requirements • Maturity levels for expression of requirements • Standard languages and methods • Dedicated methods • Others Intended message and perceived message : That´s all about semantics !! Pragmatics and Syntactic issues have a role An Introduction to System Engineering

29. Requirement validation • Importance of Validation • V&V Techniques Eureka, It Works !! It means it corresponds to What You requested and What You needed An Introduction to System Engineering

30. Concept of Operations • The concept of operations (ConOps) document is a bridge between the operational requirements (events occurring over time) and the technical requirements (static, hierarchical description).  It is written in narrative prose that is in the user's language.  It states priorities, it uses visual images and leads to software requirements.  • IEEE Standard 1362, IEEE Guide for Concept of Operations Document, 1998. An Introduction to System Engineering

31. Needs, requirement and specification { Concept of operations (the mission) Requirements NEEDS Specification (Software requirements) An Introduction to System Engineering

32. Why SE?: A Bad Experiences with Software Eng. (source NASA) An Introduction to System Engineering

33. An Introduction to System Engineering

34. The Embedded Systems Challenge We need a new formal foundation for computational systems, which systematically and even-handedly re-marries performance and robustness. What is being computed? At what cost? How does the performance change under disturbances? (change of context; change of resources; failures; attacks) An Introduction to System Engineering

35. Embedded Systems Constraints Execution constraints CPU speed power failure rates Embedded System Computation algorithms protocols reuse Reaction constraints deadlines throughput jitter An Introduction to System Engineering

36. Hardware Engineering solves a part of the equation Embedded System Design is generalized hardware design (e.g. System C) Execution constraints CPU speed power failure rates Embedded System Computation algorithms protocols reuse Reaction constraints deadlines throughput jitter An Introduction to System Engineering

37. Control Engineering solves a part of the equation Execution constraints CPU speed power failure rates Embedded System Computation algorithms protocols reuse Reaction constraints deadlines throughput jitter Embedded System Design is generalized control design (e.g. Mathlab Simulink) An Introduction to System Engineering

38. Current State of Affairs 50 years of computer science are largely ignored in embedded systems design: it is as if there were no choice between automatically synthesizing code on one hand, and assembly coding on the other hand. Software is often the most costly and least flexible part of an embedded system. An Introduction to System Engineering

39. Software Engineering solves a part of the equation Embedded System Design should not be left to electrical engineers Execution constraints CPU speed power failure rates Embedded System Computation algorithms protocols reuse Reaction constraints deadlines throughput jitter An Introduction to System Engineering

40. We need ways to combine views Embedded System Design should not be left to electrical engineers Execution constraints CPU speed power failure rates Embedded System Computation algorithms protocols reuse Reaction constraints deadlines throughput jitter BUT: we need to revisit and revise our most basic paradigms to include methods from EE An Introduction to System Engineering

41. Agenda • What is System Engineering? • Systems require Interdisciplinary Approaches • The Systems Challenge • Software inside Systems • Model-Based System Engineering • What is the Aim of this Study Group? An Introduction to System Engineering

42. Model-based systems engineering • Model-based systems engineering is an emerging approach to systems engineering: • See www.incose.org • Uses explicit models where previously informal, intuitive, natural language prose (e.g., English) of documents was used An Introduction to System Engineering

43. Michael Jackson’s World • A View based on environment and context • A machine (system) to be developed • Machine interacts with an environment • The environment exist; the machine is to be developed • User needs to make abstraction of system • Shared phenomen : Shared The Environment (Private) The machine (Private) An Introduction to System Engineering

44. Systems and their environment • Systems are not independent but exist in an environment • System’sfunction may be to change its environment • Environment affects the functioning of the system e.g. a system may require electrical supply from its environment • Organizational as well as physical environment may be important An Introduction to System Engineering

45. The need to combine different models • We need to be able to describe both the environment and the system • Different parts may be most naturally described in different kinds of models • Ideally we should be able to combine these and analyze them together somehow • Is this possible with existing system engineering techniques? • If not, what would enable such a combination? An Introduction to System Engineering

46. Agenda • What is System Engineering? • Systems require Interdisciplinary Approaches • The Systems Challenge • Software inside Systems • Model-Based System Engineering • What is the Aim of this Study Group? An Introduction to System Engineering

47. Conclusion • Systems engineering is hard! • There will never be an easy answer to the problems of complex system development • Software engineers do not have all the answers but are often better at taking a systems viewpoint • Disciplines need to recognise each othersstrengths and actively rather than reluctantly cooperate in the systems engineering process An Introduction to System Engineering

48. Study group goals • Grasp the importance of System Engineering (SE) • Analysis of selected SE methods, notations and tools • AADL (Architecture Analysis & Design Language) • Meta-H and Dome • SysML en UML 2.0 profile • Harmony (a development process for System Engineering) • AUTOSAR • SCADE • Existence of models bridging the disciplinary gaps? • Examined using a case study • Documented findings • By presentation to the rest of us and • in form of a report in article format An Introduction to System Engineering

49. AADL • The Architecture Analysis & Design Language • http://www.aadl.info/ • Produced primarily by the Society of Automotive Engineers (SAE) • Used for avionics applications in particular • OSATE tool development on top of Eclipse • MetaH AADL Toolset An Introduction to System Engineering

50. SysML • Systems Modeling Language (SysML) • http://www.sysml.org/ • http://groups-beta.google.com/group/SysMLforum • Based on UML • Driven by industry leaders as a response to OMG’s ”UML for Systems Engineering” RFP • Tool support for example for Rhapsody supported by a method called Harmony • Telelogic also has integration between SysML and Simulink (webinar February 15th) An Introduction to System Engineering
