  1. CDF Run Control Implementation Elliott McCrory BD/Proton Source/Linac & CDF September 18, 2001

  2. Talk Overview • Overview • Major OO Components • Some class diagrams • Key Elements: • Classes • Interfaces • Listeners • Transition & TransitionStateMachine • Scripting • Performance Elliott McCrory

  3. Overview of Run Control • RC and most of its components are implemented in Java • OO?? • Platform: FRH Linux • Began with SGI Irix • Swing-based GUI • JDBC • SmartSockets communications • Heavily threaded Elliott McCrory

  4. RunSet (Configuration) Database Error Handler Error Handler Error Handler State Manager State Manager State Manager Consumer Consumer SmartSockets Server(s) OnlineData VME n VME n+3 Level 3 VME n+1 VME n+2 Level 2

  5. Major Components of RC • RunSet editor for client configuration • Error handler for expert system control • Data consumers • VxWorks coordination • General state machine logic • Discussed here • Scripting interface for calibrations Elliott McCrory

  6. GUI Active State Available Transition Unavailable Transition Status of RC Tevatron Status Elliott McCrory

  7. Top-Level Class View rcBase.class daqStateManager.class GenericCalibStateManager.class QIECalibStateManager.class GUI.class Shell.class Jpython Scripting Classes RunSet.class RunSetEditor.class PartitionSelector.class ErrorHandler.class ConsumerEditor.class VxConfig.class RunTypeSelector.class

  8. RC State Machine/Manager FSM.class State.class messenger.class Transition.class ConfigMess.class StateManager.class readoutConfig.class TransitionStateMachine.class daqStateManager.class GenericCalibStateManager.class QIECalibStateManager.class

  9. Key Concepts • Modularism, abstraction, inheritance/polymorphism, data hiding, Mom & apple pie • Some “Design Patterns” • Isolation of GUI from FSM • Control flows “down”; GUI information flows “up” through listeners and interfaces Elliott McCrory

  10. FSM Generalized finite state machine StateManager CDF RC specific State Transition TransitionStateMachine DebugLevel Handles diagnostic printout messenger Singelton Design Pattern Handles messaging to clients ConfigMess Abstract: all clients use this class for their configuration messages ConfigMessageFactory Factory Design Pattern Returns a ConfigMess readoutConfig Handles reception of replies from clients Key Classes Elliott McCrory

  11. Key Interfaces • RCAction • Command Design Pattern • Perform an action when entering a state • public boolean execute() • RCCondition • public boolean isMet() to leave a state • public boolean isViolated() when an error is encountered • public void reset() Elliott McCrory

  12. Key Listeners • GUI Enabling • StateChangeListener • TransitionChangeListener • FsmStatusListener • Global information management • StateEventListener Elliott McCrory

  13. Implementation of Transitions • Specifications say: Sequence RCAction’s • e.g., you must configure all clients (“ColdStart”) before configuring Level 3 • Implemented as a FSM • TransitionStateMachine extends Transition and “Has A” FSM Elliott McCrory

  14. Sx = sub state ESx = Error State Ax = Action upon entering State Cx = Condition for leaving State Transition Sub State Machine Elliott McCrory

  15. Scripting • Used for calibrations • Desire to change one or two parameters in a client crate’s configuration message over ~10 calibration iterations • Initially implemented in Jpython • Basic JPython class extends Java class Shell • Generally requires “isinstance()” JPython operator to find configuration message for crate being calibrated • Being abandoned for all-Java solution • Benefits of scripting (easy changes) not strong enough to outweigh drawbacks (new language). Elliott McCrory

  16. Performance • Startup of rc.GUI: about 1 minute • Java VM: 10’s of MB • Run-time performance: no issue • Knowledgeable and/or relevant programmers: 3 to 10 Elliott McCrory

  17. Summary • Java implementation of CDF Run Control • Swing GUI • Some OO techniques • Calibration scripts in JPython, moving to Java calibration programs Elliott McCrory
