  1. 第 21 章 資料連結控制項與資料庫整合應用

  2. Repeater • DataList • GridView • DetailsView • DataGrid

  3. 21-2Repeater 控制項 <asp:Repeater runat="server" ID="…" DataMember="…" DataSource="<%# … %>"DataSourceID="…" OnItemCommand="…" OnItemCreated="…" OnItemDataBound="…"> <AlternatingItemTemplate> 替代項目樣板，可以包含 HTML 標籤、伺服器控制項… </AlternatingItemTemplate> <FooterTemplate> 頁尾樣板，可以包含 HTML 標籤、伺服器控制項… </FooterTemplate> <HeaderTemplate> 頁首樣板，可以包含 HTML 標籤、伺服器控制項… </HeaderTemplate>這個部份為樣板，用來定義 Repeater 控制項各區域的內容，其中只有 ItemTemplate 為必要樣板，其它樣板都可以省略。 <ItemTemplate> 一般項目樣板，可以包含 HTML 標籤、伺服器控制項… </ItemTemplate> <SeparatorTemplate> 分隔樣板，可以包含 HTML 標籤、伺服器控制項… </SeparatorTemplate> </asp:Repeater>

  4. Repeater 控制項提供下列五種樣板，用來定義各區域的內容： • AlternatingItemTemplate • FooterTemplate • HeaderTemplate • ItemTemplate • SeparatorTemplate

  5. Repeater 控制項的屬性 • DataMember="…" • DataSource="…" • DataSourceID="…" • Items

  6. Repeater 控制項的事件 • OnItemCommand="ProcedureName" • OnItemCreated="ProcedureName" • OnItemDataBound="ProcedureName"

  7. Repeater 控制項用來控制資料輸出的是「一般項目樣板」及「替代項目樣板」，那麼要如何將連結至 Repeater 控制項的資料顯示出來呢？很簡單，只要在一般項目樣板或替代項目樣板加入下列語法即可，其中格式字串可以省略：格式字串的使用方式與 CheckBoxList 控制項的 DataTextFormatString 屬性相同。 <%#Eval("欄位名稱", "格式字串")%>

  8. \Ch21\Repeater_01_Access.aspx 01:<%@ Page Language="VB" %> 02:<%@ Import Namespace="System.Data" %> 03:<%@ Import Namespace="System.Data.OleDb" %> 04:<script runat="server"> 05: Sub Page_Load(sender As Object, e As System.EventArgs) 06: '取得 web.config 組態檔的資料連接設定 07: Dim setting As ConnectionStringSettings = _ ConfigurationManager.ConnectionStrings("OLEDB_Price") 08: 09: '建立資料連接 10: Dim objConn As New OleDbConnection() 11: objConn.ConnectionString = setting.ConnectionString 12: objConn.Open()

  9. 13: 14: '建立 DataReader 物件 15: Dim strSQL As String = "Select * From 零組件報價表 Where 零組件種類='印表機' Order By 廠牌 Asc" 16: Dim objCmd As New OleDbCommand(strSQL, objConn) 17: Dim objReader As OleDbDataReader = objCmd.ExecuteReader() 18: 19: '連結資料 20: myRepeater.DataSource = objReader 21: myRepeater.DataBind() 22: 23: '關閉 DataReader 物件及資料連接 24: objReader.Close() 25: objConn.Close() 26: End Sub

  10. 27:</script> 28: 29:<html> 30: <body> 31: <form id="form1" runat="server"> 32: <asp:Repeater ID="myRepeater" runat="server"> 33: <HeaderTemplate> 34: <h1>印表機報價單</h1> 35: ------------------------- 由此開始 --------------------------<br> 36: </HeaderTemplate> 37: <ItemTemplate> 38: 廠牌：<%#Eval("廠牌")%><br> 39: 規格：<%#Eval("規格")%><br> 40: 價格：<%#Eval("價格")%><br> 41: 報價日期：<%#Eval("報價日期", "{0:yyyy/MM/dd}")%><br><br> 42: </ItemTemplate>

  11. 43: <AlternatingItemTemplate> 44: <i>廠牌：<%#Eval("廠牌")%></i><br> 45: <i>規格：<%#Eval("規格")%></i><br> 46: <i>價格：<%#Eval("價格")%></i><br> 47: <i>報價日期：<%#Eval("報價日期", "{0:yyyy/MM/dd}")%></i><br> 48: </AlternatingItemTemplate> 49: <SeparatorTemplate> 50: <hr align="Left" width="200"> 51: </SeparatorTemplate> 52: <FooterTemplate> 53: ------------------------- 至此結束 ------------------------- 54: </FooterTemplate> 55: </asp:Repeater> 56: </form> 57: </body> 58:</html>

  12. \Ch21\Repeater_02_Access.aspx <%@ Page Language="VB" %> <%@ Import Namespace="System.Data" %> <%@ Import Namespace="System.Data.OleDb" %> <script runat="server"> Sub Page_Load(sender As Object, e As System.EventArgs) '取得 web.config 組態檔的資料連接設定 Dim setting As ConnectionStringSettings = ConfigurationManager.ConnectionStrings("OLEDB_Price") '建立 DataAdpter 物件 Dim strSQL As String = "Select * From 零組件報價表 Where 零組件種類='印表機' Order By 廠牌 Asc" Dim objCmd As New OleDbDataAdapter(strSQL, setting.ConnectionString)

  13. '建立 DataSet 物件 Dim DS As New DataSet() objCmd.Fill(DS, "零組件報價表") '連結資料 myRepeater.DataSource = DS myRepeater.DataBind() End Sub </script> <html> <body> <form id="form1" runat="server"> <asp:Repeater ID="myRepeater" runat="server"> <HeaderTemplate> <h1> 印表機報價單</h1> ------------------------- 由此開始 -------------------------<br> </HeaderTemplate>

  14. <ItemTemplate> 廠牌：<%#Eval("廠牌")%><br> 規格：<%#Eval("規格")%><br> 價格：<%#Eval("價格")%><br> 報價日期：<%#Eval("報價日期", "{0:yyyy/MM/dd}")%><br> </ItemTemplate> <AlternatingItemTemplate> <i>廠牌：<%#Eval("廠牌")%></i><br> <i>規格：<%#Eval("規格")%></i><br> <i>價格：<%#Eval("價格")%></i><br> <i>報價日期：<%#Eval("報價日期", "{0:yyyy/MM/dd}")%>/i><br> </AlternatingItemTemplate>

  15. <SeparatorTemplate> <hr align="Left" width="200"> </SeparatorTemplate> <FooterTemplate> ------------------------- 至此結束 ------------------------- </FooterTemplate> </asp:Repeater> </form> </body> </html>

  16. \Ch21\Repeater_03_Access.aspx (下頁續1/2) <html> <body> <form id="form1" runat="server"> <asp:AccessDataSource ID="AccessDataSource" runat="server" DataFile="~/App_Data/Price.mdb" SelectCommand="Select * From 零組件報價表 Where 零組件種類='印表機' Order By 廠牌 Asc" /> <asp:Repeater ID="myRepeater" runat="server" DataSourceID="AccessDataSource"> <HeaderTemplate> <h1>印表機報價單</h1> ------------------------- 由此開始 -------------------------<br> </HeaderTemplate>

  17. <ItemTemplate> 廠牌：<%#Eval("廠牌")%><br> 規格：<%#Eval("規格")%><br> 價格：<%#Eval("價格")%><br> 報價日期：<%#Eval("報價日期", "{0:yyyy/MM/dd}")%><br> </ItemTemplate> <AlternatingItemTemplate> <i>廠牌：<%#Eval("廠牌")%></i><br> <i>規格：<%#Eval("規格")%></i><br> <i>價格：<%#Eval("價格")%></i><br> <i>報價日期：<%#Eval("報價日期", "{0:yyyy/MM/dd}")%>/i><br> </AlternatingItemTemplate>

  18. <SeparatorTemplate> <hr align="Left" width="200"> </SeparatorTemplate> <FooterTemplate> ------------------------- 至此結束 ------------------------- </FooterTemplate> </asp:Repeater> </form> </body> </html>

  19. 21-3DataList 控制項 <asp:DataList runat="server" ID="…" Caption="…"CaptionAlign="{NotSet|Top|Bottom|Left|Right}" CellPadding="n" CellSpacing="n" DataKeyField="…" DataMember="…" DataSource="<%# … %>"DataSourceID="…" EditItemIndex="n" ExtractTemplateRows="{True|False}"GridLines="{None|Horizontal|Vertical|Both}" RepeatColumns="n"HorizontalAlign="{NotSet|Left|Center|Right|Justify}"RepeatDirection="{Vertical|Horizontal}" RepeatLayout="{Flow|Table}"SelectedIndex="n" ShowFooter="{True|False}" ShowHeader="{True|False}" OnCancelCommand="…" OnDeleteCommand="…" OnEditCommand="…"OnItemCommand="…" OnItemCreated="…" OnUpdateCommand="…">

  20. <AlternatingItemTemplate>替代項目樣板</AlternatingItemTemplate><AlternatingItemTemplate>替代項目樣板</AlternatingItemTemplate> <EditItemTemplate>編輯樣板</EditItemTemplate> <FooterTemplate>頁尾樣板</FooterTemplate> <HeaderTemplate>頁首樣板</HeaderTemplate> <ItemTemplate>一般項目樣板</ItemTemplate> <SelectedItemTemplate>選取樣板</SelectedItemTemplate> <SeparatorTemplate>分隔樣板</SeparatorTemplate> <AlternatingItemStyle … /> <EditItemStyle … /> <FooterStyle … /> <HeaderStyle … /> <ItemStyle … /> <SelectedItemStyle … /> <SeparatorStyle … /> </asp:DataList>

  21. DataList 控制項提供下列七種樣板，用來定義各區域的內容： • AlternatingItemTemplate • EditItemTemplate • FooterTemplate • HeaderTemplate • ItemTemplate • SelectedItemTemplate • SeparatorTemplate

  22. DataList 控制項提供下列七種樣式物件，用來定義各區域的外觀： • AlternatingItemStyle • EditItemStyle • FooterStyle • HeaderStyle • ItemStyle • SelectedItemStyle • SeparatorStyle

  23. 21-3-1DataList 控制項的屬性與事件 • DataList 控制項的屬性 • Caption="…" • CaptionAlign="{NotSet|Top|Bottom|Left|Right}" • CellPadding="n" • CellSpacing="n" • DataKeyField="…" • DataKeys • DataMember="…" • DataSource="…" • DataSourceID="…" • EditItemIndex="n"

  24. ExtractTemplateRows="{True|False}" • GridLines="{None|Horizontal|Vertical|Both}" • HorizontalAlign="{NotSet|Left|Center|Right|Justify}" • Items • RepeatColumns="n" • RepeatDirection="{Vertical|Horizontal}" • RepeatLayout="{Flow|Table}" • SelectedIndex = "n" • SelectedItem • SelectedValue • ShowFooter="{True|False}" • ShowHeader="{True|False}"

  25. DataList 控制項的事件 • OnCancelCommand="ProcedureName" • OnDeleteCommand="ProcedureName" • OnEditCommand="ProcedureName" • OnItemCommand="ProcedureName" • OnItemCreated="ProcedureName" • OnItemDataBound="ProcedureName" • OnSelectedIndexChanged="ProcedureName" • OnUpdateCommand="ProcedureName"

  26. \Ch21\DataList_01_Access.aspx 01:<html> 02: <body> 03: <form id="form1" runat="server"> 04: <asp:AccessDataSource ID="AccessDataSource" runat="server"DataFile="~/App_Data/Address.mdb" SelectCommand="Select * From 通訊錄" /> 05: <asp:DataList ID="myDataList" runat="server" DataSourceID="AccessDataSource" BackColor="LightGoldenrodYellow" BorderColor="Tan" BorderWidth="1px" Caption="通訊錄清單" CaptionAlign="Top" CellPadding="2" Width="600" HorizontalAlign="Center" RepeatColumns="2">

  27. 06: <ItemTemplate> 07: 姓名：姓名：<%#Eval("姓名")%><br> 08: 生日：生日：<%#Eval("生日", "{0:yyyy/MM/dd}")%><br> 09: 電話：電話：<%#Eval("電話") %><br><br> 10: </ItemTemplate> 11: <AlternatingItemTemplate> 12: <b><i>姓名：<%#Eval("姓名")%></i></b><br> 13: <b><i>生日：<%#Eval("生日", "{0:yyyy/MM/dd}")%> </i></b><br> 14: <b><i>電話：<%#Eval("電話")%></i></b><br><br> 15: </AlternatingItemTemplate> 16: </asp:DataList> 17: </form> 18: </body> 19:</html>

  28. 21-3-2　樣式物件的屬性 • BackColor="{ColorName|#RRGGBB}" • BorderColor="{ColorName|#RRGGBB}" • BorderStyle="{NotSet|None|Dotted|Dashed|Solid|Double|Groove|Ridge|Inset|Outset}" • BorderWidth="n" • CssClass="…" • Font • ForeColor="{ColorName|#RRGGBB}" • Height="n" • HorizontalAlign="{NotSet|Left|Center|Right|Justify}" • VerticalAlign="{NotSet|Top|Middle|Bottom}" • Width="n" • Wrap="{True|False}"

  29. 21-4GridView 控制項 <asp:GridView runat="server" ID="…" AllowPaging="{True|False}"AllowSorting="{True|False}" AutoGenerateColumns="True|False"AutoGenerateDeleteButton="{True|False}" CellPadding="n" AutoGenerateEditButton="{True|False}" CellSpacing="n" AutoGenerateSelectButton="{True|False}" BackImageUrl="URI"Caption="…" CaptionAlign="{NotSet|Top|Bottom|Left|Right}" DataKeyNames="…" DataMember="…" DataSource="<%# … %>"DataSourceID="…" EditIndex="n" EmptyDataText="…"EnableSortingAndPagingCallbacks="{True|False}" GridLines="{None|Horizontal|Vertical|Both}"HorizontalAlign="{NotSet|Left|Center|Right|Justify}" PageIndex="n" PageSize="n" SelectedIndex="n" ShowFooter="{True|False}" ShowHeader="{True|False}" OnPageIndexChanged="…" OnPageIndexChanging="…" OnRowCancelingEdit="…" OnRowCommand="…" OnRowCreated="…" OnRowDataBound="…"OnRowDeleted="…" OnRowDeleting="…" OnRowEditing="…" OnRowUpdated="…" OnRowUpdating="…" OnSelectedIndexChanged="…" OnSelectedIndexChanging="…" OnSorted="…" OnSorting="…">

  30. <PagerSettings FirstPageImageUrl="URI" FirstPageText="…"LastPageImageUrl="URI" LastPageText="…"Mode="{NextPrevious|Numeric|NextPreviousFirstLast|NumericFirstLast}" NextPageImageUrl="URI" NextPageText="…" PageButtonCount="n"Position="{Bottom|Top|TopAndBottom}" PreviousPageImageUrl="URI" PreviousPageText="…" Visible="{True|False}" /> <EmptyDataTemplate> 設定當資料來源沒有傳回資料時，GridView 控制項所要顯示的內容，可以包含HTML標籤及其它控制項 </EmptyDataTemplate> <AlternatingRowStyle /> <EditRowStyle /> <EmptyDataRowStyle /> <FooterStyle />

  31. <HeaderStyle /> <PagerStyle /> <RowStyle /> <SelectedRowStyle /> <Columns> <asp:BoundField ApplyFormatInEditMode="{True|False}" ConvertEmptyStringToNull="{True|False}" DataField="…" DataFormatString="…" FooterText="…" HeaderImageUrl="URI" HeaderText="…" InsertVisible="{True|False}" NullDisplayText="…" ReadOnly="{True|False}" ShowHeader="{True|False}" SortExpression="…" Visible="{True|False}"> <ControlStyle /> <FooterStyle /> <HeaderStyle /> <ItemStyle /> </asp:BoundField>

  32. <asp:ButtonField ButtonType="{Button|Image|Link}" CausesValidation="{True|False}" CommandName="…" DataTextField="…" DataTextFormatString="…" FooterText="…" HeaderImageUrl="URI" HeaderText="…" ImageUrl="URI" InsertVisible="{True|False}" ShowHeader="{True|False}" SortExpression="…" Text="…" ValidationGroup="…" Visible="{True|False}"> <ControlStyle /> <FooterStyle /> <HeaderStyle /> <ItemStyle /> </asp:ButtonField> <asp:CheckBoxField DataField="…" FooterText="…" HeaderImageUrl="URI" HeaderText="…" InsertVisible="{True|False}" ReadOnly="{True|False}" ShowHeader="{True|False}" SortExpression="…" Text="…" Visible="{True|False}"> <ControlStyle /> <FooterStyle /> <HeaderStyle /> <ItemStyle /> </asp:CheckBoxField>

  33. <asp:CommandField ButtonType="{Button|Image|Link}" CancelImageUrl="URI" CancelText="…" CausesValidation="{True|False}" DeleteImageUrl="URI" DeleteText="…" EditImageUrl="URI" EditText="…" FooterText="…" HeaderImageUrl="URI" HeaderText="…" InsertImageUrl="URI" InsertText="…" InsertVisible="{True|False}" NewImageUrl="URI" NewText="…" SelectImageUrl="URI" SelectText="…" ShowCancelButton="{True|False}" ShowDeleteButton="{True|False}" ShowEditButton="{True|False}" ShowHeader="{True|False}" ShowInsertButton="{True|False}" ShowSelectButton="{True|False}" SortExpression="…" UpdateImageUrl="URI" UpdateText="…" ValidationGroup="…" Visible="{True|False}"> <ControlStyle /> <FooterStyle /> <HeaderStyle /> <ItemStyle /> </asp:CommandField>

  34. <asp:HyperLinkField DataNavigateUrlFields="…" DataTextField="…" DataNavigateUrlFormatString="…" DataTextFormatString="…" FooterText="…" HeaderImageUrl="URI" HeaderText="…" InsertVisible="{True|False}" NavigateUrl="URI" ShowHeader="{True|False}" SortExpression="…" Target="…" Text="…" Visible="{True|False}"> <ControlStyle /> <FooterStyle /> <HeaderStyle /> <ItemStyle /> </asp:HyperLinkField> <asp:ImageField ConvertEmptyStringToNull="{True|False}" AlternateText="…" DataAlternateTextField="…" DataAlternateTextFormatString="…" DataImageUrlField="…" DataImageUrlFormatString="…" FooterText="…" SortExpression="…" HeaderImageUrl="URI" HeaderText="…" InsertVisible="{True|False}" NullDisplayText="…" NullImageUrl="URI" ReadOnly="{True|False}" ShowHeader="{True|False}" Visible="{True|False}"> <ControlStyle /> <FooterStyle /> <HeaderStyle /> <ItemStyle /> </asp:ImageField>

  35. <asp:TemplateField ConvertEmptyStringToNull="{True|False}" FooterText="…" HeaderImageUrl="URI" HeaderText="…" InsertVisible="{True|False}" ShowHeader="{True|False}" SortExpression="…" Visible="{True|False}"> <ControlStyle /> <FooterStyle /> <HeaderStyle /> <ItemStyle /> <AlternatingItemTemplate> 文字、HTML 標籤或控制項 </AlternatingItemTemplate> <EditItemTemplate> 文字、HTML 標籤或控制項 </EditItemTemplate>

  36. <FooterTemplate> 文字、HTML 標籤或控制項 </FooterTemplate> <HeaderTemplate> 文字、HTML 標籤或控制項 </HeaderTemplate> <InsertItemTemplate> 文字、HTML 標籤或控制項 </InsertItemTemplate> <ItemTemplate> 文字、HTML 標籤或控制項 </ItemTemplate> </asp:TemplateField> </Columns> </asp:GridView>

  37. 21-4-1GridView 控制項的基本觀念

  38. GridView 控制項由下列五個項目所組成： • 標題 • 頁首 • 資料項目 • 頁尾 • 頁面巡覽區

  39. GridView 控制項使用下列八個 TableItemStyle 物件定義其外觀： • AlternatingRowStyle • EditRowStyle • EmptyDataRowStyle • FooterStyle • HeaderStyle • PagerStyle • RowStyle • SelectedRowStyle

  40. GridView 控制項是以表格的形式顯示資料，縱向代表欄位，而 GridView 控制項會顯示哪些欄位，可以透過下列三種方式來決定： • 自動產生欄位 • 手動定義欄位 • 混合式欄位

  41. \Ch21\GridView_01_Access.aspx 01:<html> 02: <body> 03: <form id="form1" runat="server"> 04: <asp:AccessDataSource ID="AccessDataSource" runat="server" DataFile="~/App_Data/Grades.mdb" SelectCommand="Select 學號, 姓名, 會計, 統計, 會計 + 統計 As 總分 From 成績單" /> 05: <asp:GridView ID="GV" runat="server" DataSourceID="AccessDataSource" /> 06: </form> 07: </body> 08:</html>

  42. 21-4-2GridView 控制項的屬性與事件 • GridView 控制項的屬性 • AllowPaging="{True|False}" • AllowSorting="{True|False}" • AutoGenerateColumns="{True|False}" • AutoGenerateDeleteButton="{True|False} • AutoGenerateEditButton="{True|False}" • AutoGenerateSelectButton="{True|False}" • BackImageUrl="URI" • Caption="…" • CaptionAlign="{NotSet|Top|Bottom|Left|Right}" • CellPadding="n" • CellSpacing="n"

  43. BottomPagerRow • Columns • DataKeyNames="…" • DataSourceID="…" • EditIndex="n" • DataKeys • EmptyDataText="…" • EnableSortingAndPagingCallbacks="{True|False}" • FooterRow • GridLines="{None|Horizontal|Vertical|Both}" • HeaderRow

  44. HorizontalAlign="{NotSet|Left|Center|Right|Justify}" • PageIndex="n" • PageCount="n" • PagerSettings • PageSize="n" • Rows • SelectedDataKey • SelectedIndex="n" • SelectedRow • SelectedValue

  45. ShowFooter="{True|False}" • ShowHeader="{True|False}" • SortDirection • SortExpression • TopPagerRow

  46. GridView 控制項的事件 • OnPageIndexChanged="ProcedureName" • OnPageIndexChanging="ProcedureName" • OnRowCancelingEdit="ProcedureName" • OnRowCommand="ProcedureName" • OnRowCreated="ProcedureName" • OnRowDataBound="ProcedureName" • OnRowDeleted="ProcedureName" • OnRowDeleting="ProcedureName" • OnRowEditing="ProcedureName"

  47. OnRowUpdated="ProcedureName" • OnRowUpdating="ProcedureName" • OnSelectedIndexChanged="ProcedureName" • OnSelectedIndexChanging="ProcedureName" • OnSorted="ProcedureName" • OnSorting="ProcedureName"
